ICP-CP508 | User's Guide | 1.0 ICP-CP508 Series Codepads Overview
1.0 ICP-CP508 Series
Codepads Overview
The codepad is the communications interface
between you and your alarm system. Use the
codepad to issue commands. The codepad offers
both visual and audible indications that guide you
through the general operation.
The codepad incorporates numerous indicators.
There are zone indicators that show the condition
of each zone and four other indicators for general
status. The following pages outline a list of
situations and the relevant indicators that appear.
Bosch Security Systems, Inc. | 9/08 | F01U089856-01
1.1
Codepad Diagrams
Figure 1:
ICP-CP508W LED Codepad Display
Figure 2:
ICP-CP508LW Eight Zone LCD
Codepad Display
Figure 3:
Codepad Buttons
EN | 2
