Room Air Conditioners
R410A Split Type – Nouveau Series
DC INVERTER
ECO930SDN
ECO1230SDN
• Please read this installation manual completely before installing the product.
• When the power cord is damaged, replacement work shall be performed by
authorized personnel only.
• Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
• Contact the authorised service technician for repair or maintenance of this unit.
Register your air conditioner
Model information can be found on the CE
label.
Please register your product online at
www.ecoair.org. For your future
convenience, record the model information
below.
____________________________________
MODEL NUMBER
____________________________________
SERIAL NUMBER
____________________________________
PURCHASE DATE
1
Advertisement
Table of Contents
Related Manuals for Ecoair Nouveau ECO930SDN
Summary of Contents for Ecoair Nouveau ECO930SDN
- Page 1 Room Air Conditioners R410A Split Type – Nouveau Series DC INVERTER ECO930SDN ECO1230SDN • Please read this installation manual completely before installing the product. • When the power cord is damaged, replacement work shall be performed by authorized personnel only.
- Page 2 Congratulations! You have purchased the very latest in room air conditioner technology. Your new EcoAir high efficiency room air conditioner will give you many years of dependable service. Many features have been built into your EcoAir air conditioner to assure quiet operation, the best circulation of cool, dry air, functional controls, and the most economical operation.
-
Page 3: Table Of Contents
Table of contents Disposal Safety Precautions Parts Identification Special Function Manual Operation Adjusting Air Flow Direction Optimal Operation How the Air Conditioner works Operating Tips Cleaning and Maintenance Troubleshooting Tips Inside you will find many helpful hints on how to use and maintain your air conditioner properly. -
Page 4: Disposal
Disposal When using this air conditioner in the European countries, the follow information must be followed: DISPOSAL: Do not dispose this product as unsorted waste. It is prohibited to dispose of this appliance in domestic household waste. For disposal: A) Contact your local council for disposal. B) The manufacture will take back the old appliance for disposal when you replace with a new product. -
Page 5: Safety Precautions
Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury. - Page 6 CAUTION When the air filter is to be Do not clean the air Ventilate the room well when used together with a removed, do not touch the conditioner with water. stove, etc. metal parts of the unit. It may cause an injury. Water may enter the unit and An oxygen shortage may occur.
- Page 7 Preparing for operation 1. Contact an installation specialist for installation. 2. Plug in the power plug properly. 3. Do not use a damaged or non-standard power cord. 4. Do not share the same outlet with other appliances. 5. Do not use an extension cord. 6.
-
Page 8: Parts Identification
____________________________________________________________________________________ Parts Identification Indoor Unit Outdoor Unit Front panel frame 12 Connecting pipe Rear air intake grille 13 Connective Front panel cable Air Purifying filter & Air 14 Stop valve filter 15 Fan hood Horizontal airflow grille LCD display window Vertical airflow grille Manual control switch Drain pipe... -
Page 9: Special Function
____________________________________________________________________________________ Special Function CLEAN AIR function (on some models) Improving the quality of indoor air is one of the mission of an air conditioner. This air conditioner is equipped with ionizer or Plasma Dust Collector (Depending on specific configuration of the model). With the anions generated by Ionizer, the air circulation of the air conditioner fills the room with refreshing, natural and healthy air. -
Page 10: Manual Operation
____________________________________________________________________________________ Manual Operation NOTE: The unit must be turned off before operating the manual control button. If the unit is operational, continue pressing the manual control button until the unit is off. Grasp both sides of the panel and pull it down, the °... -
Page 11: Optimal Operation
____________________________________________________________________________________ CAUTION The SWING buttons will be disabled when the air conditioner is • not in operation. Do not operate the air conditioner for long periods with the air • flow direction set downward in cooling or dry mode. Otherwise, condensation may occur on the surface of the horizontal louvre causing moisture to drop on to the floor or furnishing. -
Page 12: How The Air Conditioner Works
____________________________________________________________________________________ How The Air Conditioner Works AUTO operation When you set the air conditioner in AUTO mode, it will • automatically select cooling, heating (cooling/heating models only), or fan only operation depending on what temperature you have selected and the room temperature. The air conditioner will control room temperature automatically round the temperature point set by you. - Page 13 ____________________________________________________________________________________ 2. A white mist coming out from the indoor unit A white mist may generate due to a large temperature difference between air inlet and air outlet on COOL • mode in an indoor environment that has a high relative humidity. A white mist may generate due to moisture generated from defrosting process when the air conditioner •...
-
Page 14: Cleaning And Maintenance
____________________________________________________________________________________ Cleaning and Maintenance WARNING It is necessary to stop the air conditioner and disconnect the power supply before cleaning. Cleaning Indoor Unit & Remote Controller CAUTION Use a dry cloth to wipe the indoor unit and remote controller. A cloth dampened with cold water may be used on the indoor unit if it is very dirty. - Page 15 ____________________________________________________________________________________ Take hold of the handle of the air filter and lift it up slightly to take it out from the filter holder, and then pull it downwards. Remove the AIR FILTER from the indoor unit. Clean the AIR FILTER once two weeks.
-
Page 16: Troubleshooting Tips
____________________________________________________________________________________ Troubleshooting tips Malfunctions and Solutions Stop the air conditioner immediately if one of the following faults occurs. Disconnect the power and contact the nearest customer service centre. OPERATION indicator or other indicators flash rapidly (5 times every second) and this flash can't be fixed by disconnecting the power, and then connect it in again. - Page 17 ____________________________________________________________________________________ ONE (1) YEAR LIMITED WARRANTY SAVE THIS WARRANTY INFORMATION EcoAir guarantees this product free from defects in materials and workmanship for a period of one (1) year from the date of purchase, limited to parts only. Faults arising from a faulty installation is specifically excluded. This unit must be operated under conditions as recommended, at voltages indicated on the unit.
