Labconco Paramount 69632 Series User Manual

2'/3'/4'/5'/6' wide ductless enclosures
Table of Contents

Advertisement

User's Manual
Paramount
Models
69632 Series, 2' Widths
69633 Series, 3' Widths
69634 Series, 4' Widths
69635 Series, 5' Widths
69636 Series, 6' Widths
To receive important product updates,
complete your product registration card
online at register.labconco.com
Please read the User's Manual before operating the equipment.
Ductless Enclosures
®
Labconco Corporation
8811 Prospect Avenue
Kansas City, MO 64132-2696
800-821-5525, 816-333-8811
FAX 816-363-0130
E-MAIL
labconco@labconco.com
HOME PAGE www.labconco.com

Advertisement

Table of Contents
loading

Summary of Contents for Labconco Paramount 69632 Series

  • Page 1 User’s Manual Paramount Ductless Enclosures ® Models 69632 Series, 2' Widths 69633 Series, 3' Widths 69634 Series, 4' Widths 69635 Series, 5' Widths 69636 Series, 6' Widths To receive important product updates, complete your product registration card online at register.labconco.com...
  • Page 2 The warranty for all Labconco products will expire one year from date of installation or two years from date of shipment from Labconco, whichever is sooner, except the following;...
  • Page 3: Table Of Contents

    CHAPTER 1: INTRODUCTION CHAPTER 2: PREREQUISITES Support and Stability Requirements Location and Air Current Requirements Exhaust and Blower Requirements Electrical Requirements Space Requirements CHAPTER 3: GETTING STARTED Unpacking the Enclosure Set Up the Ductless Enclosure on a Supporting Structure and Work Surface Install Carbon Filters and/or HEPA Filters Connect the Electrical Supply...
  • Page 4 Maximum Visibility Simple Electrical Connection Safety Precautions Misapplications that Could Result in a Hazardous Situation CHAPTER 5: USING THE DUCTLESS ENCLOSURE Information Center Status Area Operating the Pivoting Sash Starting the Ductless Enclosure The Paramount Touchpad All Program Screens Calibration Program Screens Diagnostic Program Screens User Selectable Features Clock Timer Operation...
  • Page 5 CHAPTER 7: ACCESSORIZING THE DUCTLESS ENCLOSURE Filters Work Surfaces Work Surface with Deck Mounted Valves, Gooseneck, and Cupsink Base Stands, Accessory Shelves, Seismic Supports and Hydraulic Lift Base Stands Storage Cabinets Exhaust Transitions Remote Blowers Exhaust Dampers Utility Shelf Kits and Holders Syringe Pump Kit and Detector Tubes Sash Closures CHAPTER 8: TROUBLESHOOTING...
  • Page 6: Chapter 1: Introduction

    The Paramount Ductless Enclosure is the result of Labconco’s years of experience in the design and manufacture of fume hoods and ductless hoods. The Paramount Ductless Enclosure offers many unique features to enhance safety, performance, and ergonomics.
  • Page 7 The Paramount Ductless Enclosure ships without any filters. Chapter 3: Getting Started and Chapter 6: Maintaining the Ductless Enclosure, must be followed to properly select and install filters. This manual and other technical information is available in PDF format at our website: www.labconco.com. Product Service 1-800-522-7658...
  • Page 8: Chapter 2: Prerequisites

    Before you install the Paramount Ductless Enclosure, you need to prepare your site for installation. A dedicated source of electrical power should be located near the installation site to power the ductless enclosure and other apparatus. Additionally, the enclosure should be strategically placed in the lab to provide efficient workflow.
  • Page 9: Location And Air Current Requirements

    Canopy Exhaust Connection and remote blower listed in Chapter 7. Contact Labconco for blower sizing assistance for exhausting to the outside. Electrical connections are covered in Chapter 2 for this configuration.
  • Page 10 Chapter 2: Prerequisites Airflow Internal Face Noise Enclosure Sash Exterior Exterior Exhaust Model No. Voltage Working Velocity Pressure Width Opening Depth Height Volume Height (fpm) (dbA) (CFM) 6963200 100-115V 22.7" 9.4" 29" 43.7" 6963220 208-230V 22.7" 9.4" 29" 43.7” 6963300 100-115V 22.7"...
  • Page 11: Electrical Requirements

