- Page 1 MAXDATA PLATINUM 100 Server System Manual MAXDATA PLATINUM 100 Server...
- Page 2 Contents...
-
Page 3: Table Of Contents
System States and Power States ..................21 Wake-up Devices and Events ....................22 Hardware Support........................22 Power Connector ........................23 Fan Connectors........................23 LAN Wake Capabilities ......................23 Instantly Available PC Technology ..................23 Resume on Ring ........................24 MAXDATA PLATINUM 100 Server... - Page 4 Wake from USB ........................24 PME# Wake-up Support ......................24 Wake from PS/2 Devices ....................... 24 PCI I/O Subsystem ........................ 25 32-bit, 33-MHz PCI Subsystem ..................25 Device IDs (IDSEL) ......................25 PCI Arbitration ........................25 ATA-100 ..........................26 Video Controller ........................26 Video Modes ........................
- Page 5 6. Power States and Targeted System Power ..............21 7. Wake-up Devices and Events..................22 8. Fan Connector Function/Operation ................. 23 9. PCI Bus Characteristics ....................25 10. PCI Bus Configuration IDs....................25 11. Video Modes ........................27 12. Product Certification Markings ..................29 MAXDATA PLATINUM 100 Server...
- Page 6 Contents...
-
Page 7: Setting Up The System
This is especially important for impact printers whose vibrations could damage the hard disk. ATTENTION In order to fully separate the server from current, the power cord must be removed from the wall outlet MAXDATA PLATINUM 100 Server... -
Page 8: Connecting The System
Connecting the system Rear Connectors � � � � � � � � � Figure 1. Rear connectors PS/2-Mouse NIC 1 PS/2-Keyboard USB-Connector 1 Parallel port (Parallelport) USB-Connector 2 Serial port A (Serieller Port A) NIC 2 VGA port Powering up the system At the front of the case, you can find the neccessary controls like power button, reset button and the HDD Leds. -
Page 9: Description
® • Advanced Configuration and Power Interface (ACPI) • Plug and Play • SMBIOS Power Management Support for ACPI • Wake on PME • Wake on Ring (WOR) • Wake on LAN (WOL) Form Factor SSI-compliant MAXDATA PLATINUM 100 Server... -
Page 10: Server Board Connector And Component Locations
Server Board Connector and Component Locations � � � � � � � � �� � �� � �� � � � � � � � � � � � � � � � � Figure 3. Server Board Components PCI expansion slots Primary IDE connector ATI Rage XL Video Controller... -
Page 11: Processors
® supported on the MAXDATA Platinum Server board. A list of qualified DIMMs will be made available. Note that all DIMMs are supported by design, but only fully qualified DIMMs will be supported. -
Page 12: Intel ® 845E Chipset
Intel 845E Chipset ® The Intel 845E chipset consists of the following devices: ® • Intel 82845E Memory Controller Hub (MCH) with Accelerated Hub Architecture (AHA) ® • Intel 82801BA I/O Controller Hub (ICH2) with AHA bus ® • Intel 82802AB Firmware Hub (FWH) ®... -
Page 13: I/O Controller
The BIOS Setup program provides configuration options for the I/O controller. Serial Ports The MAXDATA PLATINUM Server board has one serial port connector and one serial port header. The serial port A connector is located on the back panel. The serial port B header is located near the main power connector. -
Page 14: Hardware Management Subsystem
NOTE The keyboard is supported in the bottom PS/2 connector and the mouse is supported in the top PS/2 connector. Power to the computer should be turned off before a keyboard or mouse is connected or disconnected. The keyboard controller contains the AMI keyboard and mouse controller code, provides the keyboard and mouse control functions, and supports password protection for power-on/reset. -
Page 15: Legacy Usb Support
USB. By default, Legacy USB support is set to Enabled. The MAXDATA PLATINUM Server board has two USB 1.1 ports; one USB peripheral can be connected to each port. For more than two USB devices, an external hub can be connected to any of the ports. -
Page 16: Ide Support
The BIOS displays a message during POST identifying the type of BIOS and a revision code. The initial production BIOS is identified as PT84510A.86B. When the MAXDATA PLATINUM Server board’s jumper is set to configuration mode and the server is powered-up, the BIOS compares the processor version and the microcode version in the BIOS and reports if the two match. -
Page 17: Pci Ide Support
