Names of the parts

Honourable users,
Thank you for choosing our products.
Our products integrate high-tech, precision,frontier science.To facilitate
using it, please read this manual carefully and operate this machine
according to it.
Top lid B
Detergent box
Lint filter
Control panel
Filter cover
Inner tub
Control panel
film
Pulsator
Cabinet
base frame
Accessories
the end connecting to
the washing machine
jointer connecting the
water inlet hose and
the water faucet
the end connecting to
the water inlet hose jointer
Top lid A
Cabinet handle
Drain hose
Adjustable foot
seam
Adjustable foot
Meaning and description of the symbols
Warning sign
bottom plate
(one)
water inlet hose
(one)
Water inlet
hose jointer
(one)
Forbidden sign
tapping screws
ST4X16
(eight)

Before Using

Before Using
water valve
Sop mat
Contents marked with that symbol
are related to the safety of the
product and the personal safety
of the users. Please operate in
strict conformity to the contents,
otherwise it may cause damage
of the machine or injure the
personal safety of the user.
Contents marked with that symbol
are actions forbidden to perform.
Performing of those actions may
result in damage of the machine
or injure the personal safety of
the user.
Power line
back cover
