Labconco Purifier 3970200 User Manual

Vertical clean benches
Hide thumbs

Advertisement

Quick Links

User's Manual
Purifier
Vertical Clean Benches
®
Models
3970200, 3970201, 3970203, 3970204, 3970220, 3970221,
3970223, 3970224, 3970300, 3970301, 3970303, 3970304,
3970320, 3970321, 3970323, 3970324, 3970400, 3970401,
3970403, 3970404, 3970420, 3970421, 3970423, 3970424
To receive important product updates,
complete your product registration card
online at register.labconco.com
Please read the User's Manual before operating the equipment.
Labconco Corporation
8811 Prospect Avenue
Kansas City, MO 64132-2696
800-821-5525, 816-333-8811
FAX 816-363-0130
E-MAIL
labconco@labconco.com
HOME PAGE www.labconco.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Purifier 3970200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Labconco Purifier 3970200

Summary of Contents for Labconco Purifier 3970200

  • Page 1 User’s Manual Purifier Vertical Clean Benches ® Models 3970200, 3970201, 3970203, 3970204, 3970220, 3970221, 3970223, 3970224, 3970300, 3970301, 3970303, 3970304, 3970320, 3970321, 3970323, 3970324, 3970400, 3970401, 3970403, 3970404, 3970420, 3970421, 3970423, 3970424 To receive important product updates, complete your product registration card online at register.labconco.com...
  • Page 2 The warranty for all Labconco products will expire one year from date of installation or two years from date of shipment from Labconco, whichever is sooner, except the following;...

  • Page 3: Table Of Contents

    CHAPTER 1: INTRODUCTION ISO Class 5 Definition About This Manual Typographical Conventions CHAPTER 2: PREREQUISITES Support, Vibration & Movement Requirements Location and Air Current Requirements Airflow Specifications Electrical Requirements Space Requirements CHAPTER 3: GETTING STARTED Unpacking the Clean Bench Installing Vertical Clean Bench on a Supporting Structure and Work Surface Verifying HEPA Filter Integrity Connecting the Electrical Supply Source to the Vertical Clean...
  • Page 4 Setting the Downflow Velocity with the Speed Control Adjustment 32 Calibrate and Operate the Airflow Monitor Initial Certification Re-Certification Fluorescent Light Replacement UV Light Replacement (If equipped) Motorized Impeller Replacement Speed Control Replacement CHAPTER 7 ACCESSORIZING & MODIFYING YOUR VERTICAL CLEAN BENCH CHAPTER 8 TROUBLESHOOTING &...
  • Page 5 Congratulations on your purchase of a Labconco Purifier® Vertical Clean Bench. Your enclosure provides product protection. It is the result of Labconco’s more than 30 years experience in manufacturing filtered enclosures. These enclosures will effectively provide product protection from airborne particulate matter. During operation, room air is drawn through the prefilter on top, forced through the blower and then through the HEPA filter and diffuser.

  • Page 6: Chapter 1: Introduction

    Chapter 1: Introduction ISO Class 5 Definition Airborne particulate cleanliness inside any clean bench or enclosure is designated by ISO Class 5, which is equivalent to 3520 particles 0.5 µm or larger per cubic meter of air per ISO Standard 14644-1. ISO Class 5 cleanliness is illustrated in the table to follow and is equivalent to Class 100 air conditions as defined by Federal Standard 209E.

  • Page 7: Typographical Conventions

    Chapter 1: Introduction Chapter 4: Performance Features and Safety Precautions explains how the Purifier Vertical Clean Bench operates and the appropriate precautions you should take when using it. Chapter 5: Appropriate Applications for your Vertical Clean Bench discusses the basic operation of how to prepare, use and shut down your Clean Bench.
  • Page 8 Chapter 1: Introduction with the information following an exclamation icon may result in injury to the user or permanent damage to the enclosure. • Critical information is presented in boldface type in paragraphs that are preceded by the wrench icon. Only a trained certifier or contractor should only perform these operations.
  • Page 9 Before you install the Vertical Clean Bench, you need to prepare your site for installation. You must be certain that the area is level and of solid construction. In addition, a dedicated source of electrical power should be located near the installation site to power the Clean Bench, and other apparatus.

  • Page 10: Chapter 2: Prerequisites

    Chapter 2: Prerequisites Support, Vibration and Movement Requirements At a minimum, the supporting structure usually consists of a base cabinet or base stand and chemically-resistant work surface. Location and Air Current Requirements Purifier Vertical Clean Benches have been designed to provide particulate-free clean air meeting Class 5 conditions by negating typical cross drafts and turbulence within the opening.

