INSTALLATION AND SET UP
1. Power Requirements
The ProTron LED Luminaire operates on AC input voltages from 100 to 240 V AC.
W ARNING! This unit does not contain an ON/OFF switch. Always disconnect power input cable to completely
remove power from unit when not in use.
The ProTron LED Luminaires has to be cooled down for 20min after it continuously works for 30 minutes.
Note:
Keep working continuously will do great harm to the luminaire.
Or there will be an power reduction function added, when the power output is at 100%
the power output will be deduced to 50% gradually; when the power output is lower than 100%, the power
output will also be deduced to 50% gradually, but will take more than 30 min to finish the deduction.
AC Power Operation
When connected to an AC source, the unit operates on 100 to 240 volts AC (+/- 10%, auto-ranging). The luminaire
contains an auto-ranging power supply. Each luminaire can draw up to 150 Watts.
W ARNING! Maximum amount of units that may be daisy-chained is (A) 10 units 100 ~ 120VAC (15 Amps) or (B)
units 230 ~ 240VAC
20
Note:
For wiring of AC input connector, refer to
2. Connecting Power
Units can be powered in one of two ways:
Direct connection to an AC power sour ce using an AC input cable. For wiring of AC input connector, refer to
necting
ProTron
Connection from the AC output of another ProTron LED Luminaire. When using this method, it is very important
not
to connect any other type of equipment device.
W ARNING! Only connect other ProTron LED Luminaires to the AC Output (Thru) connector of an ProTron LED
Luminaire.
Connecting ProTron LED Luminaires to AC Power
Table 2 on page 7 describes how to connect power to your ProTron L ED Luminaire. Field wiring of the ProTron
LED Luminaire is straight forward. A total of 3 wires/conductors is supplied from the unit. The following wiring
scheme is used:
6
(15 Amps).
Table 1: ProTron LED Luminaire Voltage (V AC) vs. Current*
Voltage (AC)
Total Current (A)
100
110
120
130
140
150
160
170
LED Luminaires to AC Power" on page 6
Voltage (AC)
1.50
1.36
1.25
1.15
1.07
1.00
0.94
0.88
"Connecting ProTron LED Luminaires to AC Power" on page 6
.
ProTron LED
continuously
Total Current (A)
180
0.83
190
0.79
200
0.75
210
0.70
220
0.68
230
0.65
240
0.63
for 30 min,
.
"Con-
