- Page 1 MAXDATA PLATINUM 220 Server System Manual...
- Page 2 Contents...
-
Page 3: Table Of Contents
Wake from PS/2 Devices .........................21 Hardware Support ..........................21 Power Connector ..........................21 Fan Connectors .............................22 Instantly Available PC Technology......................22 Hardware Management and Monitoring ....................23 Password Security..........................23 Real-Time Clock, CMOS SRAM, and Battery ..................24 Recovering the CMOS ..........................25 MAXDATA PLATINUM 220 Server... - Page 4 BIOS ..............................25 PCI Auto Configuration........................26 IDE Auto Configuration........................26 Boot Options ............................26 CD-ROM and Network Boot......................26 Booting Without Attached Devices ....................27 Fast Booting Systems with Intel Rapid BIOS Boot................27 ® Intel Rapid BIOS Boot ........................27 ® 3 Regulatory and Integration Information Product Regulatory Compliance ......................29 Product Safety Compliance ......................29 Product EMC Compliance ........................29...
-
Page 5: Setting Up The System Server Position
An insufficient air flow may damage the server and / or it’s components. ATTENTION In order to fully separate the server from current, the power cord must be removed from the wall outlet MAXDATA PLATINUM 220 Server... -
Page 6: Connecting The System
Connecting the system Rear Connectors � � � � � � � � � Figure 1. Rear connectors PS/2-Mouse NIC 1 PS/2-Keyboard G. NIC 2 Parallel port (Parallelport) USB-Connector 1 Serial port A (Serieller Port A) USB-Connector 2 VGA port Powering up the system At the front of the case, you can find the neccessary controls like power button, reset button and the HDD Leds. -
Page 7: Server Description
• 2D/3D graphics controller – ATI Rage XL Video Controller with 8 MB of SDRAM. • Serial ATA: SATA-150 controller, Promise Technology PDC20319. • Accelerated Graphics Port (AGP) connector providing AGP 8x support. continued MAXDATA PLATINUM 220 Server... -
Page 8: Back Panel Connectors
Table 1. Server Board Features (continued) BIOS Intel /AMI BIOS with support for: ® • Advanced Configuration and Power Interface (ACPI). • 8 megabit symmetrical flash memory. • Support for SMBIOS. • Intel Rapid BIOS Boot. ® • Intel Express BIOS Update. ®... -
Page 9: Server Board Connector And Component Locations
SATA-B1 and SATA-B2 Connectors (slots numbered from left to right) Serial B Header AGP Connector NIC2 (10/100 MB) System Fan 1 Header System Fan 2 Header NIC1 (1 GB) Front Panel Connector Back Panel I/O Ports MAXDATA PLATINUM 220 Server... -
Page 10: Processor
Processor The S875WP1-E server board supports a single Intel Pentium 4 processor with an mPGA478 socket. ® ® The processor connects to the server board through the mPGA478 socket. The Intel Pentium ® ® processor can be removed and replaced to accommodate a supported higher speed processor. The server board S875WP1-E supports the following processors. -
Page 11: Intel ® 875P Chipset
Integrated LAN controller (Intel 8562ET). ® • 33 MHz Peripheral Component Interface (PCI) Local Bus slots supporting PCI specification, Rev 2.3. • Power management logic (ACPI Rev 2.0-compliant). • Support for two Ultra DMA 33/ATA 100/66 connectors. MAXDATA PLATINUM 220 Server... -
Page 12: Video
Video The server board S875WP1-E contains two separate, mutually exclusive graphics subsystems. You can use either the AGP connector or the ATI Rage XL video controller. When an AGP card is installed, the integrated 8 MB video controller is disabled. AGP Connector AGP is a high-performance interface for graphics-intensive applications. -
Page 13: Super I/O
A connector is located on the back panel. The serial ports’ NS16C550-compatible UART supports data transfers at speeds up to 115.2 kB/s with BIOS support. A DH10 10-pin serial header is available on the Baseboard for an option Serial B port. MAXDATA PLATINUM 220 Server... -
Page 14: Parallel Port
Parallel Port The 25-pin D-Sub parallel port connector is located on the back panel. In the BIOS Setup program, the parallel port can be set to the following modes: • Output only (PC AT-compatible mode) • Bi-directional (PS/2 compatible) • •... -
Page 15: Pci I/O Subsystem
PCI bus supports the following embedded devices and connectors: • 2D/3D Graphics Accelerator: ATI Rage XL Video Controller. • Three PCI slots Table 4. PCI Bus Characteristics Voltage Width Speed Type Comments 32-bits 33 MHz Independent Bus Supports full-length cards MAXDATA PLATINUM 220 Server... -
Page 16: Data Storage
