Summary of Contents for Amprobe IR-450
- Page 1 IR-450 Infrared Thermometer / Laser Pointer / Flashlight Users Manual 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com...
- Page 2 IR-450 Infrared Thermometer / Laser Pointer / Flashlight Users Manual 4240687A ©2012 Amprobe. All rights reserved. Printed in Taiwan...
- Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for one year from the date of purchase, unless local laws require otherwise. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
- Page 4 IR-450 Infrared Thermometer / Laser Pointer / Flashlight 1) Laser 6) Battery cover 2) Flash light 7) Battery indicator 3) Display 8) Laser indicator 4) Flashlight button 5) On button / Test button...
-
Page 5: Table Of Contents
CONTENTS SYMBOLS ................1 UNPACKING AND INSPECTION .......... 2 INTRODUCTION ..............2 OPERATING INSTRUCTIONS ..........3 Power On / Off ............... 3 Auto Power Off .............. 3 Auto Hold ............... 3 Operating The Unit ............3 Taking Temperature Measurement ....... 3 °F / °C Selection .............. -
Page 6: Symbols
SYMBOLS � Caution! Refer to the explanation in this Manual Laser light: Do not stare into laser beam M Battery � Conform to relevant Australian standards � Complies with European Directives Do not dispose of this product as unsorted municipal waste. Contact a qualified recycler Safety Information �... -
Page 7: Unpacking And Inspection
INTRODUCTION A must-have tool for everyday applications, the IR-450 is a 3-in-1 tool that verifies temperature, is used as a laser pointer and illuminates dark work spaces with a bright LED flashlight. -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS Power On / Off Auto Power Off The IR-450 will power down after not being used for 3 minutes. Auto Hold The unit will hold the reading for 10 seconds after the on button is pressed. Operating the Unit To measure temperature, point unit at an object and press the Test button. -
Page 9: F / °C Selection
Make sure that the target is larger than the unit‘s spot size. The smaller the target, the closer you should be to it. The minimum measurement area is 3.75cm (1.5in) diameter. Press the key, and the unit will show the temperature of the target surface. -
Page 10: Reminders
Use the unit at around 30cm to get the best measurement accuracy. At longer distances, the target area shall be larger than the distance divided by 8. Please do not put the fingers on the housing for a long period of time and cross the “B line” to prevent thermo effect interference from measuring accuracy. - Page 11 Allow time for the unit to adapt to the change of ambient temperatures from the user’s pocket to environmental ambient. 2. The unit cannot take measurements through transparent surfaces such as glass. Remove the barrier between the unit and the target surface.
-
Page 12: Emissivity
3. Not recommended for use in measuring shiny or polished metal surfaces (stainless steel, aluminum, etc.). See Emissivity. 4. Steam, dust, smoke, etc., can prevent accurate measurement by obstructing the unit‘s optics Emissivity Most organic materials and painted or oxidized surfaces have an emissivity of 0.95 (pre-set in the unit). -
Page 13: Troubleshooting
Repeatability ±1°C or ±0.5% of reading, whichever is greater. Display Hold 10 s Electrical Internally powered by 1 x AAA 1.5 Supply Alkaline, LR03 battery Weight Approx. 50g (0.11lb) Dimensions 100 x 20 x 29mm (3.94 x 0.79 x 1.14in) (HxWxD) Storage -20°C to 60°C (without battery) -
Page 14: Maintenance And Repair
MAINTENANCE AND REPAIR Lens Cleaning: Blow off loose particles using clean compressed air. Gently brush remaining debris away with a brush. Carefully wipe the surface with a moist cotton swab. The swab may be moistened with water or rubbing alcohol. NOTE: DO NOT use solvents to clean the plastic lens. -
Page 15: Battery Replacement
BATTERY REPLACEMENT Please replace the battery when “Battery indicator” is flashing on display. When battery is replaced / installed, the unit will go into standby mode automatically.
