UBI EasyCoder 201 II – User's Manual
PAPER LOAD, cont'd.

External Supply

Note!
When an external paper supply is
used, take precautions to protect
the paper stock from sand, grit and
other hard particle, that may dam-
age the printhead.
The EasyCoder 201 II printers can use various types of external
supplies, e.g. boxes of fan-folded tickets or an external paper roll
thanks to its external paper intake. The outer guide is adjustable for
different paper widths.
The EasyCoder 201 II Bag Tag printer is fitted with guide rails
under its bottom plate, that makes it possible to thread the paper
without opening the right-hand door.
Turn the printhead lift knob counter-clockwise as far as it goes.
1
Pull out any remaining paper stock.
2
Insert the new paper web between the guides underneath the
3
printer's rear plate. The thermal layer should face upwards.
Gently push the paper web until it protrudes through the feed-out
4
slot at the front.
Turn the printhead lift knob clockwise until it snaps into locked
6
position.
Feed out at least one label. To tear off the paper, pull it upwards.
7