    Chapter 2: Prerequisites Electrical Requirements Standard duplex electrical receptacles should be nearby for connecting the Paramount Ductless Enclosure and other equipment. The enclosures include iris pass-through ports to allow electrical cords through the back of the enclosure without leaving a large hole for contaminants to escape. (See Appendix C for amperage.) There is no provision for controlling a remote blower for exhausting air from the Paramount Ductless Enclosure.
  • Page 12 Now that the site for your Paramount Ductless Enclosure is properly prepared, you are ready to unpack, inspect, install, and validate your system. Read this chapter to learn how to: • Unpack and move the enclosure. • Set up the enclosure with the proper supporting structure and work surface.
  • Page 13: Chapter 3: Getting Started

    Note: The United States Interstate Commerce Commission rules require that claims be filed with the delivery carrier within fifteen (15) days of delivery. Note: Do not return goods without the prior authorization of Labconco. Unauthorized returns will not be accepted.
  • Page 14 Allow a minimum of 1/8" clearance under the head of the screw for positioning the enclosure. For the stainless work surfaces, use a #10-24 x 3/8" hex washer head screw (Labconco part number 1885806). 5. Place the enclosure on the work surface and slide the rear flange and front air foil flanges under the mounting screw heads.
  • Page 15 Chapter 3: Getting Started Figure 3-1 Paramount Ductless Enclosure Installation Product Service 1-800-522-7658...
  • Page 16: Install Carbon Filters And/Or Hepa Filters

    Chapter 3: Getting Started Install Carbon Filters and/or HEPA Filters Refer to Figure 3-2 for a view of the filter loading compartment with the front panel removed. The Paramount Ductless Enclosure ships without filters that must be ordered separately. It is highly recommended that an extra set of new filters be on hand on a continuous basis.
  • Page 17: Connect The Electrical Supply

    Filter Life Timers in the Filter Setup menus described in Chapter 5: Using the Ductless Enclosure. Consult the separate Paramount Chemical Guide, Appendix E: Estimated Filter Life Calculation, and/or Labconco Specialist to determine the filter capacity. Through the use of all three sources, set the Filter Life Timers.
  • Page 18: Initial Safety-First ™ Vapor Sensor Warm Up Period

    Chapter 3: Getting Started ™ Initial Safety-First Vapor Sensor Warm Up Period ™ The Safety-First Vapor Sensor includes a 5V, 0.28W integrated heater and any detectable gas that accumulates during shipment must be driven off the organic sensor over an initial 10-30 minute warm up period with the blower activated.
  • Page 19: Validate The Enclosure

    12". Readings are measured at 5" directly below the upper sash handle. Refer to Chapter 2 for proper airflow volumes for your particular model. The Paramount Ductless Enclosures have been tested at Labconco’s airflow test facility per ASHRAE 110-1995. All enclosures achieve an “as manufactured rating”...
  • Page 20 The Paramount Ductless Enclosure is a self-contained filtered enclosure that protects the operator from specified vapors and particulates through the revolutionary combination of features to enhance safety, performance, and ergonomics. Carbon filters and/or HEPA filters must be installed. All Paramount Ductless Enclosures have the following performance features as illustrated in Figure 4-1: 1.
  • Page 21: Chapter 4: Performance Features And Safety Precautions

    Chapter 4: Performance Features and Safety Precautions Figure 4-1 Performance Features Product Service 1-800-522-7658...
  • Page 22: High Performance Containment

    Chapter 4: Performance Features and Safety Precautions High Performance Containment The Paramount Ductless Enclosures use patented technology to direct air into and through the contaminated air chamber (U.S. Patent 6,461,233). The containment enhancing and aerodynamic designs of the lower Clean- Sweep™...
  • Page 23: Safety-First™ Vapor Sensor

    The Safety-First Vapor Sensor has an optimal detection range of 1-10 ppm. Typical concentrations tested by Labconco for chemicals in separate chemical families are listed in order of sensor sensitivity as follows:...
  • Page 24: Smart-Flow™ Airflow Monitor

    Chapter 4: Performance Features and Safety Precautions Smart-Flow™ Airflow Monitor The Smart-Flow™ Airflow Monitor continuously monitors airflow and displays face velocity. An audible/visual alarm alerts the user to low airflow conditions. The Smart-Flow Airflow Monitor enables the motor speed to automatically adjust for conditions such as temperature, barometric pressure, and filter loading and maintain constant programmed airflow speed.
  • Page 25: Ergonomic Sloped Front

