Subwoofer
1 Connect the wire without insulation tube to the SUBWOOFER
minus (-) terminal, and the wire with purple insulation tube to
the SUBWOOFER plus (+) terminal.
Purple
Caution:
Never mistake the FRONT SPEAKERS and the SUBWOOFER
terminals. The unit or the speakers may be damaged.
If you use other speakers with an impedance lower than that
specified, the unit may be damaged. Front speakers: 4 ohms,
Subwoofer: 12 ohms.
Do not mistake the right and the left
channels. The right speaker is the one on the
right side when you face the unit.
Do not let the bare speaker wires touch
each other.
Do not allow any objects to fall into or to be
placed in the bass reflex duct.
Do not stand or sit on the subwoofer/
speakers. You may be injured.
Aerial connection
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS
socket and position the FM aerial wire in the
direction where the strongest signal can be
received.
Note:
Placing the aerial on the unit or near the AC
power lead may cause noise pickup.
Place the aerial away from the unit for better
reception.
External FM aerial
Use an external FM aerial if you require better reception.
Consult your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM
aerial wire.
AC power connection
After checking all the connections have been made correctly, plug
the AC power lead of this unit into the wall socket. If you plug in the
unit first, the unit will enter the stand-by mode.
Incorrect
Note:
FM
Unplug the AC power lead from the wall socket if the unit will not be
aerial
in use for a prolonged period of time.
75 ohms External
coaxial cable
FM aerial
(AC 110 - 127 V ~ 50/60 Hz)
HT-DV40U
HT-DV50U
ENGLISH
Wall socket
E-18