  • Page 11: Electrical Requirements

    Chapter 2: Prerequisites Out- Average Flow Outflow Downflow Exhaust Noise Face Enclosure Volume Velocity Velocity Pressure Width Model Description (fpm) (CFM) db(A) (fpm) 53-57 2' Vertical Clean Bench 58-60 60-61 62-63 3' Vertical Clean Bench 58-60 60-62 62-66 66-70 4' Vertical Clean Bench 58-62 60-64 62-66...
  • Page 12 Now that the site for your Vertical Clean Bench is properly prepared, you are ready to unpack, inspect, install, and validate your Clean Bench. Read this chapter to learn how to: • Unpack and move the Clean Bench. • Set up the enclosure with the proper supporting structure and work surface.

  • Page 13: Chapter 3: Getting Started

    (15) DO NOT RETURN GOODS WITHOUT THE days of delivery. PRIOR AUTHORIZATION OF LABCONCO. UNAUTHORIZED RETURNS WILL NOT BE ACCEPTED. IF CLEAN BENCH WAS DAMAGED IN TRANSIT, YOU MUST FILE A CLAIM DIRECTLY WITH THE FREIGHT CARRIER.
  • Page 14 The front of the Clean Bench should be aligned within 0.30" (8 mm) of the front of the work surface. Mounting holes are provided in the Labconco accessory work surfaces to secure the Clean Bench.
  • Page 15 Chapter 3: Getting Started Figure 3-1 Vertical Clean Bench Installation Product Service 1-800-522-7658...

  • Page 16: Verifying Hepa Filter Integrity

    Verifying HEPA Filter Integrity The HEPA filter is shipped installed with the gasket on the downstream side. The HEPA filter is leak checked at Labconco. A second leak check is recommended before using the enclosure and at least annually thereafter. Consult your Safety Officer and Chapter 6 for the HEPA Filter Leak Test.

  • Page 17: Setting The Downflow Velocity With Speed Control Adjustment

    Chapter 3: Getting Started Setting the Downflow Velocity with the Speed Control Adjustment Adjustment of the speed control gives the correct downflow velocity and is located behind the front panel. The downflow velocity should be from 30-65 fpm for Class 100 (ISO class 5) conditions.

  • Page 18: Sealing The Vertical Clean Bench To The Work Surface

    A certified technician should complete validation. The Purifier Vertical Clean Benches have been tested at Labconco before shipment and provide ISO Class 5 clean air conditions inside the enclosure. Labconco also performed extensive performance testing to validate the clean benches for product protection under ISO Class 5 conditions.
  • Page 19 The Purifier Vertical Clean Bench is designed to provide product protection only from airborne particulate matter. During operation, room air is drawn from the top and filtered by the HEPA filter providing Class 5 conditions inside the enclosure. The Purifier Vertical Clean Bench delivers Class 5 air conditions when operating at downflow velocities of 30 to 65 feet per minute.

  • Page 20: Chapter 4: Performance Features And Safety Precautions

    Chapter 4: Performance Features and Safety Precautions Located Behind Located Behind Control Panel Figure 4-1 Product Service 1-800-522-7658...
  • Page 21 Chapter 4: Performance Features and Safety Precautions Figure 4-2 Vertical Clean Bench Airflow Diagram Airflow Switch with Adjustment Screw Optional UV light (Not Shown) Figure 4-2 Vertical Clean Bench Airflow Diagram Product Service 1-800-522-7658...
  • Page 22 Chapter 4: Performance Features and Safety Precautions Figure 4-3 Optional UV Sash Closure Product Service 1-800-522-7658...
  • Page 23 Chapter 4: Performance Features and Safety Precautions 1. Aerodynamic Lower Air Foil allows air to sweep the work surface and promote ISO Class 5 air conditions inside the enclosure. See Figure 4-1. 2. Ergonomic Slope of 10 degrees provides maximum visibility and comfort, reduces glare, thereby minimizing operator fatigue.

