Transcend TS0MFLRD6E User Manual

Transcend TS0MFLRD6E User Manual

Usb 2.0 internal 6-in-1 card reader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USB 2.0
Internal 6-in-1
Card Reader
User's Manual
P/N TS0MFLRD6E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS0MFLRD6E and is the answer not in the manual?

Questions and answers

Related Manuals for Transcend TS0MFLRD6E

Summary of Contents for Transcend TS0MFLRD6E

  • Page 1 USB 2.0 Internal 6-in-1 Card Reader User’s Manual P/N TS0MFLRD6E...

  • Page 2: Table Of Contents

    Table of Contents Introduction Package Contents... 1 Features ... 1 System Requirements ... 1 Driver Installation Driver Installation for Windows 98SE, Me, and 2000 ... 2 Driver Installation for Windows XP, Linux Kernel 2.4 or Later…... 4 Hardware Setup ... 4 To Use the Internal 6-in-1 Card Reader To Use with Windows 98SE, Me, and 2000...

  • Page 3: Package Contents

    Thank you for purchasing Transcend’s Internal 6-in-1 Card Reader, a small device de- signed for fast, easy data exchange using six types of storage media: CompactFlash, IBM Microdrive™, SmartMedia, Secure Digital, MultiMediaCard™, and Memory Stick Designed to fit in any 3.5” drive, Transcend’s Internal 6-in-1 Card Reader is easy to install in your computer.

  • Page 4: Driver Installation

    Driver Installation for Windows 98SE, Me, and 2000 1. Power on the computer where you will install the Internal 6-in-1 Card Reader and make sure the USB port is enabled and working properly. NOTE: Do not plug your Internal 6-in-1 Card Reader into the USB port at this time. 2.
  • Page 5 4. The InstallShield Wizard appears. Click Next. 5. Click Finish to complete the driver installation. If using Windows 98SE or Me, the system will ask you to restart Windows. Select the No, I will restart my computer later radio button and click OK. 6.

  • Page 6: Driver Installation For Windows Xp, Linux Kernel 2.4 Or Later

    Driver Installation for Windows XP, Linux Kernel 2.4 or Later No driver is needed. Turn off the computer and refer to Hardware Setup below to install the Internal 6-in-1 Card Reader into your PC. 1. Install the Internal 6-in-1 Card Reader into an available 3.5” drive bay. 2.
  • Page 7 Plug the USB connecter with the red wire seated in pin 1 or pin 6. 5. If the layout of USB pin-header does not match the default setting of USB connector (shown above), rearrange the color wires of the USB cable as follows: a.

  • Page 8: To Use The Internal 6-In-1 Card Reader

    b. Refer to the pin assignment of USB connector (as below) and to realign the color wires. WARNING: Be careful in realigning the color wires. Any error here will cause serious damage to the Internal 6-in-1 Card Reader. c. Keep the same side of wire pins facing up and insert them back into the con- nector.

  • Page 9: To Use With Windows Xp

    2. Four Removable Disk drives with newly assigned drive letters appear in My Com- puter. The Internal 6-in-1 Card Reader is ready for use. To Use with Windows XP 1. Power on the computer. The first time you power on the computer after installing the Internal 6-in-1 Card Read- er.) 2.

  • Page 10: To Use With Linux Kernel 2.4 Or Later

    To Use with Linux Kernel 2.4 or Later The Internal 6-in-1 Card Reader is a driver-free device for Linux kernel 2.4 or later. Just follow the procedures below to mount and use it. 1. Power on the computer and insert a memory card into the Internal 6-in-1 Card Reader.

  • Page 11: Boot-Up Function

    The CompactFlash slot of the Internal 6-in-1 Card Reader can be configured as a bootable drive. To enable the Boot-Up function, your motherboard must support USB boot-up de- vices. Upon completion of the appropriate procedure for your BIOS as described below, a CompactFlash card can be used to boot up your computer.

  • Page 12: To Boot-Up With Ami Bios

    To Boot-up with AMI BIOS 1. Power on your system and follow the on-screen instructions to enter BIOS or the CMOS setup utility. 2. Refer to the owner’s manual of your motherboard for details about the configuration program for your system. 3.
  • Page 13 6. Select Boot Device Select. 7. Select USB RMD-FDD Generic STORAGE DEVICE for the 1st Boot Device, then press ESC. 8. Choose Save & Exit Setup to save the new configuration to CMOS and exit the CMOS Setup program. At SAVE to CMOS and EXIT (Y/N)? Type Y and press Enter.

  • Page 14: Specifications

    Specifications Power supply... DC 5V from USB port Slots for storage media: ... CompactFlash Card Type I/II Operating Temperature ... 0°C–40°C Storage Temperature... -10°C–60°C Humidity ... 0%–90% RH Emission/Safety ... FCC Class B, CE, BSMI Dimensions ... 154mm x 102mm x 26mm Weight ...

  • Page 15: Card Reader Limited Warranty

    We consistently position ourselves to be significantly above the industry norm. It’s all part of our commitment to Customer Satisfaction. All Transcend Information, Inc. (Transcend) products are warranted and tested to be free from defects in material and workmanship and to conform to the published specifications.