    Chapter 4: Performance Features and Safety Precautions Ergonomic Sloped Front The ergonomic slope provides maximum visibility and comfort, reduces glare, thereby minimizing operator fatigue. The space saving design (U.S. Patent No. D538,941) increases effective laboratory work space, because the impeller and filters are all self-contained within the enclosure and a separate filtered blower unit is not required.
  • Page 26: Maximum Visibility

    Chapter 4: Performance Features and Safety Precautions Maximum Visibility Visibility is maximized on all units with at least 270 degree visibility from both sides and the front pivoting sash. Some 3' and 4' models have 360 degree visibility which is especially useful in classroom demonstrations. See Chapter 2: Prerequisites for model differences and model numbers.
  • Page 27 Paramount. 22. Labconco Filter labels are color coded to match NIOSH respirator types. Only chemicals which can be safely adsorbed/treated with the specific carbon based filters installed or removed by HEPA filters are appropriate for use in this enclosure.
  • Page 28 28. Always refer to the Paramount Chemical Guide and/or the NIOSH Pocket Guide to Chemical Hazards before proceeding. For additional help with filter and chemical selection, contact Labconco at 800-821- 5525 or 816-333-8811. 29. The surface of the HEPA filter is fragile and should not be touched.
  • Page 29: Misapplications That Could Result In A Hazardous Situation

    Chapter 4: Performance Features and Safety Precautions Misapplications that Could Result in a Hazardous Situation There is one scenario where the Paramount’s misapplication could be a part of a hazardous condition. That situation is where; 1. the Inlet Concentration is greater than the exposure limit/TWA, 2.
  • Page 30: Information Center

    Information Center The Information Center is an LCD display located on the control panel. The center’s display is divided into three screens that alternate in normal mode, as shown below to display filter status, estimated filter life, filter type, filter replacement alarms, inflow face velocity, and airflow alarms.
  • Page 31: Chapter 5: Using The Ductless Enclosure

    Chapter 5: Using The Ductless Enclosure Status Area The LCD displays the Paramount Ductless Enclosure’s condition during operation such as the filter types, face velocity, and bar graph to display the remaining filter life in hours. This line can display any of the following messages: Filters OK Both filters are operating properly.
  • Page 32: The Paramount Touchpad

    Chapter 5: Using The Ductless Enclosure The Paramount Touchpad The touchpad of the Paramount Ductless Enclosure is shown below. Take a moment to get familiar with the buttons, their location and function. Also familiarize yourself with the display located on the front. The display will report system functions, such as filter types, filter life, timer displays, filter status, and low airflow alarm messages.
  • Page 33: All Program Screens

    Chapter 5: Using The Ductless Enclosure All Program Screens Product Service 1-800-522-7658...
  • Page 34 Chapter 5: Using The Ductless Enclosure Main Setup Screens Product Service 1-800-522-7658...
  • Page 35 Chapter 5: Using The Ductless Enclosure Filter Setup Program Screens Product Service 1-800-522-7658...
  • Page 36: Calibration Program Screens

    Chapter 5: Using The Ductless Enclosure Calibration Program Screens Product Service 1-800-522-7658...
  • Page 37: Diagnostic Program Screens

    Chapter 5: Using The Ductless Enclosure Diagnostic Program Screens Pressure Sensor Diagnostic Notes: Organic Sensor Diagnostic Notes: X20 CAL example represents a Organic Sensor example represents pressure of 134 with the impeller off sensor S1 calibrated in clean air at 1400 millivolts.
  • Page 38: User Selectable Features

    Chapter 5: Using The Ductless Enclosure User Selectable Features The Paramount Ductless Enclosure offers the user unsurpassed flexibility and convenience. To access the menu, press the “MENU” button. The LCD display panel will show the first level menu. To select from the various menu options press the “▲”...
  • Page 39: Light Lamp Timer And Blower Timer

    Chapter 5: Using The Ductless Enclosure Light Lamp Timer and Blower Timer Both timers allow you to decide whether the fluorescent lamp or blower will operate continuously or for a limited time period that you select. This may be desired for energy-savings as well as a safeguard for light-sensitive materials. Interval When the “interval”...
  • Page 40: Filter Setup Display Options

    The filter check time and filter final life must be selected next for each filter position. Consult Chapter 3, Appendix E, the Labconco Specialist, and the Paramount Chemical Guide for proper program times. Restoring Software Default Settings To restore the default settings to their original configuration: 1.
  • Page 41: If A Check Airflow Activates

