Summary of Contents for Minuteman V14 PRO
- Page 1 Excellence Meets Clean User Manual 2 Motor Upright...
- Page 2 This manual is furnished with each new V14 PRO. This provides the necessary operating and preventive maintenance instructions. Operators must read and understand this manual before operating or servicing this machine. This machine was designed to give you excellent performance and efficiency. For best result and minimal cost, please follow the general guidelines below: ·...
-
Page 3: Technical Specifications
Technical Specifications Model V14 PRO Model No. V14115P 14” Current Max 9.5 Amps Vacuum motor power 1150 W Traction motor power 150 W Working surface 14” (350 mm) Weight 14.8 Amps Noise level 68 dB(A) Voltage 120 / 60 Hz... -
Page 5: Table Of Contents
Replacing the filter ..............15 Replacing the Hepa filter ............16 Removing debris from the outer duct ....Removing debris from the inner duct ....Accessories provided ............19 For safety during operation ..........20 Warning ................... 21 Minuteman International Limited Warranty ....22-23... -
Page 6: Safety Instructions
Operators must read and understand this manual before operating or maintaining this machine. Do not operate this machine in flammable or explosive areas. This machine is designed solely for vacuuming dirt and dust in an indoor environment. Minuteman does not recommend using this machine in any other capacity. -
Page 7: Unpacking Instructions
Unpacking Instructions INSPECTION Carefully unpack and inspect your V14 PRO for shipping damage. Follow unpacking instructions on shipping pallet. Each unit has been tested and thoroughly inspected before shipment. Any damage is the responsibility of the delivery carrier who should be notified immediately. -
Page 8: Machine Overview
Machine Overview Machine Overview A Ergonomic handle B Power cord C Hose D Telescoping extension E ON/OFF switch F HI/LO vac motor switch G Carrying handle H Upper cord winding device L Lower cord winding device M Dust bag cover N Vent grid O Container P Electric vac motor housing... -
Page 9: Connecting The Hose
Machine Overview Connecting the hose Insert the swivel cuff into the bag-holding sleeve, insert the other end of the swivel cuff into the telescoping element, and hook the hose to the handle. -
Page 10: Telescoping Extension
Machine Overview Operating the telescoping extension Extend the telescoping extension by pulling it; lock it by turning the dedicated ring nut counter-clockwise. -
Page 11: Starting The Brush
Machine Overview Starting the brush Put your foot on the PUSH sign and tilt the vacuum-cleaner body. The brush automatically stops when the handle is placed in the upright position. -
Page 12: Checking The Brush
Machine Overview Checking the brush The brush-checking device continuously monitors the operation of the brush: Green light: the brush is working correctly Red light: the brush is either blocked or it is undergoing excessive stress. Turn the machine off, detach the plug from the power source, and look for the cause of the blockage. -
Page 13: Filter Full Indicator
Machine Overview Filter full indicator If the “bag full” gauge turns red, please verify: a) whether the dust bag is full, or b) whether the brush is clogged, or c) whether the vacuuming hose is clogged; in these cases, remove the obstruction d) whether the Hepa filter is fully clogged. -
Page 14: Replacing The Filter Bag
Machine Overview Replacing the filter bag Remove the cover. Place the dust bag into the container, by inserting the bag-holding sleeve into the dust bag hole and by pushing the safety ring all the way in. If the filter bag is not placed correctly, closing the cover will be impossible. -
Page 15: Replacing The Filter
Machine Overview Replacing the filter Pull out the filter holder and replace the filter, or clean it by tapping it lightly (replace it approximately every 20 bags). Do not start the device without the filter in place; the suction of foreign bodies will damage the vacuum motor. -
Page 16: Replacing The Hepa Filter
Machine Overview Replacing the HEPA filter; replacing or cleaning the pre-filter Pull latch “A” in order to unhook the vent grid; at the same time, slide it (in the direction shown by the arrow) so that it comes free. The pre-filter is housed in the air exhaust under the HEPA filter. -
Page 17: Removing Debris From The Outer Duct
Machine Overview Removing debris from the outer duct Any material clogging the hose can be removed by detaching the telescoping extension from its seat, turning on the vacuum, and intermittently opening and closing the wand end by hand. Do not insert objects into the hose in order to remove the debris. -
Page 18: Removing Debris From The Inner Duct
Machine Overview Removing debris from the inner duct Lay the vacuum body down flat and aligned with the electric brush. Unscrew the 1, 2 and 3 base screws, remove the base. Remove the clogged material from the duct by using a flexible cleaning rod. -
Page 19: Accessories Provided
Machine Overview Accessories provided 1 - Small brush 2 - Crevice tool 3 - Curved sleeve 4 - Hose 5 - Telescoping extension... -
Page 20: For Safety During Operation
The V14 PRO V14 PRO for safety during operations This machine was designed with total operator comfort and ease of use in mind. All machine components have been designed as a total system to efficiently clean dirty floors. • Use extra care when cleaning on stairs. -
Page 21: Warning
The V14 PRO WARNING! - No liability can be accepted for damages to persons and or objects caused by improper use, maintenance carried out by unauthorized personnel, use of unauthorized and non original spare parts, any form of tampering and or modifications to the original product. -
Page 22: Minuteman International Limited Warranty
Minuteman International, Inc. warrants to the original purchaser/user that the product is free from defects in workmanship and materials under normal use. Minuteman will, at its option, repair or replace without charge, parts that fail under normal use and service when operated and maintained in accordance with the applicable operation and instruction manuals. All warranty claims must be submitted through and approved by factory authorized repair stations. - Page 23 This warranty gives you specific legal rights, and you may have other rights which vary from state to state. Some states do not allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above exclusions and limitations may not apply to you.
- Page 24 Excellence Meets Clean Minuteman International · 14N845 U.S. Route 20 · Pingree Grove, Illinois 60140 USA Phone 1-800-323-9420 www.minutemanintl.com A Member of the Hako Group...
