Evap.
Inlet Organic
Rate
Concentration Chemical
(ml/min)
10 ppm 0.15 Acetone
10 ppm 0.20 Ethyl
Acetate
10 ppm 0.22 Toluene
If the inlet concentration is decreased to 1 ppm, then the estimated filter life
will be increased by an average factor of 5. Likewise, if the inlet
concentration is increased to 25 ppm, then the estimated filter life will be
decreased by an average factor of 2. Experience with routine use will
establish a predictable filter life that is representative of your specific
chemical work.
Impregnated Carbon Filter Life
To estimate impregnated carbon filter life for acids, formaldehyde-formalin,
and ammonia, use the following chart below. The values in the chart below
are expressed in weight (grams) and volume (milliliters) which can be used to
estimate Filter Life from a known usage.
For example, you estimate that 37% hydrochloric acid is being used at 500
ml per week and want to know how to program the Filter Life timer for a 3'
Paramount. A 3' Paramount uses 40 pounds of impregnated carbon at 17%
estimated life before saturation. 17% of 40 pounds is equivalent to 3060
grams of available carbon. There are 424 g/L of hydrochloric acid in a 37%
solution. Thus, there are 3060 grams/424 g per L or 7.2 Liters (7200 ml) of
hydrochloric acid before saturation. Assuming there are 10 hours of use per
week at 500 ml per week, the expected Final Life is programmed at 140
hours and the Check Life is programmed at 40 hours and it comes from the
following calculation:
(7200 ml/500 ml/week) * 10 hours/week = 144 hours, rounded to 140 hours
37% Hydrochloric Acid
67% Nitric Acid
96% Sulfuric Acid
37% Formaldehyde or Formalin
50% Ammonia Solution
(Ammonium Hydroxide)
Product Service 1-800-522-7658
Organic
Vapor
Estimated
SPGR MW Adsorbed
Filter Life
Filter
Capacity
0.79 58.1 2% 40 hours
0.90 88.1 9% 120 hours
0.87 92.1 20% 240 hours
Impregnated
Carbon
Chemical
Adsorbed
Filter Capacity
17%
12%
11%
10%
10%
Appendix E: Accessories
2' (2 Filters)
Estimated Adsorbed Adsorbed
Check Life Weight Volume
10 hours 135 g 171 ml
30 hours 608 g 675 ml
60 hours 1350 g 1552 ml
2' (2 Filters) 3' (4 Filters)
Adsorbed Adsorbed Adsorbed
Weight Volume Weight
1530 g 3600 ml 3060 g
1080 g 1150 ml 2160 g
990 g 560 ml 1980 g
900 g 2250 ml 1800 g
990 g 1980 ml 1980 g
3' (4 Filters) 4' & 5' (6 Filters)
Adsorbed Adsorbed Adsorbed Adsorbed
Weight Volume Weight Volume
270 g 342 ml 405 g
1216 g 1350 ml 1824 g 2025 ml
2700 g 3104 ml 4050 g 4656 ml
4' & 5' (6 Filters)
Adsorbed Adsorbed Adsorbed
Volume Weight Volume
7200 ml 4590 g 10800 ml
2300 ml 3240 g 3450 ml
1120 ml 2970 g 1680 ml
4500 ml 2700 g 6750 ml
3960 ml 2970 g 5940 ml
69
6' (8 Filters)
Adsorbed Adsorbed
Weight Volume
513 ml 540 g 684 ml
2432 g 2700 ml
5400 g 6208 ml
6' (8 Filters)
Adsorbed Adsorbed
Weight Volume
6120 g 14400 ml
4320 g 4600 ml
3960 g 2240 ml
3600 g 9000 ml
3960 g 7920 ml