    Chapter 5: Using The Ductless Enclosure If a Check Airflow Activates The most common causes of a check airflow alarm are: • Blockage of the inlet perforated baffle or exhaust outlet. • Loading or blockage of the filters resulting in low airflow. •...
  • Page 42 Chapter 5: Using The Ductless Enclosure Work Techniques • Keep all materials a minimum of 4 inches (100 mm) from the inside of the lower air foil, and perform all contaminated operations as far to the rear of the work area as possible. •...
  • Page 43: Routine Maintenance Schedule

    Replacing the carbon filters, HEPA filters, and fluorescent light is the primary routine maintenance required. Review this chapter on maintenance for the following: • Routine Maintenance. • Determination of when to replace carbon filters. • Determination of when to replace HEPA filters. •...
  • Page 44: Chapter 6: Maintaining The Ductless Enclosure

    Chapter 6: Maintaining the Ductless Enclosure Quarterly (or more often as required) • Note the airflow velocity on the display. Determine the actual airflow face velocity through the sash opening of the enclosure where the average reading should be at the specified velocity. (Use calibrated thermal anemometer or other approved apparatus).
  • Page 45 A kit including syringe pump and flexible tubing can be purchased as an accessory from Labconco (Catalog # 6924900). Labconco Customer Service Representatives are supplied with detector tube catalog numbers, as well as telephone numbers to direct you to where to purchase these items.
  • Page 46: Determination Of When To Replace Hepa Filters

    “Time” can be used to anticipate saturation or exposure limit/TWA levels based on prior experience. However, this does not replace the need for sampling. Consult Labconco Specialist for an estimate of carbon filter life based on chemical usage. Refer to Chapter 3 on how to “Set the Filter Life and Filter Check Timers.”...
  • Page 47: Install Carbon Filters And/Or Hepa Filters

    Chapter 6: Maintaining the Ductless Enclosure Install Carbon Filters and/or HEPA Filters Refer to the instructions in Chapter 3 on filter installation during startup. Set Filter Life and Filter Check Timers Refer to the instructions in Chapter 3 on setting the Filter Life and Filter Check Life Timers.
  • Page 48 Chapter 6: Maintaining the Ductless Enclosure Procedure For the ATI 2G Photometer 1. Turn on the photometer and allow it to operate for a minimum of 5 minutes. Leave the valve in the “CLEAR” setting. 2. Press the “ENTER” keypad. Press the “REF” keypad. 3.
  • Page 49: Change The Airflow Face Velocity (If Necessary)

    Sensor” and “Airflow Alarm.” The “Calibration” menus require a password to protect the ductless enclosure integrity and the password can only be obtained from Labconco Product Service for certifier use. The “Airflow Alarm” should be set at 10-20 fpm below the normal operating face velocity and it was tested and shipped at 60 fpm.
  • Page 50: Fluorescent Light Replacement

    Chapter 6: Maintaining the Ductless Enclosure Figure 6-1 Light Replacement Fluorescent Light Replacement 1. Disconnect the power. 2. Locate the small light reflector located under the control panel shown in Figure 6-1. 3. Remove the light reflector by removing two Phillips screws on the bottom of the light reflector.
  • Page 51 Chapter 6: Maintaining the Ductless Enclosure Figure 6-2 Light Replacement Product Service 1-800-522-7658...
  • Page 52: Motorized Impeller Replacement

    Chapter 6: Maintaining the Ductless Enclosure Motorized Impeller Replacement The motorized impeller (ECM) must be replaced as a complete unit; it has over 50,000 hours of useful life as tested. See Appendix A for Replacement Parts Diagram. See Figure 6-3 for a view of the motorized impeller plenum assembly.
  • Page 53: Main Control Board Replacement

    Chapter 6: Maintaining the Ductless Enclosure Main Control Board Replacement If the main control board is replaced, the Paramount must be calibrated per the menu screens in Chapter 5. See Appendix A: Replacement Parts, and reference Figure 6-4. 1. Consult the wiring diagram on the back of the front panel and disconnect all power.
  • Page 54: Organic Sensor Board Replacement

    Organic Sensor Board Replacement If the organic sensor board is replaced, the Paramount must be calibrated for the “Organic Sensor.” Contact Labconco Product Service. See Appendix A: Replacement Parts and reference Figure 6-5. Please note that the 6' Paramount utilizes two organic sensor boards, one for each motorized impeller.
  • Page 55: Filters

