- Page 1 USB 2.0 Internal Multi-Card Reader User’s Manual P/N TS0MFLRD8B/8E...
-
Page 2: Table Of Contents
Table of Contents Introduction Package Contents......................1 Features..........................1 System Requirements .......................1 Driver Installation Driver Installation for Windows 98SE and 2000 ..............2 Driver Installation for Windows Me, XP and Linux… ............4 Hardware Setup ......................4 To Use the Internal Multi-Card Reader To Use with Windows 98SE and 2000 ................6 To Use with Windows Me and XP ..................7 To Use with Linux Kernel 2.4 or Later................7 To Safely Remove Memory Cards... -
Page 3: Package Contents
Introduction Thank you for purchasing Transcend’s Internal Multi-Card Reader, designed for fast, easy data exchange using multiple types of storage media: Your Internal Multi-Card Reader supports: CompactFlash Type I/II, Microdrive™, SmartMedia, Secure Digital, miniSD (with adapter), Mul- ® ® ®... -
Page 4: Driver Installation
Driver Installation Driver Installation for Windows 98SE and 2000 1. Power on the computer where you will install the Internal Multi-Card Reader and make sure the USB port is enabled and working properly. Do not plug your Internal Multi-Card Reader into the USB port at this time. 2. - Page 5 5. Select the Next button to complete the driver installation. If using Windows 98SE or 2000, the system will ask you to restart your computer. Please do not restart your computer at this time. Cancel the Yes, restart my computer now option and select the Finish button.
-
Page 6: Driver Installation For Windows Me, Xp And Linux
6. Shutdown the computer and refer to the Hardware Setup below to set up the Internal Multi-Card Reader. Driver Installation for Windows Me, XP and Linux No driver is needed. Turn off the computer and refer to Hardware Setup below to install the In- ternal Multi-Card Reader into your PC. - Page 7 Plug the USB connecter with the red wire seated in Pin 1 or Pin 6. 5. If the layout of USB pin-header does not match the default setting of the USB connector (shown above in Step 3), please rearrange the color of the wires of the USB cable as follows: Use a needle to raise the small plastic tab and pull the wires out of the connector.
-
Page 8: To Use The Internal Multi-Card Reader
Wire Pin Assignment Vcc / Power / +5V White P-, Data- Green P+, Data+ Black Thick Black Not Connect / Shield Ground Be careful in realigning the color wires. Any error here will cause serious damage to the Internal Multi-Card Reader. Keep the same side of the wire pins facing up and insert them back into the connector. -
Page 9: To Use With Windows Me And Xp
2. Four Removable Disk drives with newly assigned drive letters will appear in My Computer. The Internal Multi-Card Reader is ready for use. To Use with Windows Me and XP 1. Power on the computer. The Found New Hardware status message will appear (the first time you power on the computer after installing the Internal Multi-Card Reader). -
Page 10: To Safely Remove Memory Cards
Example: mkdir /mnt/CardReader Mount the Internal Multi-Card Reader. Example: mount –a –t msdos /dev/sda1 /mnt/CardReader No matter how many memory cards are inserted into the Internal Multi-Card Reader, only the memory card that was first inserted can be mounted. To Safely Remove Memory Cards To Remove in Windows Make sure that the LED is not blinking (no data is being transmitted). -
Page 11: Specifications
Specifications Power Supply ..........DC 5V from USB port Slots for Storage Media:......CompactFlash Card Type I/II Microdrive SmartMedia Card Secure Digital Card miniSD (with adapter) MultiMediaCard RS-MMC (with adapter) Memory Stick Memory Stick PRO Memory Stick Duo (with adapter) Memory Stick PRO Duo (with adapter) Operating Temperature ....... -
Page 12: Card Reader Limited Warranty
This warranty is subject to the conditions and limitations set forth herein. Duration of Warranty: Transcend Card Readers are covered by this warranty for a period of two (2) years from the date of purchase. Transcend will inspect the product and make the determination as to whether the product is eligible for repair or replacement.
