Camera light
Camera lens
Battery (left)
Battery gauge
button (left)
Battery power
indicator lights (left)
Chapter 1
Battery release switch (left)
FlexDock connector Connects to the FlexDock when docked. Remove the cover
(cover shown) before attaching the J3500 to the dock.
Battery power Show the amount of remaining battery power.
indicator lights
Battery Powers the Tablet PC when it is not plugged in or docked.
Battery gauge Press the button to show remaining power on the indicator
button lights.
Battery release Slide to release and remove the battery.
switch
Camera lens Capture images to the hard disk drive.
Camera light Provides light for the integrated camera.
Getting Started
Back
Battery release switch (right)
FlexDock
connector
(cover shown)
Battery power
indicator lights
(right)
Battery (right)
Battery gauge
button (right)
3
