- Page 1 MAXDATA PLATINUM NAS1000R Server User’s Manual...
-
Page 3: Table Of Contents
1. Server Board Features ........................7 2. Configuration Jumpers [J1D1] ......................10 3. NIC LEDs ............................11 4. Keyboard Commands ........................15 5. LED Information ..........................17 6. BIOS Error Messages ........................18 7. BIOS Post Beep Codes ........................19 8. Product Certification Markings ......................21 MAXDATA PLATINUM NAS1000R Server... - Page 5 ESD protection by wearing an antistatic wrist strap attached to chassis ground - any unpainted metal surface - on your server when handling parts. ATTENTION In order to fully separate the server from current, the power cord must be removed from the wall outlet. MAXDATA PLATINUM NAS1000R Server...
-
Page 6: Setting Up The System
Powering up the System At the front of the case, you can find the neccessary controls like power button, reset button and the HDD LEDs. Press the power button one time briefly in order to boot the server. � � �... -
Page 7: Server Board Features
• Three PCI-X 64-bit PCI slots • One 32-bit PCI slot Integrated Capabilities • Integrated 2D/3D graphics controller: ATI Rage XL Video Controller with 8 MB of SDRAM Fans Support for up to six system fans and one processor fan MAXDATA PLATINUM NAS1000R Server... - Page 8 BIOS Intel/AMI BIOS with support for: • Advanced Configuration and Power Interface (ACPI) • 8 megabit symmetrical flash memory • Support for SMBIOS Power Management Support for ACPI: • Suspend to RAM (STR) • Wake on USB, PCI, RS-232, PS/2, LAN, and front panel Server Management Intel Server Management 5.8 support via mini Baseboard Management...
-
Page 9: Server Board Connector And Component Locations
PCI Slot 6, 32/33 Aux Power Connector NIC 2 (10/100 Mbit) Main Power Connector NIC 1 (1 Gbit) Secondary IDE Connector Video Connector Primary IDE Connector Serial A Connector Floppy Connector Keyboard and Mouse Battery USB Connectors MAXDATA PLATINUM NAS1000R Server... -
Page 10: Configuration Jumpers
Configuration Jumpers Figure 3. Configuration Jumper Location Table 2. Configuration Jumpers [J1D1] Jumper Name Pins What happens at system reset CMOS clear If these pins are jumpered, the CMOS settings will be cleared on the next reset. These pins should be jumpered on 1-2 for normal operation. Password Clear If these pins are jumpered, administrator and user passwords will be cleared on the next reset. -
Page 11: Rear Connectors
No network connection (Gigabit) Solid Amber Network connection in place Blinking Transmit/receive activity Amber Right LED 10 Mbps connection (if left LED is on or blinking) Solid Amber 100 Mbps connection Solid Green 1000 Mbps connection MAXDATA PLATINUM NAS1000R Server... -
Page 12: Hardware Requirements
Hardware Requirements Processor A minimum of one Intel Pentium 4 Processor 2.0 GHz with 512 KB Cache cache support is re- ® ® quired. Memory A minimum of one 128 MB Unbuffered, ECC or non-ECC, DDR266-, DDR333- or DDR400- compliant, 184-pin DIMMs. -
Page 13: Server Board Installations And Upgrades
Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekviva lent typ som rekom- men deras av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruktion. VAROITUS Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan laitevalmistajan suo- sittele maan tyyppiin. Hävitä käytetty paristo valmistajan oh jeiden mukaisesti. MAXDATA PLATINUM NAS1000R Server... -
Page 14: Replacing The Battery
1. Observe the safety and ESD precautions at the beginning of this book. 2. Turn off all peripheral devices connected to the server. Turn off the server. 3. Disconnect the AC power cord from the server. 4. Remove the server’s cover and locate the battery. 5. -
Page 15: Server Utilities
Setup is exited. If “No” is selected and the Enter key is pressed, or the ESC key is pressed, the user is returned to where they were before F10 was pressed without affecting any existing values. MAXDATA PLATINUM NAS1000R Server... -
Page 16: Clearing The Password
Clearing the Password If the user or administrator password(s) is lost or forgotten, moving the password clear jumper into the “clear” position clears both passwords. The password clear jumper must be restored to its origi- nal position before a new password(s) can be set. The password clear jumper is located on jumper block J1D1. -
Page 17: Led Information
Power LED Identify the power Front Panel Green • Off = Power is off state of the system (off or S5) • On = Power on or • Slow Blink = Low power state (S1 – S3) MAXDATA PLATINUM NAS1000R Server... -
Page 18: Bios Error Messages
BIOS Error Messages When a recoverable error occurs during the POST, the BIOS displays an error message describing the problem (see Table 6). Table 6. BIOS Error Messages Error message Explanation GA20 Error An error occurred with Gate A20 when switching to pro- tected mode during the memory test. -
Page 19: Bios Post Beep Codes
. These beeps have a code that identifies system or PCI card events. For example, some Intel ® RAID cards have beep codes. Before checking for a system beep code error make sure the PCI card is not causing the beeping. MAXDATA PLATINUM NAS1000R Server... -
Page 21: Regulatory And Compliance Information
Europe (CE Declaration of Conformity) This product has been tested in accordance too, and complies with the Low Voltage Directive (73/23/ EEC) and EMC Directive (89/336/EEC). The product has been marked with the CE Mark to illustrate its compliance. MAXDATA PLATINUM NAS1000R Server...
