Oven And Accessories - Sharp R-61FBST Operation Manual With Cookbook

R-61+62FBST English 22/07/2003

OVEN AND ACCESSORIES

9
1 Grill heating element
2 Front trim
3 Oven lamp
4 Control panel
5 Waveguide cover
6 Oven cavity
7 Seal packing
8 Door seals and sealing surfaces
9 Door opening handle
10 Fixing points (4 points)
11 Ventilation openings
12 Outer cover
13 Rear cabinet
14 Power supply cord support clips
15 Power supply cord
ACCESSORIES:
Check to make sure the following accessories are
provided:
(16) Turntable (17) Roller stay (18) Rack
(19) 4 fixing screws (not shown)
Place the roller stay in the seal packing on the floor of
the cavity.
Then place the turntable on the roller stay.
To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
12:48 Page 2
1
8 7 6
15
14
2
2
3
4
5
10
16
17
18
11
12
13
