- Page 1 IR-710 10:1 IR thermometer Users Manual • Mode d’emploi • Bedienungshandbuch • Manual d’Uso • Manual de uso • Användarhandbok...
- Page 3 IR-710 10:1 IR thermometer Users Manual September 2011, Rev.1 ©2011 Amprobe Test Tools. All rights reserved. Printed in China...
- Page 4 Please check the “Where to Buy” section on www.amprobe.com for a list of distributors near you. Additionally, in the United States and Canada In-Warranty repair and replacement units can also be sent to a Amprobe® Test Tools Service Center (see address next page).
- Page 5 Non-Warranty Repairs and Replacement – US and Canada Non-warranty repairs in the United States and Canada should be sent to a Amprobe® Test Tools Service Center. Call Amprobe® Test Tools or inquire at your point of purchase for current repair and replacement rates.
- Page 6 IR-710 10:1 IR thermometer Laser Aperture Trigger Battery Cover Display Hold (After releasing the trigger) Laser Indicator Temperature Unit °C / °F MAX / MIN Temperature Display Backlight Low Battery Indicator Making Measurement (Pulling the trigger)
-
Page 7: Table Of Contents
CONTENTS SYMBOLS ................1 SAFETY INFORMATION ............1 UNPACKING AND INSPECTION .......... 3 FEATURES ................3 HOW THE THERMOMETERS WORK ........3 OPERATING THE THERMOMETER ........4 Temperature Measurement ........... 4 Locating a Hot or Cold Spot .......... 5 Distance and Spot Size ........... 5 Field of View.............. -
Page 8: Symbols
SYMBOLS � Caution ! Refer to the explanation in this Manual. Warning! Laser light. Do not stare into laser beam. °C Celsius. °F Fahrenheit. Battery indication. � Complies with European Directives. Do not dispose of this product as unsorted municipal waste. Contact a qualified recycler. Safety Information The instrument complies with: EN 61010-1 General Safety... - Page 9 X� Warning: Read Before Using • Do not stare into laser beam. • Do not point laser directly at eye or indirectly off reflective surfaces. • For use by competent persons only. • Do not point laser directly at eye or indirectly off reflective surfaces.
-
Page 10: Unpacking And Inspection
FEATURES The Amprobe IR-710, a 10:1 spot to distance ratio infrared thermometer, offers best in class accuracy and response time with a temperature measurement range of 0°F to 716°F or -18°C to 380°C. The IR-710 is specifically designed for HVAC/R, electrical, industrial maintenance, automotive as well as quality control and fire prevention applications. -
Page 11: Operating The Thermometer
OPERATING THE THERMOMETER Temperature Measurement The Thermometer turns on when you press the trigger. The Thermometer turns off when no activity is detected for 8 seconds. To measure temperature, point the thermometer at an object and pull the trigger. You can use the laser pointer to help aim the thermometer. -
Page 12: Locating A Hot Or Cold Spot
Button Description. °C °F Toggle between Celsius and Fahrenheit. Toggle between MAX and MIN options. MAX or MIN reading is displayed on the secondary display. Turn off or on the laser. Turn off or on display backlight. � Laser To avoid injury, do not point the laser directly at eye or indirectly off reflective surfaces. -
Page 13: Distance And Spot Size
Distance and Spot Size As the distance (D) from the target being measured increases, the spot size (S) of the area measured by the instrument becomes larger. The spot size indicates 90% encircled energy. Locating a Hot or Cold Spot Make sure that the target is larger than the spot size. -
Page 14: Emissivity
Emissivity Emissivity describes the energy-emitting characteristics of materials. Most organic materials and painted or oxidized surfaces have an emissivity of about 0.95. If possible, to compensate for inaccurate readings that may result from measuring shiny metal surfaces, cover the surface to be measured with masking tape or flat black paint (<150°C / 302°F ) and use the high emissivity setting. - Page 15 2. The instrument cannot measure through transparent surfaces such as glass. It will measure the surface temperature of the glass instead. 3. Not recommended for use in measuring shiny or polished metal surfaces (stainless steel, aluminum, etc.). See Emissivity. 4. Steam, dust, smoke, etc., can prevent accurate measurement by obstructing the instrument’s optics.
-
Page 16: Specification
SPECIFICATION Function Range 0°F to 716°F Temperature Range -18°C to 380°C -18°C to 10°C (-0.4°F to 50°F): Accuracy With ±2%+1°C (2°F), or ±3°C (±6°F), ambient operating whichever is greater temperature of 21°C >10°C to 380°C (>50°F to 716°F): to 25°C ±2%, or ±2°C (±4°F), (70°F to 77°F) whichever is greater... -
Page 17: Maintenance
Dual LCD Display √ LCD Backlit √ Low Battery √ Indication 9V 6F22 alkaline battery or Power equivalent 10 hours with laser and backlight on Battery Life 30 hours with laser and backlight off Dimension Approx.153 x 108 x 40 mm (H x L x W) (6.0 x 4.3 x 1.6 in) Weight Approx.180 g (0.4 lb) -
Page 18: Trouble Shooting
TROUBLE SHOOTING Code Problem Action Select target Target temperature is within over range specifications Select target Target temperature is within under range specifications Battery Check and/or Low battery indication replace battery Check and/or Blank display Possible dead battery replace battery 1.Replace 1.Low or dead battery Laser doesn’t... -
Page 19: Battery Replacement
BATTERY REPLACEMENT To install or change one 9V battery (see below): 1. Open the handle. 2. Install the battery noting its correct polarity. 3. Close and lock the handle. Battery: 9V 6F22 alkaline battery or equivalent...
