- Page 1 Robot Vacuum Cleaner 7 Series User Guide...
- Page 3 Thanks for purchasing patented Robot Vacuum Cleaner products Hope you can enjoy it Thanks again for your choice!
-
Page 5: Table Of Contents
E n j o y S m a r t e r L i f e ! Content This User Guide is for all Deebot 7Series products ..... 10.Remote Control........1. Safety Instruction............User Guide......Battery Placement.............. -
Page 6: Safety Instruction
1.Safety Instruction ： War ning Where there is a drop off in the cleaning area due to a step or stairs and they are not carpeted, you should operate the unit to see that the Guardrail Guardrail unit can detect the step without falling over the edge. It may become necessary to place a physical barrier at the edge to keep the unit from falling over the drop but make sure the physical barrier is high enough so that you or a family member will not trip on the barrier and cause themselves injury. -
Page 7: The Spectrum Of Product Use
E n j o y S m a r t e r L i f e ! The Spectrum of the Product Use ● This robot is applicable to domestic sweeping, including wooden floor, ceramic tile ceramic tile rubber floor, ceramic tile, linoleum and medium or short-haired carpet short-haired carpe however, it is inapplicable to long-haired carpet. -
Page 8: Notes Before Cleaning
Notes before Cleaning ● Take extra care of the robot when the first it works. Please remove the obstacles when it is beyond the robot. Try to avoid the situation that the robot stops working. ● Make precautions to solve the problem which may make the cleaning in trouble, such as: ---- Keep the easily knock over objects in a safe place. -
Page 9: Battery Replacement And Disposal
E n j o y S m a r t e r L i f e ! ● Take good care of the product and keep it beyond child and people who can not judge danger nearby. Extra attention should be paid when it starts working. -
Page 10: Content In The Original Package And Technical Parameter
2.Cont ent ( For D73 ) Charging block Virtual wall Main Unit spot edge auto Robot Vacuum Cleaner return intensive Battery for virtual wall 7 Series User Guide control Battery for remote Remote control User Guide Roll brush clean-up Magnetic adding tool Border tape gadget... -
Page 11: The Host
E n j o y S m a r t e r L i f e ! technique parameter The host The charging block Working voltage In-put voltage DC12V AC220-240V Rated power rated out-put voltage DC14.5V Speed rated frequency 0.25m/s 50Hz Capacity of dust box rated power... -
Page 12: User Guide
2.Content(For D76) Robot Vacuum Cleaner 7 Se ri es U se r Gu id e Main Unit Charge Station User Guide Magnetism recovery tool Telescopic tube Remote control battery Hose 2 in 1 brush crevice tool Remote control Wall&ceiling brush Virtual wall Handheld belt Rolling brush cleaning tools... -
Page 13: Parts Descripition
E n j o y S m a r t e r L i f e ! 3.Parts Description(For D73) Main Unit up-ground height sensor control button wind gate All-round rotating side brush wheel welted induction infrared main brush suspended receiver driving wheel rubber scraper... - Page 14 3.Parts Description（For D76） Main Unit is the same as D73 Handheld vacuum cleaner release button Dust container power slot Infrared signal generator Dust inlet hole Charging pin Air outlet grid Charging station Charging power cord indicator Dust inlet hole Anti-slip slots Charge station ( Front view) Charging station ( Top view) Dust container handle...
-
Page 15: Lcd And Control Panel
E n j o y S m a r t e r L i f e ! LCD and Control Panel mode Power Demo mode 13. Keep timing cleaning 19. Battery display Model selection Border cleaning mode 14. One-time timing cleaning 20. -
Page 16: Charging
Tangle the power cord on the pothook and do not scatter it besides the block or hold it under the base, in case that robot would get impeded when it turns back. There should not be any object at least 1.5 meter in front of the charging block. -
Page 17: Power On/Pause/Power Off
E n j o y S m a r t e r L i f e ! 5.Power On/Pause/Power Off Get power supply and power on ● Turn on the power switch on the bottom firstly. ● Press the key on host and get power supply. There would be a short music tip and at the same time LCD lights for roughly 2 second and goes off. -
Page 18: Mode Selection
Tips : Put the robot on the charging block and keep it charging after finishing house cleaning. Do not keep the robot on pause status for long time, because under pause, the full charged battery can only last for around 20 hours. -
Page 19: Fixed Point Cleaning Mode
E n j o y S m a r t e r L i f e ! Under this status, robot helps to remove the corner of wall, table, sofa and bed where it is beyond the mode of automatic cleaning. The operation of this mode takes around 25 minutes and then robot goes back to charging block by itself. -
Page 20: Automatic Charging
7.Automatically charging ● When it finishes cleaning or there is low battery, it would seek charger in same route as automatic cleaning.To make it easy for robot to search for charging block, you need to put the block back to the wall and make sure there is no obstacle within 1.5 meters ahead ？... -
Page 21: Appointment Timing
E n j o y S m a r t e r L i f e ! 9. Appointment Timing Appointment time setting 1. After power is on, keep press First time setting around 3 seconds then on LCD is light and the number with time setting is flashing. -
Page 22: Set Frequency And Cancel Timing