CD in the CD-ROM drive, the system will attempt to boot from the next defined drive. The network can be selected as a boot device. This selection allows booting from the on- board NIC or a network add-in card with a remote boot ROM installed. MAXDATA PLATINUM 100 Server... -
Page 18: Booting Without Attached Devices
Booting Without Attached Devices For use in embedded applications, the BIOS has been designed so that after passing the POST, the operating system loader is invoked even if the following devices are not present: • Video adapter • Keyboard • Mouse Fast Booting Systems with Intel Rapid BIOS Boot... -
Page 19: System Management Bios (Smbios)
Hardware support: – Power connector – Fan connectors – LAN wake capabilities – Instantly Available PC technology – Resume on Ring – Wake from USB – Wake from PS/2 devices – Power Management Event (PME#) wake-up support MAXDATA PLATINUM 100 Server... -
Page 20: Wake On Lan Technology
ACPI gives the operating system direct control over the power management and Plug and Play functions of a computer. The use of ACPI with the MAXDATA PLATINUM Server board requires an operating system that provides full ACPI support. ACPI features include: •... -
Page 21: System States And Power States
Notes: Total system power is dependent on the system configuration, including add-in boards and peripherals powered by the system chassis’ power supply. Dependent on the standby power consumption of wake-up devices used in the system. MAXDATA PLATINUM 100 Server... -
Page 22: Wake-Up Devices And Events
The use of these wake-up events from an ACPI state requires an operating system that provides full ACPI support. In addition, software, drivers, and peripherals must fully support ACPI wake events. Hardware Support The MAXDATA PLATINUM Server board provides several power management hardware features, including: • Power connector •... -
Page 23: Power Connector
When used with an ATX12V or EPS-12 V compliant power supply that supports remote power on/off, the MAXDATA PLATINUM Server board can turn off the system power through software control. When the system BIOS receives the correct command from the operating system, the BIOS turns off power to the computer. -
Page 24: Resume On Ring
The standby power indicator LED shows that power is still present even when the computer appears to be off. Figure 4 shows the location of the standby power indicator LED. CAUTION If AC power has been switched off and the standby power indicator is still lit, disconnect the power cord before installing or removing any devices connected to the board. -
Page 25: Pci I/O Subsystem
PCI I/O Subsystem The primary I/O bus for the MAXDATA PLATINUM Server board is PCI, with one independent PCI bus. The PCI bus complies with the PCI Local Bus Specification, Rev 2.2. The PCI bus is directed through the Intel 82801BA I/O Controller Hub (ICH2). -
Page 26: Video Controller
(RAID 0+1) for storage capacity and data redundancy. Video Controller The MAXDATA PLATINUM Server board provides an ATI Rage XL PCI graphics accelera- tor, along with 8 MB of video SDRAM and support circuitry for an embedded SVGA video subsystem. -
Page 27: Video Modes
The server board supports a 8 MB (2048K x 32bit x 4 Banks) SDRAM device for video memory. Network Interface Controller (NIC) The MAXDATA PLATINUM Server board supports two 10Base-T/100Base-TX Network Interface Controllers (NICs) based on the Intel 82550PM NIC. The 82550PM is a highly integrated PCI ®... -
Page 28: Nic Connector And Status Leds
The yellow LED indicates 100-Mbps operation when lit, and 10-Mbps when off. Hardware Monitoring The MAXDATA PLATINUM Server board has an integrated Hardware Management ASIC that is responsible for hardware monitoring. Together, the Hardware Management ASIC and the Intel LANDesk Client Manager (LDCM) 6.3 software provide basic server hardware... -
Page 29: Regulatory And Integration Information
EN55024 (Immunity) (European Union) • CE – EMC Directive (89/336/EEC) (European Union) Product Regulatory Compliance Markings This product is marked with the following Product Certification Markings: Table 12. Product Certification Markings UL Recognition Mark CE Mark MAXDATA PLATINUM 100 Server... -
Page 30: Electromagnetic Compatibility Notices
Electromagnetic Compatibility Notices FCC (USA) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 31: Installation Precautions
The suitability of this product for other applications or environments, (such as medical, industrial, alarm systems, test equipment, etc.) may require further evaluation. MAXDATA PLATINUM 100 Server...
