Smeg Hob Instructions For The User

Smeg Hob Instructions For The User

Hide thumbs Also See for Hob:
Table of Contents

Advertisement

Quick Links

See also: Instructions for Use Manual , Instructions for the User
1. INSTRUCTIONS FOR USE ................................................................................................... 28
2. INSTRUCTIONS FOR DISPOSAL ........................................................................................ 30
3. INSTALLING THE APPLIANCE ............................................................................................ 31
4. ADAPTATION TO DIFFERENT TYPES OF GAS ................................................................. 34
5. FINAL OPERATIONS ............................................................................................................ 36
6. THE CONTROL PANEL ........................................................................................................ 37
7. USING THE COOKING HOB ................................................................................................ 39
8. USING THE OVEN ................................................................................................................ 40
9. ELECTRONIC PROGRAMMER ........................................................................................... 44
10. AVAILABLE ACCESSORIES .............................................................................................. 46
11. CLEANING AND MAINTENANCE ....................................................................................... 47
12. EXTRAORDINARY MAINTENANCE ................................................................................... 50
INSTRUCTIONS FOR THE USER: these contain user advice, description of the commands and the
correct procedures for cleaning and maintenance of the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified technician who must
carry out an adequate inspection of the gas system, install the appliance, set it functioning and test it.
@
Further product information is available from the website www.smeg.com
Contents
27

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hob and is the answer not in the manual?

Questions and answers

Related Manuals for Smeg Hob

Summary of Contents for Smeg Hob

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified technician who must carry out an adequate inspection of the gas system, install the appliance, set it functioning and test it. Further product information is available from the website www.smeg.com...

  • Page 2: Instructions For Use

    THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE IT MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE HOB. WE ADVISE YOU TO READ THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN CAREFULLY BEFORE USING THE HOB.
  • Page 3 VANS, CARAVANS ETC.) THEY MUST ONLY BE USED WHEN THE VEHICLE IS STOPPED. INSTALL THE PRODUCT SO THAT WHEN OPENING THE DRAWERS AND DOORS OF UNITS POSITIONED AT THE LEVEL OF THE COOKING HOB THERE IS NO POSSIBILITY OF MAKING CONTACT WITH PANS POSITIONED ON TOP OF IT.

  • Page 4: Instructions For Disposal

    The environment – Instructions for disposal 2. INSTRUCTIONS FOR DISPOSAL 2.1 Our environmental responsibility Pursuant to Directives 2002/95/EC, 2002/96/EC and 2003/108/EC relating to the reduction of the use of hazardous substances in electrical and electronic appliances, as well as to the disposal of refuse. The crossed out bin symbol on the appliance indicates that the product, at the end of its useful life, must be collected separately from other refuse.

  • Page 5: Installing The Appliance

    Instructions for the installer 3. INSTALLING THE APPLIANCE The appliance must be installed by a qualified technician and according to the regulations in force. Depending on the type of installation, it belongs to class 1 (Fig. A) or to class 2, subclass 1 (Fig. B-C). This appliance may be installed next to walls, one of which must be higher than the appliance, at a minimum distance of 50 mm from the side of the appliance, as shown in drawings A and B relative to the installation classes.

  • Page 6: Electrical Connection

    Instructions for the installer 3.1 Electrical connection Make sure the voltage and the cross-section of the power supply line match the specifications indicated on the identification plate positioned in the storage compartment. Do not remove this plate for any reason. If the appliance is connected to the power supply network by means of a fixed connection, install a multipolar cut-out device on the power supply line, with a contact opening distance equal to or greater than 3 mm, located near the appliance and in an easily reachable position.
  • Page 7 Instructions for the installer CONNECTION USING RUBBER HOSES COMPLYING WITH THE CURRENT REGULATIONS IS ONLY PERMITTED IF THE HOSE CAN BE INSPECTED ALONG ITS ENTIRE LENGTH. THE TIGHTENING TORQUE BETWEEN CONNECTIONS THAT INCORPORATE A GASKET MUST NOT EXCEED 10NM 3.4.2 Connection to natural and city gas Make the connection to the gas mains using a rubber hose whose specifications comply with the current regulations (verify that the reference standard is stamped on the hose).

  • Page 8: Adaptation To Different Types Of Gas

    To change the nozzles, proceed as described in the following paragraphs. 4.1 Replacement of the cooking hob nozzles 1 Extract the pan racks and remove all the caps and flame-spreader crowns;...
  • Page 9 NATURAL GAS – G20 20 mbar (kW) Nozzle Rated diameter capacity 1/100 mm Auxiliary 1.05 72 (X) Semi-rapid 97 (Z) Ultra-rapid 135 (K) 1500 4.3 Arrangement of the burners on the hob BURNERS 1. Auxiliary 2. Semi-rapid 4. Ultra-rapid...

