UBI Shell 4.0 Standard - Startup Manual
CONTENTS
UBI Shell 4.0 Standard
Startup Manual
Edition 2, June 1995
Art. No. 1-960372-01
Contents .................................................................................. 1
Copyrights and Trade Marks ................................................... 2
Startup Files ............................................................................ 3
Using the Print Key and Headlift Handle ................................. 4
Starting Up with UBI Shell ...................................................... 5
Options in UBI Shell ................................................................ 6
Overview ................................................................................ 9
Step-by-Step Instructions ....................................................... 10
Setup Overview ..................................................................... 14
Starting Terminal Setup ......................................................... 15
Solving Communication Problems ........................................ 15
Using Terminal Setup ............................................................ 16
Selecting an Application ........................................................ 17
Changing the Setup ............................................................... 18
Exiting Terminal Setup .......................................................... 19
Setup Parameters ................................................................... 20
Description ............................................................................ 21
1
Advertisement
Table of Contents
Related Manuals for UBI EasyCoder 101
Summary of Contents for UBI EasyCoder 101
-
Page 1: Table Of Contents
UBI Shell 4.0 Standard – Startup Manual CONTENTS Introduction Using UBI Shell Setup Mode Terminal Setup Line Analyzer UBI Shell 4.0 Standard Startup Manual Edition 2, June 1995 Art. No. 1-960372-01 Contents ... 1 Copyrights and Trade Marks ... 2 Startup Files ... -
Page 2: Copyrights And Trade Marks
Information in this manual is subject to change without prior notice and does not represent a commitment on the part of UBI Printer AB. © Copyright UBI Printer AB, 1995. All rights reserved. Published in Sweden. EasyCoder and LabelShop are trademarks of United Barcode Industries (UBI). -
Page 3: Startup Files
3. Non DOS-formatted memory cards (SRAM or OTPROM). 4. Printer's ROM memory, e.g. the configuration EPROM's. This implies that if you e.g. have UBI Shell stored in the printer's configuration EPROM's and insert a memory card with another startup file before you turn on the printer, the startup file of the... -
Page 4: Using The Print Key And Headlift Handle
UBI Shell 4.0 Standard – Startup Manual INTRODUCTION, cont'd. Using the Print Key and Headlift Handle EasyCoder 101 Headlift Handle EasyCoder 201 II Headlift Handle EasyCoder 401 and EasyCoder 501 Headlift Handle Print Load DOWN In EasyCoder printers without keyboard, the Print key has been given dual functions in UBI Shell by combining it with the printhead lift handle. -
Page 5: Using Ubi Shell Starting Up With Ubi Shell
UBI Shell 4.0 Standard – Startup Manual USING UBI SHELL Starting Up with UBI Shell A few seconds after you have turned on the power to the printer, the countdown menu of the UBI Shell program will be displayed: PRINT=UBI SHELL 5 sec. -
Page 6: Options In Ubi Shell
Note that after having selected an application, you must wait for the printer to restart and perform the 5 seconds countdown before the selected application is opened. As standard, EasyCoder printers fitted with UBI Shell will contain the following application programs: UBI LabelShop selects the standard serial interface "uart1:"... - Page 7 – these will presented as additional options. When you have selected an application, the printer beeps and the error lamps comes on. Then the display goes blank as the printer is restarted. After a short moment, the printer starts up and the UBI Shell countdown menus are shown again.
- Page 8 The Setup Mode allows you to adjust the Label Stop Sensor (LSS) and to read the printer's present setup in its display window. In EasyCoder 101, you can also set up the printhead resistance, whereas all other models have automatic resistance detection. For information on the various setup parameters, please refer to the Technical Manual for the printer model in question.
