Processors

The System board board supports a single Intel
Processors are not included with the system board and must be purchased separately.
Table 2. Supported Processors
Type
Intel Pentium 4 processor
® ®
Intel Pentium 4 processor
® ®
Intel Celeron processor
® ®

Memory

The SE845WD1-E system board contains two 184-pin DIMM sockets and supports up to
two DDR SDRAM DIMMs. The minimum supported memory configuration is 64 MB and
the maximum configurable memory size is a 2 GB stacked un-buffered DDR200/266 ECC
DIMM. See the table below for supported memory configurations.
Table 3. Supported Memory Confi gurations
DIMM Number of
Capacity Sides
64 MB SS
64 MB SS
128 MB DS
128 MB SS
128 MB SS
256 MB DS
256 MB SS
256 MB SS
512 MB DS
512 MB SS
1024 MB DS
Notes:
1. If the number of DDR SDRAM devices is greater than nine, the DIMM will be double sided.
2. Front side population/back side population indicated for DDR SDRAM density and DDR SDRAM organization.
DIMM and memory configurations must adhere to the following:
• 2.5 V (only) 184-pin DDR SDRAM DIMMs with gold-plated contacts
• Unbuffered single-sided or double-sided DIMMs.
• Maximum total system memory: 2 GB; Minimum total system memory: 64 MB
• 200/266 MHz DDR SDRAM DIMMs only
• Serial Presence Detect (SPD)
• Suspend to RAM
• Non-ECC and ECC DIMMs
• Only DIMMs tested and qualified by Intel
supported on the MAXDATA Fusion 6000 System board. A list of qualified DIMMs will
be made available. Note that all DIMMs are supported by design, but only fully qualified
DIMMs will be supported.
MAXDATA Fusion 6000
Pentium
®
Designation
1.6, 1.8, 2.0, 2.26, and 2.4 GHz
1.8, 1.9, and 2.0 GHz
1.7, 1.8, and 1.9 GHz
DDR SDRAM DDR SDRAM Organization
Density Front-side/Back-side
64 Mbit 8 M x 8/empty
128 Mbit 8 M x 16/empty
64 Mbit 8 M x 8/8 M x 8
128 Mbit 16 M x 8/empty
256 Mbit 16 M x 16/empty
128 Mbit 16 M x 8/16 M x 8
256 Mbit 32 M x 8/empty
512 Mbit 32 M x 16/empty
256 Mbit 32 M x 8/32 M x 8
512 Mbit 64 M x 8/empty
512 Mbit 64 M x 8/64 M X8
or a designated memory test vendor will be
®
4 processor with a µPGA478 socket.
®
System Bus L2 Cache Size
400 / 533 MHz 512 KB
400 MHz 256 KB
400 MHz 128 KB
Number of DDR
SDRAM Devices
8
4
16 (Note 1)
8
4
16 (Notes 1 and 2)
8
4
16 (Notes 1 and 2)
8
16
11
