Strong STR 8106 User Manual

Digital terrestrial hd receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Digital Terrestrial HD Receiver SRT 8106

User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STR 8106 and is the answer not in the manual?

Questions and answers

Related Manuals for Strong STR 8106

Summary of Contents for Strong STR 8106

  • Page 1: User Manual

    Digital Terrestrial HD Receiver SRT 8106 User manual...

  • Page 4: Table Of Contents

    7.5 Games 7.6 Media+ 8.0 TRoUblESHooTIng 9.0 TECHnICAl SPECIfICATIonS STRong declares that this item complies with the basic requirements and other relevant regulations of directives 2004/108/EC and 73/23/EC, RoHS 2002/95/EC Subject to alterations. In consequence of continuous research and development technical specifications, design and appearance of products may change.

  • Page 5: Introduction

    PART 1 • English 1.0 InTRoDUCTIon 1.1 Safety Instructions Do noT InSTAll YoUR RECEIvER: In a closed or poorly ventilated cabinet; directly on top of or under any other „ „ equipment; on a surface which might obstruct the ventilation slots. Do noT EXPoSE THE RECEIvER oR ITS ACCESSoRIES: To direct sunlight or any other equipment that generates heat;...

  • Page 6: Equipment Set-Up

    „ „ the receiver. Always make backups of data on your USB storage device before using it with this receiver. STRONG will not take responsibility for any loss of information or circumstances caused by loss of information. 2.0 YoUR RECEIvER 2.1 PIn-CoDE DEfAUlT: 0000...

  • Page 7: Rear Panel

    PART 1 • English 3. pq (CHAnnEl UP/DoWn) Change channel to previous/next 4. moDE InDICAToR: RED indicates that the receiver is in STAND-BY mode. gREEn indicates that the receiver is in OPERATING mode. 5. 4 DIgITS DISPlAY: Indicates current time in STAND-BY mode Indicates current channel number in OPERATING mode 6.

  • Page 8: Connection

    PART 1 • English 14. 0~9 Channel selection or value input 15. EPg Shows the EPG (Electronic Programme Guide) in TV mode 16. RECAll Back to previous shown channel 17. AUDIo Sets the current audio channel to left, right or stereo 18.

  • Page 9: Connecting To A Digital Audio Amplifier And Tv Using Hdmi

    For proper functioning of Time Shift and recording functions, a fast USB device (such as a hard disk drive) is needed. Interrupted playback or a distorted picture during playback or Time Shift are indications for a low device speed. STRONG cannot guarantee proper functioning of recoding and or Time Shift functions with all USB devices.

  • Page 10: Quick Guide To Using Your Receiver

    5.0 QUICk gUIDE To USIng YoUR RECEIvER We at STRONG understand that you can’t wait to enjoy your new high definition digital terrestrial receiver. The following quick guide will make you familiar with the basic operation of this device. We do, however, advice you to read the full manual to get the best performance from your receiver.

  • Page 11: Changing Channels

    PART 1 • English 6.1 Changing channels Your new receiver is equipped with four ways to change channels. Via direct access using the 0~9 buttons. „ „ Via the channel list trough ok button. „ „ Via the Pg+ and Pg- keys. „...

  • Page 12: Subtitles

    PART 1 • English 6.5 Subtitles Some channels support a choice of subtitle languages. Press SUbTITlE in viewing mode to display a list of available subtitle languages. Select your subtitle of choice with pq and press ok to confirm. Press EXIT to leave without making changes. 6.6 Time Shift Time Shift allows you to pause live broadcasts and resume playback later.

  • Page 13: Tv Channel List

    PART 1 • English 7.1.1 Tv Channel list In Edit Channel menu select TV Channel List with pq and press ok to enter. Use tu to change the channel group (assumed you have already set up favourite groups). Select the desired channel with pq. Press ok to view the selected channel in the preview box. 7.1.2 Adding channels to favourite lists Channels from the TV Channel List can be added to up to 8 different favourite groups.

  • Page 14: Installation

    PART 1 • English Sort Press RED to enter the Sort menu. Use pq to select the desired sorting method and press ok to confirm. Possible methods are: Name (A-Z): Sorting in alphabetical order from A to Z. Name (Z-A): Sorting in alphabetical order from Z to A.

  • Page 15: System Setup

    PART 1 • English 7.2.2 Channel Scan Use pq to select Installation, press ok or u to advance. Use pq to select Channel Scan and press ok to enter. Use tu to toggle between available scan modes: By Channel and By Frequency. If By Channel is selected, use the cursor buttons to select Scan Band and Channel No.

  • Page 16: Local Time Setting

    PART 1 • English 7.3.2 Tv System Use this menu to match your receiver to your TV set. The following settings are available: Video Resolution: Toggles between 576i up to 1080p. Please use a setting that matches your TV’s specifications. After a selection is made, you will be asked to confirm. Note: Selection is only applicable on HDMI.

  • Page 17: Tools

    PART 1 • English Wakeup Date: Use the 0~9 buttons to input the date for the timed event. Wakeup Time: Use the 0~9 buttons to input the desired start time. Duration: Use the 0~9 buttons to input the timer duration. Once all settings are according to your wishes, use pq to move the highlight to Save and press ok to confirm.

  • Page 18: Receiver Information

    This receiver is equipped with an Over The Air software upgrade option. An Over The Air update might not be available in your region. Please visit our website www.strong.tv or contact your local service hotline for more information about this option.

  • Page 19: Games

    PART 1 • English 7.4.5 Remove USb device safely Select Remove USB device safely from the tools menu and press ok. The receiver will display a message indicating that you can safely remove your storage device from the receiver. noTE: After performing this function, the USB device is no longer accessible from your receiver.

  • Page 20: Dvr Hdd Information

    Formatting will permanently delete ALL data stored on the connected device. Please make a backup copy of all data you wish to keep before entering the HDD Format menu. STRONG cannot be held responsible for loss of data from USB devices used with this receiver.

  • Page 21: Troubleshooting

    Replace remote batteries Forgotten PIN code Default PIN is 0000 Contact local Service Hotline or send email to our Support via www.strong.tv After moving the receiver Antenna signals are too weak Press the Info button on to another room/area you...

  • Page 22: Technical Specifications

    Audio playback – MP3 and FLAC formats* Picture view – JPEG format* *STRONG cannot guarantee the playback of video files although extensions are listed, as it depends on codec used, data bit rate and resolution (all MPEG codec formats are supported).
  • Page 23 PART 1 • English Connectors ANT IN - IEC Female TO TV - IEC Male TV SCART (RGB, CVBS, Audio L&R) HDMI 1.3 MODULATOR – IEC Male S / PDIF: coaxial output Cinch Cinch (Audio L&R and Video CVBS) USB 2.0 port: 5 V/800 mA (max.) supported general Data Supply Voltage:...
