Summary of Contents for Gefen GBT-HDBT-POL
- Page 1 3GSDI Audio Embedder Extender for HDMI GBT-HDBT-POL User Manual Release A5...
-
Page 2: Important Safety Information
Extender for HDMI w/POL Important Safety Information Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this product near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 3: Warranty Information
Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications. - Page 4 Extender for HDMI w/ POL is a trademark of Gefen, LLC. Important Notice Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing in the United States and other countries.
- Page 5 This product is Ultra HD 4K x 2K compliant. 4K x 2K resolutions can be extended up to 130 feet (40 meters) over a CAT-5e cable. • POL (Power Over Line) technology from Gefen sends power to the Receiver unit over the same CAT-5e / CAT-6 cable that is used for extending the HDMI signal. •...
- Page 6 ► CEC pass-through ► Lip Sync pass-through • Bi-Directional IR remote control of devices • Gefen POL feature provides power to the Receiver unit over the CAT-5e • Uses HDBaseT® Technology • Locking power connector • Easy surface mounting •...
-
Page 7: Packing List
Packing List The Extender for HDMI w/ POL ships with the items listed below. If any of these items are not present in your box when you first open it, immediately contact your dealer or Gefen. • 1 x Extender for HDMI w/POL - Sender unit •... -
Page 8: Table Of Contents
Extender for HDMI w/POL Table of Contents Getting Started Sender Unit Layout....................2 Front ......................2 Back ......................3 Receiver Unit Layout ..................... 4 Front ......................4 Back ......................5 Installation ......................6 Connecting the Extender for HDMI w/ POL ..........6 Sample Wiring Diagram ................ -
Page 11: 01 Getting Started
Extender for HDMI 01 Getting Started Sender Unit Layout....................2 Front ......................2 Back ......................3 Receiver Unit Layout ..................... 4 Front ......................4 Back ......................5 Installation ......................6 Connecting the Extender for HDMI w/ POL ..........6 Sample Wiring Diagram ................6... -
Page 12: Sender Unit Layout
Sender Unit Layout Front Name Description IR Out Connect the included single infrared IR emitter (Gefen part no. GTB-IREMIT) from this jack to the IR sensor window of the source. Link Connect a CAT-5e / CAT-6 cable from this port to the Receiver unit. -
Page 13: Back
Getting Started Sender Unit Layout Back Name Description 24V DC Connect the included 24V DC power supply to this connector and plug the AC power cord into an available electrical outlet. Only use the power supply shipped with this unit. Power This LED will turn on once the included 24V DC power supply has been connected. -
Page 14: Receiver Unit Layout
Receiver Unit Layout Front Name Description IR Out Connect the included single infrared IR emitter (Gefen part no. GTB-IREMIT) from this jack to the IR sensor window of the source. Link Connect a CAT-5e / CAT-6 cable from this port to the Sender unit. -
Page 15: Back
Getting Started Receiver Unit Layout Back Name Description Power This LED will turn on once the included 24V DC power supply has been connected to the Sender unit and a CAT-5e / CAT-6 cable is connected between the Sender and Receiver unit. See Power LED Indicator for more information on using the LED indicator. -
Page 16: Installation
Connect the included 24V DC power supply to the Sender unit and plug the AC power cord into an available electrical outlet. Power to the Receiver unit is delivered from the Sender unit over the CAT-5e/CAT-6 cable using Gefen POL technology. For information on using IR control, see... -
Page 19: Operating The Extender For Hdmi W/ Pol
Extender for HDMI 02 Operating the Extender for HDMI w/ POL Power LED Indicator ................... 10 Using Bi-Drectional IR ..................11 Controlling the Source ................. 11 Controlling the Display ................12... -
Page 20: Power Led Indicator
Operating the Extender for HDMI w/POL Power LED Indicator The Power LED indicator on the Sender and Receiver unit provides basic information on the current status of the Extender for HDMI w/ POL. Status Description Power Solid blue • Power connected to Sender unit. •... -
Page 21: Using Bi-Drectional Ir
The source device can be controlled from the viewing location by connecting an IR Extender (Gefen part no. EXT-RMT-EXTIRC or EXT-RMT-EXTIRN) to the Receiver unit. The display can also be controlled from the source location by connecting an automation system with electrical IR outputs to the Sender unit (see the following page). -
Page 22: Controlling The Display
Operating the Extender for HDMI w/POL Using Bi-Directional IR Controlling the Display Connect a 3.5mm-to-3.5mm mini-mono cable from one of the electrical IR emitter jacks, on the automation system, to the IR In jack on the Sender unit Connect an IR emitter from the IR Out jack on the Receiver unit to IR sensor on the display. -
Page 25: 03 Appendix
Extender for HDMI 03 Appendix Network Cable Diagram ..................16 Wall Mounting Instructions .................. 17 Specifications ...................... 18... -
Page 26: Network Cable Diagram
Shielded (STP) CAT-5 or CAT-6 is recommended. However, unshielded (UTP) CAT-5 or CAT-6 is acceptable. CAT-5, CAT-5e, and CAT-6 cabling comes in stranded and solid core types. Gefen recommends using solid core cabling. CAT-6 cable is also recommended. It is recommended to use one continuous run from one end to the other. Patch cable is not recommended. -
Page 27: Wall Mounting Instructions
Appendix Wall Mounting Instructions The GefenToolbox Extender for HDMI w/POL should be mounted vertically on a wall or inside / outside a cabinet with wood / drywall screws as shown in the diagram above. There should be an inch or two of clearance between the edges of the unit and any walls or vertical surfaces to allow for enough clearance for connection and disconnection of the HDMI cable. -
Page 28: Specifications
Appendix Specifications Supported Formats Video • 1080p Full HD • 4K x 2K (Ultra HD) Audio • 7.1-channel LPCM • Dolby® TrueHD • DTS-HD Master Audio™ Electrical Maximum Pixel Clock • 300 MHz Maximum TMDS Clock • 300 MHz Power / HDCP Indicator •... - Page 30 Stretch it. Switch it. Split it. Gefen’s got it. ® 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefentoolbox.com support@gefentoolbox.com This product uses UL listed or CE compliant power supplies.
