Settings

3.8.4 Advanced Scan

The channel search procedure can be performed in different ways. Start
by selecting the satellite to be searched in the Advanced Scan menu.
The TP frequency can be entered manually by using the Number
buttons, or selected from the dropdown list that appears when you
press the OK(
entering TP frequency, symbol rate and polarization, modulation, FEC
and Pilot, move the highlight bar to TP Search and press the OK(
button to start searching channels.
① TP Frequency: Specify the frequency in MHz.
② Symbol Rate: Enter with the Number buttons.
③ Polarization: Select Horizontal or Vertical.
④ Modulation: DVB-S/QPSK, DVB-S2/QPSK or DVB-S2/8PSK.
⑤ FEC: Select FEC(Forward Error Correction) value or leave as Auto.
⑥ Pilot: 0 or 1.

3.8.4.1 PID Edit

Use this in case of a specific Transponder which has non-DVB standard
channels and which can only be found when you have entered the
necessary settings. You can also add or delete channels from a specific
TP.
) button while highlighting the Frequency field. After
)
