Volume Slider

Controls the volume levels of the input sources.

Balance Slider

The sliders control the balance of the left and right speakers for
audio sources with stereo capability. Moving the slider to the left
decreases the volume of the right speaker but the left speaker volume
is left consistent. The opposite applies when you move the slider to
the right.

Automatic Gain Control Check Box

The Automatic Gain Control (AGC) check box automatically adjusts
input gain from the microphone to a level suitable for recording.

Save Button

The Save button saves all changes made to the Mixer to the
CTMIX.CFG file. The new setting will be used the next time you
preset the mixer setting with the command MIXERSET /P.

Input Box

The Input Box enables you to select the audio sources you want to
control as input to the Mixer. The audio sources available are MIDI,
Line and Microphone input, and CD-audio. You can direct these
audio sources through the left or/and right input channels of your
Mixer.

Output Box

The Output Box enables you to select the audio sources you want to
control as output from the microphone, Line-in, and CD-audio to the
left and right speakers. You can select one or a combination of the
above audio sources playing through the card.
To get a stereo sound effect, make sure that the left channel
signal of the audio source is directed to the Left-In channel
and the right signal to the Right-In channel.
MIXERSET Utility 8-5