    There are several ways to accessorize and/or modify the ductless enclosure for your individual requirements. These include the addition of carbon filters, HEPA filters, work surfaces, impregnated carbon filters, base stands, base stand shelves, storage cabinets, seismic support, exhaust transition, remote blowers, exhaust dampers, utility shelf kits, syringe pump kits, deck mounted valves with work surface and sash closures.
  • Page 56: Chapter 7: Accessorizing The Ductless Enclosure

    Chapter 7: Accessorizing the Ductless Enclosure 2. Work Surfaces An optional work surface is available to attach to the ductless enclosure. The black epoxy work surfaces are contoured to fit the dimensions of the ductless enclosures to contain spills. The stainless work surfaces include a front trough to contain spills.
  • Page 57: Work Surface With Deck Mounted Valves, Gooseneck, And Cupsink

    Chapter 7: Accessorizing the Ductless Enclosure 3. Work Surface with Deck Mounted Valves, Gooseneck, and Cupsink The work surfaces supplied with deck mounted valves allow the convenience of water, air, and vacuum along with a cupsink and cold water gooseneck fixture. NOTE: Work Surfaces with Deck Mounted Service Fixtures cannot be used with a Protector Solvent Cabinet.
  • Page 58: Base Stands, Accessory Shelves, Seismic Supports And Hydraulic Lift Base Stands

    Chapter 7: Accessorizing the Ductless Enclosure 4. Base Stands, Accessory Shelves, Seismic Supports, and Hydraulic Lift Base Stands The following base stands, hydraulic lift base stands, accessory shelves, and seismic supports may be used with the accessory work surfaces to support the Paramount Ductless Enclosures.
  • Page 59: Storage Cabinets

    Chapter 7: Accessorizing the Ductless Enclosure 5. Storage Cabinets The following storage cabinets may be used with the accessory work surfaces to support the Paramount Ductless Enclosures. SOLVENT ACID Size/Description Dual Doors Right Hinge Left Hinge Dual Doors Right Hinge Left Hinge 48"...
  • Page 60: Exhaust Transitions

    Chapter 7: Accessorizing the Ductless Enclosure 6. Exhaust Transitions Canopy Exhaust Transitions connect each motorized impeller for ducting to the outside. The Canopy Exhaust Transition is available for 6" nominal duct (6' Paramount requiring two). The Canopy Exhaust Transition should be sealed to the top of the enclosure with silicone sealant to prevent leaks.
  • Page 61: Remote Blowers

    Chapter 7: Accessorizing the Ductless Enclosure 7. Remote Blowers – used to exhaust to the outside only. 6" nominal ID inlet blower has a 1/4 hp direct drive motor and corrosion-resistant epoxy-coated steel housing and wheel with blower inlet of 6.00" ID. Outlet dimensions are 4.25"...
  • Page 62: Exhaust Dampers

    10" Airtight Damper (10" tall) 9. Utility Shelf Kits and Holders Labconco offers a utility shelf kit part number 3925000 consisting of three shelves to hold items inside the enclosure. One shelf may be used for the printer, one shelf for spatulas and weigh brushes, and one miscellaneous shelf.
  • Page 63: 11. Sash Closures

    Chapter 7: Accessorizing the Ductless Enclosure 11. Sash Closures All Paramount Ductless Enclosures have a standard sash opening at the bottom consisting of 9.4" or 12". Sometimes it is necessary to close the lower sash opening during operating procedures. The Sash Closure consists of bi-fold doors to close the opening.
  • Page 64: Chapter 8: Troubleshooting

    A spare set of filters (s = organic sensor) should always be on hand. Consult Chapters 3, 4, and 5, the Labconco Specialist, and the Chemical Guide for estimated filter life based on specific chemical use. All chemicals have a different estimated filter life based on specific chemical use.
  • Page 65 Chapter 8: Troubleshooting PROBLEM CAUSE CORRECTIVE ACTION Replace filters Organic sensor alarms Organic sensor has detected filter intermittent alarm intermittently and display breakthrough and only 5-10% of filter life occurs reads “Replace Filters-s”, remains. Replace filters with a spare set of s = organic sensor filters stored.
  • Page 66 Chapter 8: Troubleshooting PROBLEM CAUSE CORRECTIVE ACTION Lights do not work Lamp not installed Inspect lamp installation. properly. Lamp wiring Inspect lamp wiring. disconnected. Defective lamp. Replace lamp. Light switch is defective. Replace membrane switch on control panel. Defective electronic Replace ballast.
  • Page 67: Appendix A: Replacement Parts

