- Page 1 MAXDATA Fusion 6000 System Manual MAXDATA Fusion 6000...
- Page 2 Inhalt...
-
Page 3: Table Of Contents
System States and Power States ..................21 Wake-up Devices and Events ....................22 Hardware Support........................22 Power Connector ........................23 Fan Connectors........................23 LAN Wake Capabilities ......................23 Instantly Available PC Technology ..................23 Resume on Ring ........................24 MAXDATA Fusion 6000... - Page 4 Wake from USB ........................24 Wake from PS/2 Devices ....................... 24 PME# Wake-up Support ......................24 PCI I/O Subsystem ........................ 25 32-bit, 33-MHz PCI Subsystem ..................25 Device IDs (IDSEL) ......................25 PCI Arbitration ........................25 ATA-100 ..........................26 Video Controller ........................26 Video Modes ........................
- Page 5 7. Wake-up Devices and Events..................22 8. Fan Connector Function/Operation ................. 23 9. PCI Bus Characteristics ....................25 10. PCI Bus Confi guration IDs....................25 11. Video Modes ........................27 12. Product Certifi cation Markings ..................29 MAXDATA Fusion 6000...
- Page 6 Contents...
-
Page 7: Setting Up The System
This is especially important for impact printers whose vibrations could damage the hard disk. ATTENTION In order to fully separate the system from current, the power cord must be removed from the wall outlet MAXDATA Fusion 6000... -
Page 8: Connecting The System
Connecting the system Rear Connectors Figure 1. Rear connectors A. PS/2-Mouse NIC 1 B. PS/2-Keyboard G. USB-Connector 1 C. Parallel port (Parallelport) H. USB-Connector 2 D. Serial port A (Serieller Port A) NIC 2 E. VGA port Powering up the system At the front of the case, you can find the neccessary controls like power button, reset button and the HDD Leds. -
Page 9: Description
® • Advanced Confi guration and Power Interface (ACPI) • Plug and Play • SMBIOS Power Management Support for ACPI • Wake on PME • Wake on Ring (WOR) • Wake on LAN (WOL) Form Factor SSI-compliant MAXDATA Fusion 6000... -
Page 10: System Board Connector And Component Locations
System Board Connector and Component Locations Figure 3. System Board Components PCI expansion slots Primary IDE connector ATI Rage XL Video Controller Floppy drive connector Chassis intrusion connector System fan (fan 3) AGP connector Intel 82801BA I/O controller hub (ICH2) ®... -
Page 11: Processors
® supported on the MAXDATA Fusion 6000 System board. A list of qualified DIMMs will be made available. Note that all DIMMs are supported by design, but only fully qualified DIMMs will be supported. -
Page 12: Intel ® 845E Chipset
Intel 845E Chipset ® The Intel 845E chipset consists of the following devices: ® • Intel 82845E Memory Controller Hub (MCH) with Accelerated Hub Architecture (AHA) ® • Intel 82801BA I/O Controller Hub (ICH2) with AHA bus ® • Intel 82802AB Firmware Hub (FWH) ®... -
Page 13: I/O Controller
The BIOS Setup program provides configuration options for the I/O controller. Serial Ports The MAXDATA Fusion 6000 System board has one serial port connector and one serial port header. The serial port A connector is located on the back panel. The serial port B header is located near the main power connector. -
Page 14: Hardware Management Subsystem
Hardware Management Subsystem The Hardware Management features enable the board to be compatible with the Wired for Management (WfM) specification. The board has several hardware management features, including the following: • Fan monitoring • Thermal and voltage monitoring • Chassis intrusion detection Hardware Management ASIC The Hardware Management ASIC provides low-cost instrumentation capabilities. -
Page 15: Legacy Usb Support
USB. By default, Legacy USB support is set to Enabled. The MAXDATA Fusion 6000 System board has two USB 1.1 ports; one USB peripheral can be connected to each port. For more than two USB devices, an external hub can be connected to any of the ports. -
Page 16: Ide Support
The drive reports the transfer rate and translation mode to the BIOS. The MAXDATA Fusion 6000 System board supports Laser Servo (LS-120) diskette tech- nology through the IDE interfaces. An LS-120 drive can be configured as a boot device by setting the BIOS Setup program’s Boot menu to one of the following:... -
Page 17: Pci Ide Support
