THE CHANNEL LIST

Press the soft key or to sequence to the channel list
screen.
Tip
In addition to using the and keys, you can also use the
left and right arrows to sequence through the results screens.
The channel list provides essential information about each channel.
In the list you will find the channel number in the first column
followed by the label. The level of the video carrier is in the next
column. The package in which the channel is contained is dis-
played in the fourth column. Finally, the overall limits pass/fail
result for the channel is found in the last column.

THE PASS/FAIL INDICATOR

Use the PASS/FAIL indicator located directly above the channel
list to quickly determine whether the highlighted channel has
passed the limits check. If the channel failed, you can identify the
reason(s) for the failure by looking at the symbols that appear in this
indicator.
28