Data Storage Serial ATA (SATA) The server board S875WP1-E supports Serial ATA devices using the ICH5-R controller. The ICH-5 provides the following Serial ATA support: • 150 MB/sec transfer rate. • Up to two SATA devices on the server board S875WP1-E. These are indicated by the connectors labeled SATA-B1 and SATA-B2 on the server board. -
Page 17: Network Interface Controller (Nic)
On (brighter and The computer is communicating with another computer pulsing) on the LAN. Table 6 describes the LED states when the board is powered up and the 82547EI 10/100/1000 Gigabit Ethernet LAN subsystem is operating. MAXDATA PLATINUM 220 Server... -
Page 18: Power Management
Table 6. 10/100/1000 Gigabit Ethernet LAN Connector LEDs LED Color LED State Indicates Green LAN link is not established. (left LED) On (steady state) LAN link is established. The computer is communicating with another computer (brighter and pulsing) on the LAN. Bi-color LED 10 MBit/sec data rate is selected. -
Page 19: Effects Of Pressing The Power Switch Under Acpi
(ACPI S5 – Soft off) Sleep Less than four seconds Wake-up (ACPI S1 – sleeping state) (ACPI S0 – working state) Sleep More than four seconds Power-off (ACPI S1 – sleeping state) (ACPI S5 – Soft off) MAXDATA PLATINUM 220 Server... -
Page 20: Wake-Up Devices And Events
Wake-up Devices and Events Table 8 provides an overview of the devices or events that can wake the computer from specific states. Table 8. Wake-up Devices and Events These devices/events can wake up the computer… …from this state Power button S1, S3, S4 (Note 1), S5 RTC alarm S1, S3, S4 (Note 1), S5... -
Page 21: Wake From Usb
A standard ATX 20 pin power connector and standard ATX 12V 4-pin 2x2 connector can be used to power the S875WP1-E board. Plug the power cables into the pin 1 end of their respective motherboard connectors, leaving pins 21-24 unused on the main power connector and 5-8 unused on the 12V connector. MAXDATA PLATINUM 220 Server... -
Page 22: Fan Connectors
Fan Connectors Table 9 summarizes the function/operation of the fan connectors. Table 9. Fan Connector Function/Operation Connector Description Processor fan (CPU FAN) • +12V DC connection for a processor fan or active fan heat sink. • Fan is on in the S0 or S1 state. Fan is off when the system is off or in the S3, S4, or S5 state. -
Page 23: Hardware Management And Monitoring
If both the supervisor and user passwords are set, you must enter either the supervisor password or the user password to access Setup. Setup options are then available for viewing and changing depending on whether the supervisor or user password was entered. MAXDATA PLATINUM 220 Server... -
Page 24: Real-Time Clock, Cmos Sram, And Battery
• Setting a user password restricts who can boot the server. The password prompt is displayed before the server is booted. If only the supervisor password is set, the server boots without asking for a password. If both passwords are set, you can enter either password to boot the server. -
Page 25: Recovering The Cmos
When the S875WP1-E server board’s jumper is set to configuration mode and the server is powered- up, the BIOS compares the processor version and the microcode version in the BIOS and reports if the two match. MAXDATA PLATINUM 220 Server... -
Page 26: Pci Auto Configuration
PCI Auto Configuration The BIOS can automatically configure PCI devices. PCI devices may be onboard or add-in cards. Auto configuration lets a user insert or remove PCI cards without having to configure the system. When a user turns on the system after adding a PCI card, the BIOS automatically configures interrupts, the I/O space, and other system resources. -
Page 27: Booting Without Attached Devices
This boot time may be so fast that some drives might be not be initialized at all. If this condition should occur, it is possible to introduce a programmable delay ranging from three to 30 seconds (using the Hard Disk Pre-Delay feature of the Advanced Menu in the Drive Configuration Submenu of the BIOS Setup program). MAXDATA PLATINUM 220 Server... - Page 28 Server Description...
-
Page 29: Regulatory And Integration Information
EN55024 (Immunity) (European Union) • CE – EMC Directive (89/336/EEC) (European Union) Product Regulatory Compliance Markings This product is marked with the following Product Certification Markings: Table 11. Product Certification Markings UL Recognition Mark CE Mark MAXDATA PLATINUM 220 Server... -
Page 30: Electromagnetic Compatibility Notices
Electromagnetic Compatibility Notices FCC (USA) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 31: Installation Requirements
The suitability of this product for other applications or environments, (such as medical, industrial, alarm systems, test equipment, etc.) may require further evaluation. MAXDATA PLATINUM 220 Server...
