Summary of Contents for Transcend TS0MFLRD6A
- Page 1 6-in-1 Card Reader User’s Manual P/N TS0MFLRD6A...
-
Page 2: Table Of Contents
Table of Contents Introduction Package Contents........................ 1 Features ..........................1 System Requirements ......................2 Driver Installation Driver Installation for Windows 98/98SE and 2000 ............2 Driver Installation for Mac OS 9.x..................3 To Use the 6-in-1 Card Reader To Use with Windows 98/98SE and 2000................3 To Use with Windows Me and XP .................. -
Page 3: Package Contents
Introduction Thank you for purchasing Transcend’s 6-in-1 Card Reader, a small device designed for fast, easy data storage and exchange using six types of memory cards: CompactFlash, IBM Mi- ® crodrive™, SmartMedia, Secure Digital, MultiMediaCard™, and Memory Stick / Memory Stick PRO. -
Page 4: System Requirements
System Requirements • Desktop or notebook computer with a USB port • One of the following operating systems: ® ® - Windows 98/98SE, Windows 2000 ® ® - Windows Me, Windows XP (no driver needed) - Mac™ OS 9.x - Mac™ OS X 10.1.2 or later (no driver needed) - Linux kernel 2.4 or later (no driver needed) Driver Installation Driver Installation for Windows 98/98SE and 2000... -
Page 5: Driver Installation For Mac Os 9.X
the process. Driver Installation for Mac OS 9.x 1. Power on the computer to which you will connect the 6-in-1 Card Reader and make sure the USB port is enabled and working properly. (Do not plug your 6-in-1 Card Reader into the USB port at this time). -
Page 6: To Use With Windows Me And Xp
4. Four Removable Disk drives with newly assigned drive letters appear in My Computer. The 6-in-1 Card Reader is ready for use. To safely remove the memory card, you must make sure that no LED is blinking (no data are being transmitted). WARNING: Never remove or insert a memory card or disconnect the USB cable while data are being transmitted. - Page 7 Four Removable Disk drives with newly assigned drive letters appear in My Computer. The 6-in-1 Card Reader is ready for use. To safely remove the memory card, you must make sure that no LED is blinking (no data are being transmitted). WARNING: Never remove or insert a memory card or disconnect the USB cable while data are being transmitted.
-
Page 8: To Use With Mac Os 9.X
To Use with Mac OS 9.x 1. Complete the driver installation. 2. Connect the 6-in-1 Card Reader to an available USB port via the USB extension cable. 3. Insert a memory card into the 6-in-1 Card Reader. A disk icon appears on the desktop. You can then use the memory card as if it were a Mac HardDisk. -
Page 9: To Safely Remove The 6-In-1 Card Reader
Example: mount –a –t msdos /dev/sda1 /mnt/CardReader Mapping of Disks: SmartMedia /dev/sda MS/MS PRO /dev/sdb SD/MMC /dev/sdc CF/Microdrive /dev/sdd To safely remove the memory card, un-mount the device from the Linux environment. Example: umount /mnt/CardReader WARNING: Never remove or insert a memory card or disconnect the USB cable while data are being transmitted. -
Page 10: To Remove In Mac Os And Linux
If you attempt to remove the 6-in-1 Card Reader without following the above steps, the Unsafe Removal of Device message (in Windows 2000) appears. To Remove in Mac OS and Linux When there is no memory card in the 6-in-1 Card Reader, you can disconnect the device from the USB port at any time. -
Page 11: Led Indicators
LED Indicators LED #5 LED #4 LED #3 LED #2 LED #1 MS/ MS PRO CF/Microdrive SD/MMC SmartMedia Power LED #1 Red: Power On LED #2 Green: SmartMedia card inserted Blinking: Data traffic on SmartMedia card LED #3 Green: Secure Digital or MultiMediaCard inserted Blinking: Data traffic on Secure Digital or MultiMediaCard LED #4... -
Page 12: Specifications
Specifications Power Supply ·············································· DC 5V from USB port Slots for memory cards································ CompactFlash Card Type I / II IBM Microdrive SmartMedia Card Secure Digital Card MultiMediaCard Memory Stick / Memory Stick PRO LED Indicators············································· 5 sets ° ° Operating Temperature································ 0 C –... -
Page 13: Usb Card Reader Limited Warranty
Transcend is also not responsible for damage or failure of any third party equipment, even if Transcend has been advised of the possibility. This limitation does not apply to the extent that it is illegal or unenforceable under applicable law.
