Mounting on (Bicycle) Handlebars (optional)

You can attach your navigation system to a bicycle as an optional additional feature. A
special holder is needed to do this. The installation is explained in the following.
1. Release both the screws connecting the clamp to the holding plate with the hexa-
gon key.
2. Remove the rubber ring and wind it around
the handlebars.
3. Position the clamp on your bicycle handle-
bars, by pulling it across the handlebars from
below.
4. Put the holding plate back onto the clamp
and retighten both the screws.
5. Seat the holder for the navigation system on
the holder plate until it locks into place audi-
bly. Please pay attention to the fact that the
holder must only be seated in one direction.
6. Now place the device on the holder. You must pay attention to firm positioning.
Note
Your navigation system could also be equipped with a different bicycle
mounting, where the attachment of mountings can vary slightly, accord-
ing to the version.
86
Holding plate
Clamp
English
Hexagon key
