2 Description

System Board Features

Table 1. System Board Features
Feature
Processors
Memory
Chipset
I/O Control
Peripheral Interfaces
Expansion Capabilities
BIOS
Power Management
Form Factor
MAXDATA Fusion 6000
Description
Support for an Intel Pentium
®
Support for an Intel Celeron
®
Supported
• Two 184-pin DDR SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for up to 2 GB ECC system memory
• Support for single-sided or double-sided DIMMs (DDR 200/266)
Intel 845E Chipset, consisting of:
®
• Intel
82845E Memory Controller Hub (MCH)
®
• Intel
82801BA I/O Controller Hub (ICH2)
®
• Intel
82802AB 4 Mbit Firmware Hub (FWH)
®
SMSC LPC47M102 LPC bus I/O controller
• Two external USB ports with an additional internal header providing two
optional USB ports for front panel support
• One serial port and one serial port header
• One parallel port
• Two IDE interfaces with UDMA 33, ATA-66/100 support
• One fl oppy drive interface with support for two drives (Diskette A and
Diskette B)
• PS/2 keyboard and mouse ports
One independent PCI bus (32-bit/33 MHz, 5 V) with three PCI connectors and
four embedded devices:
• 2D/3D graphics controller – ATI Rage XL Video Controller with 2 MB of
SDRAM
• Two Intel 10/100 82550PM Fast Ethernet Controllers
®
• ATA-100 controller, Promise Technology PDC20267
Intel /AMI BIOS with support for: /AMI BIOS with support for:
® ® ®
• Advanced Confi guration and Power Interface (ACPI)
• Plug and Play
• SMBIOS
Support for ACPI
• Wake on PME
• Wake on Ring (WOR)
• Wake on LAN (WOL)
SSI-compliant
4 processor in a µPGA478 socket
®
processor in a µPGA478 socket 400/533 MHz
®
9
