Smeg HOB Instructions For Use Manual

Hide thumbs Also See for HOB:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instructions for Use Manual, Instruction Manual
1. INSTRUCTIONS FOR USE ................................................................ 4
2. SAFETY PRECAUTIONS ................................................................... 6
3. ENVIRONMENTAL CARE................................................................... 8
4. DESCRIPTION OF THE CONTROLS ................................................ 9
5. USING THE HOB.............................................................................. 10
6. CLEANING AND MAINTENANCE.................................................... 12
7. POSITION NEAR THE COUNTER TOP .......................................... 14
8. ADAPTATION TO DIFFERENT TYPES OF GAS ............................ 20
THESE INSTRUCTIONS ARE VALID ONLY FOR THE DESTINATION COUNTRIES
WHOSE IDENTIFYING SYMBOLS ARE INCLUDED ON THE COVER OF THIS
MANUAL.
THIS IS A CLASS 3 BUILT IN HOB.
INSTRUCTIONS FOR THE USER: these contain user advice, the description
of the controls and the correct procedures for cleaning and maintenance of
the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
authorized person who must install the appliance, set it functioning and
carry out an inspection test.
@
Further information about the products can be found at www.smeg.com
Contents
3

Advertisement

Table of Contents
loading

Related Manuals for Smeg HOB

Summary of Contents for Smeg HOB

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR THE INSTALLER: these are intended for the authorized person who must install the appliance, set it functioning and carry out an inspection test. Further information about the products can be found at www.smeg.com...

  • Page 2: Instructions For Use

    General instructions 1. INSTRUCTIONS FOR USE This manual is an integral part of the appliance. It must be kept in its entirety and in an accessible place for the whole working life of the appliance. We recommend reading this manual and all information it contains carefully before using the appliance.

  • Page 3: General Instructions

    General instructions Never place pans with bottoms which are not perfectly flat and smooth on the cooking hob pan stands. Never use pans or griddle plates which project beyond the outside edge of the hob. Suitable heat-proof gloves should be worn for all operations.

  • Page 4: Safety Precautions

    General instructions 2. SAFETY PRECAUTIONS Refer to the installation instructions for the safety regulations for electric or gas appliances and ventilation functions. In your interests and for your safety the law requires that the installation and servicing of all electrical and gas appliances is carried out by qualified personnel in accordance with the regulations in force.
  • Page 5 General instructions This appliance may be used by children from the age of 8 and by people of reduced physical and mental ability or lacking in experience and knowledge, provided they are supervised or instructed on the safe use of the appliance and if they understand the associated risks.

  • Page 6: Environmental Care

    Instructions for disposal 3. ENVIRONMENTAL CARE Our products packing is made of non-polluting materials, which are therefore compatible with the environment and recyclable. Please help by disposing of the packaging correctly. You can obtain the addresses of collection, recycling and disposal centres from your retailer or from the competent local organisations.

  • Page 7: Description Of The Controls

    Instructions for the user 4. DESCRIPTION OF THE CONTROLS Auxiliary Burner (AUX) Rapid Burner (R) Double crown Burner (UR2) KNOB DESCRIPTION To light the flame, press the knob and, at the same time, turn it anticlockwise to the maximum flame symbol To adjust the flame, turn the knob to the zone between the maximum ( ) and minimum (...

  • Page 8: Using The Hob

    Instructions for the user 5. USING THE HOB Before lighting the hob burners, check that the flame-spreader crowns are correctly in place with their respective burner caps, making sure that the holes A in the flame-spreaders are aligned with the igniters and thermocouples.
  • Page 9 Take the greatest care when using fats or oils since they may catch fire if overheated. To prevent burns or damage to the hob or the counter top during cooking, all pans or griddles must be placed inside the perimeter of the hob.

  • Page 10: Cleaning And Maintenance

    Instructions for the user 6. CLEANING AND MAINTENANCE Before performing any operations requiring access to powered parts, disconnect the appliance from the power supply. NEVER USE A JET OF STEAM TO CLEAN THE APPLIANCE. WARNING: For your safety, you are advised to wear protective gloves while performing any cleaning or extraordinary maintenance.
  • Page 11 Remove the pan stands and clean them with lukewarm water and non-abrasive detergent, making sure to remove any encrustations. Replace them on the cooking hob. These components must not be washed in the dishwasher. 6.2.3 Burner caps and flame-spreader crowns The burner caps and flame-spreader crowns can be removed for easier cleaning.

  • Page 12: Position Near The Counter Top

    Make sure that there is a minimum distance of 750 mm between the stoves of the hob and any shelf that may be installed directly above it. If a hood is installed above the hob, refer to the hood instruction manual to ensure the correct clearance is left.
  • Page 13 IMPORTANT: if the appliance is mounted on a unit, make sure that a separating shelf is installed, as shown in the figure. However, if the appliance is on an oven installed under the hob, there is no need to install a separating shelf.

  • Page 14: Clearances Above And Around Domestic Appliances

    Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions. However, in no case shall the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm.
  • Page 15 Make sure that the supply line is suitably earthed. Fit power line with an omnipolar circuit breaker with a contact opening gap equal to or greater than 3 mm in an easily accessible position close to the hob. Avoid the use of adapters and shunts.
  • Page 16 Instructions for the installer Gas connection This appliance is suitable for installation with Natural Gas or ULPG (propane/butane). Refer to page 26 for the relevant burner pressure and appropriate injector sizes. When the appliance is to be connected to Natural Gas then the pressure regulator supplied must be fitted to the gas inlet.
  • Page 17 Room ventilation Caution – Caution – This hob may only be installed and operated in rooms permanently ventilated in accordance with current regulations. For proper operation of a gas appliance it is essential for the air necessary for combustion of the gas to be able to flow naturally into the room.

  • Page 18: Adaptation To Different Types Of Gas

    To change the nozzles, proceed as described in the following paragraphs. Replacement of nozzles on the hob 7 Extract the pan stands and remove all caps and flame-spreader crowns; 8 Unscrew the burner nozzles with a 7 mm socket wrench;...
  • Page 19 Instructions for the installer Burner and nozzle characteristics table Burner NG – 1.0 kPa Nominal gas Injector Consumption (MJ/h) (mm) Auxiliary (1) 0.90 Rapid (2) 1.40 INT Double crown (3) 0.90 EXT Double crown (3) 14.4 1.75 Burner ULPG – 2.75 kPa Nominal gas Injector Consumption (MJ/h)
  • Page 20 This label can be obtained from the nearest Authorised Service Centre or supplied where envisaged. Arrangement of the burners on the hob HOB BURNERS 1 Auxiliary 2 Rapid...
