EASY START

PRODUCT DESCRIPTION

10
9
8
7
The load door can be installed by the
user in the opposite side. It can help to
easily put and remove the laundry or if
there is a limit to install the appliance
(see separate leaflet).

CONTROL PANEL

1
On / Off button
2
Programme selection touchpad
3
Dryness selection touchpad
6
1 2
3
4
5
6
1 2 3
Water container
1
Control panel
2
Appliance door
3
Primary Filter
4
Bottom cover with the airflow slots
5
WARNING! Do not put any object
on the bottom cover
Buttons to open the bottom cover
6
Adjustable feet
7
Condenser door
8
Locks for condenser door
9
Rating plate
10
4 5 6
4
Options selection touchpad
5
Time touchpad
6
Start/Pause touchpad
9
8
7
