⑧ Y/Cb/Cr: Component video output socket for the television set.
(green/blue/red)
⑨ VIDEO: Composite video output socket for the television set.
(yellow)
⑩ AUDIO L/R: Stereo audio output socket for the television set or the
audio system. (white/red)
⑪ ANT IN: Connect with TV RF antenna.
⑫ TV OUT: Connect with RF feed.
⑬ SCART TV: Audio and video output socket for the television set.
⑭ LNB OUT: Satellite broadcasting signal output socket.
⑮ LNB IN: Satellite broadcasting signal input socket.
