ProTron LED LUMINAIRE OVERVIEW

1. ProTron LED Luminaire Components

Major Luminaire Components

High Intensity LED Array
Truss Hook / Clamp*
Attachment Point
4
Yoke Assembly
Luminaire Head
Assembly
Figure 1: ProTron LED Luminaire Components
AC Input
DMX512 /
RDM Input
Safety cable anchor point
ProTron LED
AC Output
DMX512 /
RDM Output
Yoke(Tilt) Position
Locking handle
