UBI EasyCoder 601 – Installation Instruction
PAPER CUTTER KIT

General Information

UBI EasyCoder 601 E
Paper Cutter Kit
Installation Instructions
Edition 2, February 1995
Article No. 1-960348-51
This leaflet contains instructions on how to fit a Paper Cutter on an
EasyCoder 601 E printer.
The Paper Cutter Kit consists of:
• One cutter unit assembly
• This installation instructions leaflet
The Paper Cutter is power-supplied by the printer and is conse-
quently not dependent on the mains voltage.
The Paper Cutter is intended to cut through continuous non-
adhesive paper strip or through the backing paper between labels.
It must not be used to cut through any kind of adhesive, which would
stick to the cutting parts and rapidly render the cutter inoperable –
possibly also causing damage to the electric motor.
Maximum paper thickness is 175 µm (≈ 175 grammes/m
normal paper-based materials.
The Paper Cutter replaces the printer's front hatch and can be tilted
down in order to facilitate cleaning and paper load and also to give
access to the optional Memory Card Adapter.
When the Paper Cutter is fitted, it will increase the printer's length
and weight by:
Length .......... :
28 mm
≈ 1.65 kgs (≈ 3.6 lbs)
Weight .......... :
The rotating cutting edge will cut through the paper approximately
37 mm (1.5") in front of the printer's tear-off edge. The paper feed
setup should be adjusted accordingly, see page 6.
For safety reasons, the cutter must not be operated
when in open position.
Information in this manual is subject to change without prior notice
and does not represent a commitment on the part of UBI Printer AB.
© Copyright UBI Printer AB, 1995. All rights reserved. Published
in Sweden.
EasyCoder is a trademark of United Barcode Industries (UBI).
Torx is a registered trademark of Camcar Division of Textron Inc.
(1.1")
CAUTION!
2
) for
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyCoder 601 and is the answer not in the manual?

Questions and answers

Related Manuals for UBI EasyCoder 601

Summary of Contents for UBI EasyCoder 601

  • Page 1 Information in this manual is subject to change without prior notice UBI EasyCoder 601 E and does not represent a commitment on the part of UBI Printer AB. Paper Cutter Kit © Copyright UBI Printer AB, 1995. All rights reserved. Published Installation Instructions in Sweden.
  • Page 2 Remove the hatch completely. Front Hatch Press sideways As standard, the EasyCoder 601 E is fitted with a label-taken sensor (LTS), which intrudes on the space required by the cutter and which has no use anyway in connection with cut-off operation.
  • Page 3 UBI EasyCoder 601 – Installation Instruction PAPER CUTTER KIT, cont'd. Step-by-Step Instructions, Disconnect the LTS cable from connector P-606 at the upper cont'd. front corner of the CPU board. Disconnect LTS Here! POWER ON EPROM FLASH 040700.04 P-606 Loosen the #T10 Torx screw that holds the LTS bracket to the front of the print unit and remove the LTS assembly.
  • Page 4 UBI EasyCoder 601 – Installation Instruction PAPER CUTTER KIT, cont'd. Step-by-Step Instructions, Fit the cutter unit to the vacant hinges from which you removed cont'd. the front hatch. Make sure that the locking plate snaps into the groove of the right-hand hinge and that the angled plate at the bottom of the cutter is inserted under the printer's bottom plate.
  • Page 5 UBI EasyCoder 601 – Installation Instruction PAPER CUTTER KIT, cont'd. Step-by-Step Instructions, Put back the power cord and switch on power. The cutter will cont'd. perform an idle cycle in order to occupy its home position. Switch off the power again.
  • Page 6 UBI EasyCoder 601 – Installation Instruction PAPER CUTTER KIT, cont'd. Controlling the Cutter The cutter is activated by statements in the UBI Fingerprint program, see the UBI Fingerprint manual. Since the cutting edge is situated a longer distance from the printhead than the tear-off/dispensing edge, the paper feed setup may need to be adjusted (see “Setup Parameters;...