  • Page 10: Final Operations

    The label is inserted inside the pack together with the nozzles. 5.1 Regulation of the hob burner minimum for natural gas Light the burner and turn it to the minimum position .

  • Page 11: The Control Panel

    FRONT LEFT-HAND BURNER FRONT RIGHT-HAND BURNER REAR LEFT-HAND BURNER HOB BURNERS CONTROL KNOB To light the flame, press the knob and turn it anticlockwise to the minimum flame symbol . To adjust the flame, turn the knob to the zone between the maximum ) and minimum ( ) settings.
  • Page 12 Instructions for the user ELECTRIC OVEN FUNCTIONS KNOB The electric oven’s various functions are suitable for different cooking modes. After selecting the desired function, set the cooking temperature using the thermostat knob. STATIC OVEN FUNCTION LARGE FAN-ASSISTED GRILL FUNCTION WIDE GRILL FUNCTION VENTILATED LOWER HEATING...

  • Page 13: Using The Cooking Hob

    Once the contents come to the boil, turn down the flame far enough to ensure that the liquid does not boil over. To prevent burns or damage to the hob during cooking, all pans or griddles must be placed inside the perimeter of the hob. All pans must have smooth, flat bottoms. Take the greatest care when using fats or oils since they may catch fire if overheated.

  • Page 14: Using The Oven

    Instructions for the user 8. USING THE OVEN 8.1 Warnings and general advice In models with an electronic programmer, before using the oven make sure that is on the display. When using the oven and the various heating elements for the first time, they should be heated to the maximum temperature (260°C) for long enough to burn off any oily residues left by the manufacturing process, which might contaminate foods with unpleasant smells.
  • Page 15 Instructions for the user 8.3.1 Using the rotisserie Both the static grill and the fan-assisted grill make it possible to perform cooking processes in combination with the rotisserie. Insert the rotisserie rod into the rotisserie bushing, select the grill function and position the thermostat knob on the desired temperature (in any case no more than 200°C).
  • Page 16 Instructions for the user 8.4 Storage compartment (on some models only) The storage compartment is in the bottom of the cooker, underneath the oven. To open it, pull on the top of the door. Never use it to store flammable materials such as rags, paper, etc.; it is intended for storing the appliance’s metal accessories only.
  • Page 17 Instructions for the user 8.5 Description of the selectable functions STATIC: As the heat comes from above and below at the same time, this system is particularly suitable for certain types of food. Traditional cooking, also known as static or thermal radiation cooking, is suitable for cooking just one dish at a time.

  • Page 18: Electronic Programmer

    Instructions for the user 9. ELECTRONIC PROGRAMMER LIST OF FUNCTIONS TIMER BUTTON COOKING DURATION BUTTON END OF COOKING BUTTON VALUE DECREASE BUTTON VALUE INCREASE BUTTON 9.1 Setting the time When the oven is used for the first time, or after an interruption in the electricity supply, the display flashes at regular intervals, showing .
  • Page 19 Instructions for the user After the setting, to view the cooking time left press the key; to view the cooking end time press the key. The logic prevents the setting of incompatible values (e.g. the programmer will not accept a cooking end time with a duration which is too long for this value).

  • Page 20: Available Accessories

    Instructions for the user 10.AVAILABLE ACCESSORIES The oven features 4 runners for positioning trays and racks at different heights. Oven rack: for cooking food inside dishes, small cakes, roasts or foods that require slight grilling. Tray rack: for placing on top of a tray for cooking foods which may drip.

  • Page 21: Cleaning And Maintenance

    Remove the racks and clean them with lukewarm water and non-abrasive detergent, making sure to remove any encrustations. Replace them on the cooking hob. Continuous contact between the racks and the flame can cause modifications to the enamel over time in those parts exposed to heat.
  • Page 22 During the pyrolysis cycle, a door locking device makes it impossible to open the door. If the oven is installed under a hob, make sure that the burners or electric hotplates on the hob remain switched off during the automatic cleaning cycle.
  • Page 23 Warning: never leave anything in the oven during the pyrolysis cycle. Keep children at a distance. Pay close attention especially when the start of the cycle is delayed with respect to the current time. During the pyrolysis cycle the hob must not be used.

  • Page 24: Extraordinary Maintenance

    Instructions for the user 12.EXTRAORDINARY MAINTENANCE The oven may require extraordinary maintenance or replacement of parts subject to wear such as gaskets, bulbs, etc. The following instructions describe how to carry out these minor maintenance operations. Before any intervention that requires access to live parts, disconnect the appliance from the power supply.