-
Page 9: Overview
UBI SHELL option and proceed SER-COM RESET HU/PP UBI SHELL Enter Terminal Setup CLEAR RAM MEMORY by transmitting T T T HU/PP to printer, when menus marked with grey UBI SHELL are displayed! REBOOT HU/PP SEL. APPLICATION HD/PP HD/PP LABELSHOP HU/PP SEL. -
Page 10: Setup Mode Step-By-Step Instructions
The Setup Mode can only be used to manually change the adjust- ment of the label stop sensor/black mark sensor, to read the present setup values and – in case of EasyCoder 101 – to change the printhead resistance setup. To change any other setup parameters, use the Terminal Setup in UBI Shell or a setup file (see statement in the UBI Fingerprint manual). - Page 11 , you will have to adjust the LSS as described below. TESTFEEDs Before the LSS is adjusted, the printer must be set up for the type of paper web you intend to use, i.e. “Label (w gaps)”, “Ticket (w mark)”, “Ticket (w gaps)”, “Fix length strip”, or “Var. length strip”.
- Page 12 UBI Shell 4.0 Standard – Startup Manual SETUP MODE, cont'd. Step-by-Step Instructions, cont'd. Label (w gaps): Put a piece of paper with backing paper into the sensor. The cursor should appear at the left side of the menu: LABEL <103> GAP Put a piece of backing paper without any label into the sensor.
- Page 13 LSS. Select another level by pressing < Print > with the print- head lifted. EasyCoder 101 and EasyCoder 201 II: Each time you press < Print >, the level will increase one step in a loop of four levels (000-001-002-003-000-001-002-003- 000...).
-
Page 14: Setup Overview
DISABLE HD/PP U1,XO,FROM HOST ENABLE HD/PP U1,XO,TO HOST ENABLE HU/PP HEAD RESISTANCE HEAD RESISTANCE HEAD RESISTANCE EasyCoder 101 only HEAD RESISTANCE HEAD RESISTANCE HEAD RESISTANCE HD/PP HEAD RESISTANCE All others HEAD RESISTANCE HU/PP LSS ADJUST LABEL <103> HD + HU... -
Page 15: Terminal Setup Starting Terminal Setup
T (TTT) to start Terminal Setup. There you can change the printer's setup to the desired protocol. Turn off the printer, change the setup of the host to the desired protocol, and start up the printer again. Now the communication should work. -
Page 16: Using Terminal Setup
Comprehensive explanations of the various setup parameters can be found in the Technical Manual for the printer model in question. When you transmit the triple T (TTT) to the printer, the following message will appear on printer's display: SETUP FROM... -
Page 17: Selecting An Application
(Y / N):N ---------------- SEL. APPLICATION UBI Fingerprint 6.0 ---------------- (Y / N):Y ---------------- STD I/O CHANNEL UART1 ---------------- (Y / N):Y When you have answered the final prompt, the printer will exit Terminal Setup, reboot and start the selected application. -
Page 18: Changing The Setup
TERMINAL SETUP, cont'd. Changing the Setup If you want to set up the printer or use any other of the facilities, you should answer N (=No) to the “Select Application” prompt. The following example illustrates how to change the printer's commu-... -
Page 19: Exiting Terminal Setup
(Y / N):Y If you answer N (=No) here, you will return to the “Select Application” option, but if you answer Y (=Yes) the printer will start up again and begin the UBI Shell countdown. Then you can enter Terminal Setup once more by transmitting a triple T, enter the UBI Shell manually by pressing the <... -
Page 20: Setup Parameters
“Setup Mode”. ---------------- SETUP FROM TERMINAL ---------------- Reading printer setup, please wait. If no change, press ENTER To end terminal setup: enter QUIT (Q), or QUIT and SAVE (S) CONTRAST,5 New value: (0-10) : UART1,BAUDRATE,9600... -
Page 21: Line Analyzer Description
You can scroll between the ports, which are organized as a continuous loop (1-2-3-4-1...) by pressing the < Print > key with the printhead lifted. If the printer is not fitted with a port, an error message appears in the display:... - Page 22 UBI Shell 4.0 Standard – Startup Manual NOTES...
