These instructions must be read and understood completely before attempting installation.
Safety Labeling and Signal Words
DANGER,
WARNING,
CAUTION,
and NOTE
The signal words DANGER, WARNING, CAUTION, and NOTE
are used to identify levels of hazard seriousness. The signal word
DANGER is only used on product labels to signify an immediate
hazard. The signal words WARNING, CAUTION, and NOTE will
be used on product labels and throughout this manual and other
manual that may apply to the product.
Signal Words in Manuals
The signal word WARNING is used throughout this manual in
the following manner:
DANGER - Immediate hazards which will result in severe person-
al injury or death.
WARNING - Hazards or unsafe practices which could result in
severe personal injury or death.
CAUTION
- Hazards or unsafe practices which may result in
minor personal injury or product or property damage.
NOTE - Used to highlight suggestions which wilt result in en-
hanced installation, reliability, or operation.
The signal word CAUTION is used throughout this manual in
the following manner:
Signal Words on Product
Labeling
Signal words are used in combination with colors and/or pictures
or product labels.
z_
Safety-alert
symbol
When you see this symbol on the unit and in instructions or manu-
als, be alert to the potential for personal injury.
TABLE OF CONTENTS
SAFETY CONSIDERATIONS
...............................
3
INTRODUCTION
.........................................
4
CODES AND STANDARDS
................................
4
SAFETY .................................................
4
GENERAL INSTALLATION
.................................
5
COMBUSTION
AND VENTILATION
AIR .....................
5
DUCT SYSTEMS
.........................................
5
ACOUSTICAL
LINING AND FIBROUS GLASS DUCT ..........
5
GAS PIPING AND GAS PIPE PRESSURE TESTING
..........
5
ELECTRICAL
CONNECTIONS
.............................
5
VENTING
...............................................
5
ELECTROSTATIC
DISCHARGE
(ESD)
PRECAUTIONS
PROCEDURE
.............................
5
LOCATION
..............................................
6
AIR FOR COMBUSTION
AND VENTILATION
.................
8
INSTALLATION ..........................................
10
U PFLOW INSTALLATION
.................................
10
DOWNFLOW
INSTALLATION
.............................
11
HORIZONTAL
INSTALLATION .............................
12
FILTER ARRANGEMENT
.................................
13
AIR DUCTS .............................................
13
GAS PIPING ............................................
16
ELECTRICAL
CONNECTIONS
............................
19
SERVICE AND MAINTENANCE
PROCEDURES
.............
40
SEQUENCE
OF OPERATION
.............................
44
WIRING DIAGRAM
......................................
46
TROUBLESHOOTING
GUIDE .............................
47
IS0 9001
Use of the AHRI Certified
TM Mark indic-
ates a manufacturer's
participation
in the
program. For verification
of certification
for
individual
products,
go to www.ahridirect-
ory.org
.
PERSONAL INJURY, AND/OR PROPERTY
DAMAGE HAZARD
Failure to carefully read and follow this warning could
result in equipment
malfunction,
property damage,
3ersonal injury and/or death.
Installation
or repairs made by unqualified
persons
could
result
in equipment
malfunction,
property
damage, personal injury and/or death.
The information contained in this manual is intended for
use by a qualified service technician familiar with safety
3rocedures and equipped with proper tools and test
instruments.
Installation must conform with local building codes and
with the
Natural
Fuel Gas Code
(NFCG)
NFPA
54/ANSI Z223.1
INSTALLER: Affix these instructions on or adjacent to the furnace.
CONSUMER:
Retain these instructions for future reference.
Portions of the text and tables are reprinted
from NFPA 54/ANSI
Z223.t -2009@), with permission
of National
Fire Protection
Association,
Quincy, MA 02269 and American Gas Association,
Washing-
ton, DC 20001.
This reprinted
material is not the complete
and official position of the NFPA or ANSI, on the referenced
subiect,
which is represented
only
by the standard
in its entirety.
Printed in U.S.A.
441 01 1411 03 May 2012
