Parts Diagrams - Hellenbrand promate 6.0 Owner's Manual

prOMaTe-6.0 COnDiTiOner & brine Tank asseMblies
Item Description
1 Metered Control Valve
2 Top Diffuser
3&4 Mineral Tank Assembly
PM6-024 8 x 44
PM6-032 9 x 48
PM6-032-10 10 x 44
PM6-048 10 x 54
PM6-064 13 x 54
PM6-096 14 x 65
PM6-128 16 x 65
PM6-160 18 x 65
PM6-192 20 x 62
5 Ion Exchange Resin
6 Underbedding
7-15a Brine Tank Assy (18x40)-Granite
b Brine Tank Assy (24x41)
b 24x50 Salt Keeper Tank-Black
9a Salt Keeper Cvr 18x40
b Salt Keeper Cvr 24x41
c Salt Keeper Cvr 24x50
10-14 a Safety Brine Valve Assy 41"
b Safety Brine Valve Assy 50"
10 Cap, Brine Well
11* Safety Brine Valve
12 Float Assembly
13 Air Check
14 a Brine Well 40"-41"
b Brine Well 50"
15 2-Piece Overflow
16 a Grid Plate 18" (optional)
b Grid Plate 24" (optional)
– Owners Manual (Not Shown)
*Must be ordered as complete assembly
NOTE: Do not use 3/4" drain nut & insert (102131 & 101871) when installing connection between softener drain & MAV
24
Qty Part #
1 104306 PM6-32 (see page 26 for detailed components)
Specify Model - ie 24, 32, 48
1 101539
Item 3 only
Mineral Tank
1 104535
1 104539
1 104548
1 104554
1 104567
1 104465
1 104583
1 104585
1 104588
* 101113
No underbedding required for Vortech Tank
1 104449
104424
1 104497
1 101488
Included with 8b
Included with 8c
104172
104173
2 101365
1 101274
1 101660
1 101181
1 102877
102878
1 102217
1 101758
1 101754
1 800198
Item 4 only Not Shown
Distributor Assy Granite Tank Jacket
101505 103626
101508 103630
101505 103633
101512 103638
101512
Tank Adapter
101514
101514 100314
103512 (Hub & Lateral) 100314
103513 (Hub & Lateral) 100314
*See Specifications for amount
Brine Recovery Option
Stock code: 103841 - 36" Well – 40" Brine Tank
103845 - 46" Well – 50" Brine Tank
Qty P/N
A 1 108015 1.25" Stainless Steel Bracket
B 1 102032 1.25" MAV FxFxF
C 1 108013 1/2"-13 1" Nylon Bolt
D 1 108012 1/2"-13 Nylon Wing Nut
E 0.5 101640 1" Solvent Elbow
F 1 101639 1" MNPT Plastic Elbow
G 0.25 102664 1/2"x12-1/2" PVC80 Tube
H 1 100415 Adapter 1/2" TxMNPT
I 2 101365 4" Well Cap
J 1 101275 474 Brine Valve
K 1 102664 1/2" x 12-1/2" Tube
1 102877 4"x36" Brine Well
L
1 102878 4"x46" Brine Well
M 1 101660 Float
N 1 100342 Bushing 3/4"x1/2" SxF PV80
O 1 108565 Bushing 1"x3/4" TxT PV80
Note: MAV bracket can be removed and valve mounted
if desired. Kit # 108469 required.
Description
