The Control Panel; Use - Zanussi ZTE 280 User Manual

Use

The control panel

1 Programme/Time
selector dial
Allows you to select
electronically
controlled or time
controlled drying.
Turn the dial to the
required
programme or time.
Electronically
controlled drying
(automatic)
The appliance runs
these programmes
with the help of
probes which detect
the degree of
dampness of the
laundry.
Simply select the
programme
according to the
type of laundry and
degree of drying
required.
2 Low temperature
button
Pressing this button
allows drying to be
performed at a
10
lower temperature,
for delicate items.
The corresponding
pilot light comes on.
This option can also
be used for time
controlled drying.
3 Long Anticrease
If this additional
function is selected,
the anti-crease
phase at the end of
the drying cycle is
lengthened by 60
minutes. The
laundry can be
removed at any
time during the anti-
crease phase.
4 Quick drying
button
By depressing this
button the drying
time is reduced in
the following
programmes:
1 2 3 4 5
• Cotton&linen
• Synthetics
The corresponding
light illuminates.
This option cannot
be selected
together with
"low temperature"
function .
5 Buzzer - button
A buzzer sounds
• when selecting
the programme
• when depressing
the buttons
• when an incorrect
option selection is
made
• when the
programme
selector dial is
turned to another
position during
the programme or
when you
depress an option
button during the
8
6 7 10 9
cycle
• at the end of the
programme
• when the water
reservoir is full
• if the machine is
not working
correctly
• when the small
door at the
bottom is open
By depressing
button the
acoustic signal is
switched off.
The corresponding
light comes on.
6 Time button
To select the
programme
duration after
setting the
programme. You
can select a
programme
duration from 20
mins to 2 hrs in 10-
minute steps.
1. Turn the