  • Page 24: Safety Precautions

    Chapter 4: Performance Features and Safety Precautions 11. Filter Clamping Bolt evenly seals the HEPA filter to the frame of the enclosure. See Figure 4-1 and 4-2. 12. Control Panel. The control panel, which is located above the sash, contains the filter pressure gauge, control switches and electronics.
  • Page 25 Chapter 4: Performance Features and Safety Precautions 2. Use good housekeeping in the Clean Bench at all times. Clean up spills immediately. Periodically clean Clean Bench interior. 3. Do not overload the work surface with apparatus or work material. 4. The Purifier Vertical Clean Bench should never be used with biohazardous materials, toxins, acids, or radionuclides.
  • Page 26 HEPA filter during maintenance. If you suspect that a HEPA filter has been damaged DO NOT use the Clean Bench; contact a local certification agency or Labconco. 16. The HEPA filter in the enclosure will gradually accumulate airborne particulate matter from the room. The rate of accumulation will depend upon the cleanliness of the room air, and the amount of time the Clean Bench is operating.

  • Page 27: Routine Daily Work Procedures

    Now that the installation of your Vertical Clean Bench is completed, you are ready to use it. Read this chapter to learn about: 1. Routine Daily Work Procedures. 2. Suitable Applications. 3. Appropriate HEPA Filter Applications, Suitability and Guidelines. Routine Daily Work Procedures Planning •...

  • Page 28: Chapter 5: Appropriate Applications For Your Vertical Clean Bench

    Chapter 5: Appropriate Applications For Your Vertical Clean Bench • Wear a long sleeved lab coat, rubber gloves and protective eyewear. Wear a protective mask if appropriate. Consult your Safety Officer for additional personal protective equipment recommendations. • Wipe down interior surfaces with a mild household detergent or disinfectant.

  • Page 29: Hepa Filter Applications, Suitability & Guidelines

    Chapter 5: Appropriate Applications For Your Vertical Clean Bench Listed below are suitable applications for HEPA filters. HEPA Filter Applications, Suitability and Guidelines • Procedures traditionally performed on an open bench where a clean Class 5 air environment is now required. •...
  • Page 30 Monitoring airflow and changing the filters are the primary maintenance required. Certification and recertification is also reviewed in Chapter 6. Review this chapter on maintenance for the following: 1. Routine Maintenance. 2. Determination of when to replace the HEPA filters. 3.

  • Page 31: Chapter 6 Maintaining Your Vertical Clean Bench

    Chapter 6: Maintaining Your Vertical Clean Bench Routine Maintenance Schedule Weekly • Wipe down the interior surfaces of the enclosure with a disinfectant or cleaner, depending upon the usage of the unit and allow to dry. • Using a damp cloth, clean the exterior surfaces of the enclosure, particularly the front and top to remove any accumulated dust.

  • Page 32: How To Install A New Hepa Filter

    Chapter 6: Maintaining Your Vertical Clean Bench installations and usage, the HEPA filters will last two to five years before requiring replacement. Replace HEPA filters when downflow velocity drops below the recommended 30-65 fpm velocity and the speed control is adjusted to full speed. Replace HEPA filter if it fails the HEPA Filter Leak Test in Chapter 6.
  • Page 33 Chapter 6: Maintaining Your Vertical Clean Bench Prefilter HEPA Filter Sealing HEPA Filter Surface Filter Clamp Bolt Gasket Side Down as Shown Gasket Front Panel Speed Control Adjustment Screw Figure 6-1 HEPA Filter Changing Diagram & Filter Leak Test Diagram Product Service 1-800-522-7658...

  • Page 34: Hepa Filter Leak Test

    Chapter 6: Maintaining Your Vertical Clean Bench HEPA Filter Leak Test HEPA Purpose After installing the new HEPA filter, the HEPA filter should be leak checked. This test is performed to determine the integrity of the HEPA filter, the filter housing, and the filter seal. Leak testing must be done by a qualified technician with calibrated equipment.
  • Page 35 Chapter 6: Maintaining Your Vertical Clean Bench 4. Using the “^” or “ν” keypads, respectively, increase or decrease the numerical value until it equals 30 (2'), 20 (3'). 15 (4') for the Purifier Vertical Clean Bench enclosure at 55 fpm downflow velocity.

