Upgrading The Firmware - Polycom KWS600v3 Installation And Configuration Manual

Under the Configuration menu, select ETH0 and then select IP.
In the IP Address field, enter the new IP address.
In the Network mask field, enter the network mask.
In the Default gateway field, enter the IP address of the default gateway on your
network.
Select OK.
Select Reset (under the Administration menu) to save your configuration.
Connect the device to your network via the ETH0 port.
5.
Change your computer's IP address parameters back to their original values.
6.

Upgrading the Firmware

Refer to UC Server Interoperable SIP Device Features and Comparisons technical note, available at
http://kb.adtran.com, to determine the most recently supported version of firmware for the device.
Performing firmware upgrades
1. Retrieve the firmware and radio update files from the Polycom website. You will need to
download the Asterisk version. Refer to
http://www.polycom.com/support/voice/dect/dect_ws_600v3.html.
2. Open your browser and enter the IP address of the KWS600v3.
3. When prompted, use the following default Web access username and password:
Web Access Username: admin
Web Access Password:
4. Under the Administration menu, select Upload.
5. Select Radio.
6. Select Browse. A dialog box will appear to prompt you for the radio update file.
7. Select the firmware file and then select Open.
8. Select Send File.
9. Wait for the system to finish updating.
10. Under the Administration menu, select Upload and Firmware.
11. Select Browse. A dialog box will appear to prompt you for the firmware file.
12. Select the firmware file and then select Open.
ip1200
4