Current time setting 1. After second time setting, and then go to the current time setting. The disappeared, mode and the number with time setting flashing. 2. Set hour and minute via and , each time press will increase one hour or minute. While decrease one hour and minute for mode ,and then press... -
Page 23: Remote Control
E n j o y S m a r t e r L i f e ! 10.Remote Control Batter y placement Tips: It applies two units of alkaline batteries (7#) Please note the positive and negative when place the battery Change the battery when you notice it is in low battery and make sure you use the same kind of battery as mixture is forbidden. -
Page 24: Virtual Wall
Note: When you use virtual wall, please face marked ECOVACS to the block area you expect. Put virtual wall outside of the room you want to block to get best effect. The system would cancel virtual wall after it is set for two hours in order to save battery. As a result, every time the robot start new task and there needs to use virtual wall, please do and check whether the switch on virtual wall is on and there is indicator. -
Page 25: Use Of Virtual Wall
E n j o y S m a r t e r L i f e ! Power: Press this key and virtual wall starts work which will prevent robot Infrared receiver from entering the blocked region. power Indicator: It is red when the power is on, and it shows virtual wall is ejecting Indicator invisible beam to prevent robot form entering the blocked region. -
Page 26: Day-To-Day Storage
Paste the Border Tape on the floor after tearing off the white layer on one side. Rub the Border Tape with Border Enhancement Tool. Attention: Deebot Do not paste the Border Tape within a 1.5-meter radius vicinity of the Charging Station, or will not be able to return for charging. -
Page 27: Handheld Vacuvm Cleaner (For D76)
E n j o y S m a r t e r L i f e ! 15.Handheld vacuum cleaner ( For D76) By using the handheld vacuum cleaner , you can extend Deebot’s function and cleaner your home more thoroughly. Assemble the handheld vacuum cleaner Attention: Press the “... -
Page 28: Maintenance
Adjusting telescopic length : push the button on the telescopic tube and adjust the tube to the desired length simultaneously and then release the adjusting button until you hear the Click sound which indicates the tube Kaka length has been fixed. Different accessories can be fixed onto the end of the telescopic tube for different use. - Page 29 E n j o y S m a r t e r L i f e ! Hold the handle of In order to avoid dust dust box and lift it to leaking, lift the suction take out. up when you take out dust box.
-
Page 30: Sponge Filter And Dust Box Cleaning
Sponge Filter Replacement 1. Open the cover of the Deebot, take out the dust box. 2. Push aside the lock catch of the dust box, then open the dust box and clean it. 3. Extract the axle of the dust box’s cover. -
Page 31: Dust Container Assembly
Dust container cleaning Under normal situation , the dust container only need to be cleaned once per week (depending on you house situation). If you use the handheld vacuum cleaner separately , we suggest you to clean the dust container each time after your use. - Page 32 E n j o y S m a r t e r L i f e ! Tap the filtration assembly gently to get rid of the attached dust. Take the sponge out of the filtration assembly. If needed , the filtration assembly can be cleaned under tap-water. Don’t use brush to clean to avoid breakage.
-
Page 33: Side Brush Cleaning
E n j o y S m a r t e r L i f e ! Side brush cleaning Side brush is a kind of easy wear part. We suggest you to check it every time it takes cleaning task. Please change it if necessary. Note：... -
Page 34: Dust Sensor Cleaning
Your Robot is fitted with two 6V 2500mAah Ni-MH battery packs. The battery packs must be replaced together. Never mix an old Battery pack with a new Battery pack. Only use ECOVACS approved replacement parts for your Robot. Use of parts that are not approved by ECOVACS are dangerous and will invalidate your warranty. -
Page 35: Alarm Function
E n j o y S m a r t e r L i f e ! 17. Alarm function Note: The robot will stop working under following circumstance; there will be alarm and tip sound at the same time. What's more, LCD will have red light flashing. -
Page 36: Common Failure
18. Common Failure Problem Solution Turn off the power. 1. Check if there is dust on up-ground height sensor, which cause robot to make wrong Robot keeps proceeding or moving signal. Use half dry cloth to clean it. backward once power is on. Buffer collision is out of control. -
Page 37: Other Problems
E n j o y S m a r t e r L i f e ! E n j o y S m a r t e r L i f e ! Turn off the power supply, and then take out of dust box. - Page 38 cleaned for long time, as it is tangled with automatic and border cleaning mode. Its much hair and dust. side brush can remove dust along bottom edge efficiently; there would be dust beyond Why does robot fail to start cleaning on robot in the tiny area formed by two walls appointment time? which need to be removed by hand..
- Page 39 E n j o y S m a r t e r L i f e ! How does main brush avoid being tangled How to clean the LCD screen? by power cord? Answer: Please clean the screen with soft Answer: Robot is probably get tangled by the dry cloth to wipe away the fingerprint or wire scattered on the floor when it is...
- Page 40 E n j o y S m a r t e r L i f e ! D7S-000IM2011/02...