  • Page 36: Calibrate And Operate The Airflow Monitor

    Optional Guardian Airflow Monitor Options Refer to Figure 6-2 for operation and calibration. Labconco Airflow Monitor / Airflow Switch Operation The Guardian Airflow Monitor consists of a circuit board and an airflow switch. This switch indicates airflow as safe or low. It...
  • Page 37 Night Setback allows an external signal to prevent a “low” airflow alarm from occurring (not any different from Alarm Disable above other than the terminology.) • Contact Labconco for ordering information on this special PCB. Calibration 1. Ensure the flow switch and alarm circuit board are installed and operational.
  • Page 38 Chapter 6: Maintaining Your Vertical Clean Bench 6. Over time the HEPA filter will load and eventually slow the downflow velocity. Once the alarm condition is met, simply increase the speed control as outlined in Chapter 6 or replace the HEPA filter if the speed control is maximized.
  • Page 39 Chapter 6: Maintaining Your Vertical Clean Bench Speed Control Light Airflow Monitor LED Reflector Circuit Board Airflow Switch with Adjustment Screw Control Panel Green “Safe” LED Red “Alert” LED with Silence Alarm Button Audible Alarm with Test/Reset Figure 6-2 Guardian Airflow Monitor with Airflow Switch Product Service 1-800-522-7658...

  • Page 40: Initial Certification

    Chapter 6: Maintaining Your Vertical Clean Bench Initial Certification The Purifier Vertical Clean Bench has been certified at the factory for an average downflow velocity of 40-55 fpm along with the HEPA Filter Leak Test. The Purifier Vertical Clean Bench should be certified for the proper downflow velocity required by your Safety Officer.

  • Page 41: Uv Light Replacement (If Equipped)

    Chapter 6: Maintaining Your Vertical Clean Bench UV Light Replacement (if equipped) 1. Disconnect the power. 2. Locate the UV lamp located inside the enclosure. 3. Rotate and remove the old UV lamp. 4. Reinstall the new UV lamp. 5. Power the unit up and try the new UV lamp. Motorized Impeller Replacement The motorized impeller must be replaced as a complete unit.
  • Page 42 Chapter 6: Maintaining Your Vertical Clean Bench Mounting Screws HEPA Filter for Motorized 2' Model Impeller Capacitor Mounted here on Electrical Subassembly Motorized Located behind Impeller the Control Panel Wire Access Hole Impeller Mounting Bracket Hardware Front Panel Wire Access Holes Motorized Impellers...

  • Page 43: Speed Control Replacement

    Chapter 6: Maintaining Your Vertical Clean Bench Speed Control Replacement 1. Remove the bracket that the speed control is attached to. See Figures 6-1, and 6-2. 2. Remove the two screws holding the speed control using a Phillips screwdriver. Refer to Appendix A for Replacement Parts Diagram.

  • Page 44: Vertical Clean Bench

    There are several ways to accessorize and modify the Vertical Clean Bench for your individual requirements. These include the addition of accessory work surfaces, airflow monitors, filters, and storage cabinets or stands. 1. Work Surfaces An optional dished work surface is available to attach to the Vertical Clean Bench.

  • Page 45: Chapter 7 Accessorizing & Modifying Your Vertical Clean Bench

    Chapter 7: Accessorizing and Modifying Your Vertical Clean Bench 2. Guardian™ Airflow Monitor The Guardian Airflow Monitor allows you to continuously monitor airflow through the Clean Bench. The Guardian monitor can be placed on any Purifier Vertical Clean Bench. Description Order Part #’s Individual Parts Required Guardian Airflow Monitor...
  • Page 46 Chapter 7: Accessorizing and Modifying Your Vertical Clean Bench 4. Storage Cabinets and Stands SOLVENT ACID Size/Description Dual Doors Right Hinge Left Hinge Dual Doors Right Hinge Left Hinge 48" 9902000 9901000 36" 9902100 9901100 30" 9902200 9901200 24" 9902300 9902400 9901300 9901500...
  • Page 47 Chapter 7: Accessorizing and Modifying Your Vertical Clean Bench 5. IV Bar Kits For pharmacy applications, IV Bar Kits support intravenous bottles and bags. 3721000 2' IV Bar Kit 3721001 3' IV Bar Kit 3721002 4' IV Bar Kit Product Service 1-800-522-7658...
  • Page 48 Refer to the following table if your Vertical Clean Bench fails to operate properly. If the suggested corrective actions do not solve your problem, contact Labconco for additional assistance. PROBLEM CAUSE CORRECTIVE ACTION Class 5 air conditions Improper user See “Certifying the Enclosure” Chapter...