    The components that are available for your ductless enclosure are listed. The parts shown are the most commonly requested. If other parts are required, please contact Product Service. Item Quantity Part No. Description 6938100 HEPA Filter, 99.99% efficient on 0.3 micron, particulate 6938200 Activated Carbon Filter, Organic Vapor, 7.5 lbs.
  • Page 68 Appendix A: Replacement Parts Item Quantity Part No. Description 6964700 Front Panel, 2' 6964701 Front Panel, 3' 6964702 Front Panel, 4' 6964703 Front Panel, 5' 6964704 Front Panel, 6' 6964101 Label, Front Panel 6964100 Membrane Switch 6964300 ECM Motorized Impeller, 115V 6964301 ECM Motorized Impeller, 230V 1295500...
  • Page 69 Appendix A: Components Product Service 1-800-522-7658...
  • Page 70: Appendix B: Paramount Dimensions

    Models Paramount Description 6963200, -20 2' Short 24.0 22.7 23.4 29.0 43.7 6963300, -20 3' Short 36.0 22.7 23.4 29.0 43.7 6963301, -21 3' Tall 36.0 32.0 23.4 29.0 53.0 12.0 6963302, -21 3' x 360 Visibility 36.0 32.0 23.4 29.0 53.0 12.0...
  • Page 71: Appendix C: Specifications

    This Appendix contains technical information about all the Paramount Ductless Enclosures including electrical specifications and environmental operating conditions. Electrical Specifications • All 2', 3', 4', 5' Paramounts – 100-115V, 5 Amps, 50/60 Hz or 230V, 3 Amps, 50/60 Hz. • 6' Paramounts – 100-115V, 10 Amps, 50/60 Hz or 230V, 5 Amps, 50/60 Hz.
  • Page 72: Appendix D: Quick Chart

    6963401, -02, 6963301, -02, 6963501, -03, 6963601, -03, Model No.’s 6963200, -20 6963300, -20 6963400, -20 -03, -21, -22, -21, -22 -21, -23 -21, -23 Model Size Sash Height from Work Surface 12.0 12.0 12.0 (inches) Total Open Area with Bypass (sq. 1.45 2.20 2.85...
  • Page 73: Appendix E: Estimated Filter Life Calculation

    Furthermore, toluene at 10 ppm used in the 3' Paramount will have a Filter Life of 240 hours. These three chemicals are summarized in the table that follows to show the Filter Life ranges and you should consult the Labconco Specialist and/or Paramount Chemical Guide for further information on other chemicals.
  • Page 74 Appendix E: Accessories 2' (2 Filters) 3' (4 Filters) 4' & 5' (6 Filters) 6' (8 Filters) Organic Evap. Vapor Inlet Organic Estimated Estimated Adsorbed Adsorbed Adsorbed Adsorbed Adsorbed Adsorbed Adsorbed Adsorbed Rate SPGR Adsorbed Concentration Chemical Filter Life Check Life Weight Volume Weight...
  • Page 75: Appendix F: Filtration Efficiency Test Results

    Ductless enclosures require filtration efficiency testing to validate performance. Independent testing, conducted by a consultant and the University of Kansas, concluded the tested filtration efficiency for acetone, ethanol, isopropyl alcohol, toluene and hydrochloric acid was excellent. Filtration capacity is defined as a percentage of the chemical mass adsorbed compared to the total carbon filter weight.
  • Page 76: Acetone

    Appendix F: Filtration Efficiency Test Results (ppm) Concentration Exhaust Acetone Product Service 1-800-522-7658...
  • Page 77: Ethyl Alcohol

    Appendix F: Filtration Efficiency Test Results (ppm) Concentration Exhaust Alcohol Ethyl Product Service 1-800-522-7658...
  • Page 78: Isopropyl Alcohol

    Appendix F: Filtration Efficiency Test Results (ppm) Concentration Exhaust 2-Propanol Product Service 1-800-522-7658...
  • Page 79: Toluene

    Appendix F: Filtration Efficiency Test Results (ppm) Concentration Exhaust Toluene Product Service 1-800-522-7658...
  • Page 80: Hydrochloric Acid

    Appendix F: Filtration Efficiency Test Results (ppm) Concentration Exhaust Product Service 1-800-522-7658...
  • Page 81: Declaration Of Conformity

    I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s). See individual Declaration of Conformity which will be signed by the importer for your country. Place: _______________________________________ (Signature) Date: _______________________________________ (Full Name) _______________________________________ (Position) Labconco P/N 36960-66, Rev. -, ECO E950 Product Service 1-800-522-7658...