CD in the CD-ROM drive, the system will attempt to boot from the next defi ned drive. The network can be selected as a boot device . This selection allows booting from the on- board NIC or a network add-in card with a remote boot ROM installed. MAXDATA Fusion 6000... -
Page 18: Booting Without Attached Devices
Booting Without Attached Devices For use in embedded applications, the BIOS has been designed so that after passing the POST, the operating system loader is invoked even if the following devices are not present: • Video adapter • Keyboard • Mouse Fast Booting Systems with Intel Rapid BIOS Boot... -
Page 19: System Management Bios (Smbios)
Hardware support: − Power connector − Fan connectors − LAN wake capabilities − Instantly Available PC technology − Resume on Ring − Wake from USB − Wake from PS/2 devices − Power Management Event (PME#) wake-up support MAXDATA Fusion 6000... -
Page 20: Wake On Lan Technology
ACPI gives the operating system direct control over the power management and Plug and Play functions of a computer. The use of ACPI with the MAXDATA Fusion 6000 System board requires an operating system that provides full ACPI support. ACPI features include: •... -
Page 21: System States And Power States
Notes: Total system power is dependent on the system confi guration, including add-in boards and peripherals powered by the system chassis’ power supply. Dependent on the standby power consumption of wake-up devices used in the system. MAXDATA Fusion 6000... -
Page 22: Wake-Up Devices And Events
The use of these wake-up events from an ACPI state requires an operating system that provides full ACPI support. In addition, software, drivers, and peripherals must fully support ACPI wake events. Hardware Support The MAXDATA Fusion 6000 System board provides several power management hardware features, including: • Power connector •... -
Page 23: Power Connector
When used with an ATX12V or EPS-12 V compliant power supply that supports remote power on/off, the MAXDATA Fusion 6000 System board can turn off the system power through software control. When the system BIOS receives the correct command from the operating system, the BIOS turns off power to the computer. -
Page 24: Resume On Ring
The standby power indicator LED shows that power is still present even when the computer appears to be off. Figure 4 shows the location of the standby power indicator LED. CAUTION If AC power has been switched off and the standby power indicator is still lit, disconnect the power cord before installing or removing any devices connected to the board. -
Page 25: Pci I/O Subsystem
Independent Bus Supports full-length cards 32-bit, 33-MHz PCI Subsystem All 32-bit, 33-MHz PCI I/O for the MAXDATA Fusion 6000 System board is directed through the Intel 82801BA I/O Controller Hub (ICH2). The PCI bus supports the following embedded ® devices and connectors: •... -
Page 26: Video Controller
(RAID 0+1) for storage capacity and data redundancy. Video Controller The MAXDATA Fusion 6000 System board provides an ATI Rage XL PCI graphics accelerator, along with 8 MB of video SDRAM and support circuitry for an embedded SVGA video subsystem. -
Page 27: Video Modes
Intel 82559, with the addition of Alert-on-LAN ® functionality. The MAXDATA Fusion 6000 System board supports independent disabling of the two NIC controllers using the BIOS Setup menu. The 82550PM supports the following features: •... -
Page 28: Nic Connector And Status Leds
The yellow LED indicates 100-Mbps operation when lit, and 10-Mbps when off. Hardware Monitoring The MAXDATA Fusion 6000 System board has an integrated Hardware Management ASIC that is responsible for hardware monitoring. Together, the Hardware Management ASIC and the Intel LANDesk Client Manager (LDCM) 6.3 software provide basic system hardware... -
Page 29: Regulatory And Integration Information
• EN55024 (Immunity) (European Union) • CE – EMC Directive (89/336/EEC) (European Union) Product Regulatory Compliance Markings This product is marked with the following Product Certification Markings: Table 12. Product Certification Markings UL Recognition Mark CE Mark MAXDATA Fusion 6000... -
Page 30: Electromagnetic Compatibility Notices
Electromagnetic Compatibility Notices FCC (USA) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 31: Installation Precautions
The suitability of this product for other applications or environments, (such as medical, industrial, alarm systems, test equipment, etc.) may require further evaluation. MAXDATA Fusion 6000...