  • Page 49: Chapter 8 Troubleshooting & Servicer

    Chapter 8: Troubleshooting PROBLEM CAUSE CORRECTIVE ACTION Blower won’t Unit not plugged Plug the enclosure into appropriate operate. into outlet. electrical service. Circuit breaker(s) Reset circuit breaker. or ground fault Interrupter. Blower wiring is Inspect blower wiring. disconnected. Blower switch is Replace switch.
  • Page 50 Chapter 8: Troubleshooting PROBLEM CAUSE CORRECTIVE ACTION Airflow Monitor Wrong alarm set Airflow monitor was not properly Malfunction point. adjusted. Repeat calibration steps (Continued) outlined in this manual in Chapter 6. Constant audible Check airflow and calibration of alarm. airflow monitor. See Chapter 6. Continuous alarm.
  • Page 51 Chapter 8: Troubleshooting Service Operating Record Log Customer Name Model Number Date Installed Serial Number Unit Location Date Comments Product Service 1-800-522-7658...
  • Page 52 The components that are available for your Vertical Clean Bench are listed. The parts shown are the most commonly requested. If other parts are required, please contact Product Service. Product Service 1-800-522-7658...

  • Page 53: Appendix A: Vertical Clean Bench Components And Replacement Parts

    Appendix A: Vertical Clean Bench Components and Replacement Parts Item Qty. Part Number Description 3911000 Glass, Side 3911900 Glass, Sash 2' 3911901 Glass, Sash 3' 3911902 Glass, Sash 4' 3938900 Sash Assembly, 2' 3938901 Sash Assembly, 3' 3938902 Sash Assembly, 4' 3905600 Lower Air Foil, 2' 3905601...
  • Page 54 Appendix A: Vertical Clean Bench Components and Replacement Parts Item Qty. Part Number Description 3937900 Wiring Harness Main, 115V, 2' 3937901 Wiring Harness Main, 230V, 2' 3938000 Wiring Harness, 115V, 3' and 4' 3938001 Wiring Harness, 230V, 3' and 4' 3811500 Guardian Airflow Monitor Printed Circuit Board 1885405...
  • Page 55 Appendix A: Vertical Clean Bench Components and Replacement Parts Item Qty. Part Number Description 1893712 Screw, #10 x .75 PH Phil. Thd. Forming 1881196 Capscrew, 3/8 –16 x 6.0 Lg. Hx. Hd. 1911018 Washer, Flat 3/8 1906925 Nut, Hex 3/8 Nylon Lock 3707900 HEPA Filter (2') 18 x 18 x 3.32 w/ Gasket 3707901...
  • Page 56 Appendix A: Vertical Clean Bench Components and Replacement Parts Fluorescent 35, 36 Shown 12, Not Shown Figure A-1 Replacement Parts, Purifier Vertical Clean Benches Product Service 1-800-522-7658...
  • Page 57 See the following dimensions for the Purifier Vertical Clean Benches. Product Service 1-800-522-7658...

  • Page 58: Appendix B: Dimensions

    Appendix B: Dimensions Figure B-1 Purifier Vertical Clean Bench Product Service 1-800-522-7658...
  • Page 59 This Appendix contains technical information about all the Purifier Vertical Clean Benches including electrical specifications, environmental operating conditions and wiring diagrams. • 5 Amps, 115V, 60 Hz or 3 Amps, 230V, 50/60 Hz, Purifier Vertical Clean Bench. Environmental Conditions • Indoor use only. •...

  • Page 60: Appendix C: Vertical Clean Bench Specifications

    Appendix C: Vertical Clean Bench Specifications Product Service 1-800-522-7658...
  • Page 61 Appendix C: Vertical Clean Bench Specifications Product Service 1-800-522-7658...
  • Page 62 Appendix C: Vertical Clean Bench Specifications Product Service 1-800-522-7658...
  • Page 63 Appendix C: Vertical Clean Bench Specifications Product Service 1-800-522-7658...

  • Page 64: Appendix D: References

    Many excellent reference texts and booklets are currently available. The following is a brief listing: Bryan, D., and R.C. Marback. 1984. Laminar-airflow equipment certification: What the Pharmacist needs to Know. American Journal of Hospital Pharmacy. 41.1343- 1348. General Services Administration. 1988. FED-STD-209E Federal Standard –...

  • Page 65: Declaration Of Conformity

    See individual Declaration of Conformity, which will be signed by the importer for your country. Place: _______________________________________ (Signature) Date: _______________________________________ (Full Name) _______________________________________ (Position) *An individual version of this declaration is included with your shipping/customs documentation. Labconco P/N 36960-52 REV - Product Service 1-800-522-7658...
