Haier XQB50-10A User Manual

Haier automatic washing machine user's manual
Hide thumbs

Advertisement

Automatic Washing Machine
User's manual
This manual is for
XQB50-10A
Please read this manual
carefully before using.
Retain it for future reference.

Advertisement

loading

  Related Manuals for Haier XQB50-10A

  Summary of Contents for Haier XQB50-10A

  • Page 1 Automatic Washing Machine User's manual This manual is for XQB50-10A Please read this manual carefully before using. Retain it for future reference.
  • Page 2: Table Of Contents

    Contents Names of the parts...the 2 cover Safety precautions ...1 Installation and adjustment ...3 Install the water inlet hose...5 Using process Preparation before washing ...6 Put in the laundries ...7 Put in the detergent ...8 Use the operation buttons ...9 Close the top lid ...13 Finish washing ...14 Disposal after washing ...14...
  • Page 3: Names Of The Parts

    Names of the parts Top lid B Detergent box (Installed by user) Lint filter Control panel Filter cover Inner tub Control panel film Pulsator Cabinet base frame Accessories Top lid A Sop mat Cabinet handle Drain hose Adjustable foot Bottom plate Meaning and description of the symbols (one) Warning sign...
  • Page 4: Safety Precautions

    Safety precautions Please plug the plug on special 120V AC receptacle.Please guarantee that the earthing wire is ear-thed reliably. A tierra Do not bend ,extend,twist,bind by force.Do not press or nip it with weight. Keep the pin of the power plug clean,if the power plug is polluted with dust, please wipe with dry cloth carefully.
  • Page 5 Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children.Do not let the children climb the washing machine. Do not put any hot or heavy items (such as the kettle with hot water ) on the washing machine.
  • Page 6: Installation And Adjustment

    Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the lint filter 1.Press downward to assmble. 2.Pull upward to detach. Pull down Put up Put up...
  • Page 7: Usage Of The Drain Hose

    Usage of the drain hose The drainage shall be smooth with the drain hose. 1.put the drain hose up to suitable position. Do not put it on ground 2.Do not step on or press the drain hose. Notes: the highest point of drain pipe should be higher than the water level of washing tub for avoiding to siphon phenomenon during drain.
  • Page 8: Install The Water Inlet Hose

    Install the water inlet hose Install the water inlet hose 1. Insert a new flat washer into each end of the inlet hoses. Firmly put the washers in the coupling. Note: Use the new hose sets supplied with the washer.
  • Page 9: Using Process

    1 Preparation before washing Pay attention to followings before washing the laundries Confirm Clear the pocket. there's special Take out the requirment for coins , sand, the laundries. hairpins etc. A. Check if the laundries are applicable for washing with machine. b.
  • Page 10: Put In The Laundries

    2 Put in the laundries Reference weight of the laundries: working suit up,down cotton,about 1120g blanket cotton,about 900g pajamas shirt cotton,about 300g undershirt cotton,about 180g The capacity of washing and spinning of the machine refer to the largest weight of the standard laundries under dry condition that can be washed or spinned in one time.
  • Page 11: Put In The Detergent

    3 Put in the detergent Inlet for concentrated washing powder and detergent Detergent box How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laundries with color or pattern as they are prone to lose color.
  • Page 12: Use The Operation Buttons

    4 Use the operation buttons Description of the function of the buttons PROGRAM STATUS STANDARD HEAVY GENTLE QUICK WASH WASH SPIN " WATER LEVEL"button The user selects a suitable water level depending on the load. SURPLUS(MIN) To indicate -- during sensing. To indicate remaining min.
  • Page 13 During working, push it to pause working. During pause, push this button to restart and continue operation. XQB50-10A START PAUSE Remarks: After pressing "Power On/Off" to connect power supply, if the washing machine lasts idle more than 10 min, it would automatically shut off the supply.
  • Page 14 PROGRAM PROGRAM RESERVATION RESERVATION WATER LEVEL WATER LEVEL Page 9 Using process Using process XQB50-10A POWER POWER START START ON/OFF ON/OFF PAUSE PAUSE POWER POWER...
  • Page 15 Attention Even there's no water in the tub, the spinning will start after a certain period. Do not use soak process for woolen Wash the laundries that are prone to lose colors separately from other laundries. The pulsator will not rotate unless the water is filled to selected water level.
  • Page 16: Close The Top Lid

    Total time: including the normal water inlet time, drain time, excluding the power off time. The total washing time may be influenced by the water inlet pressure and water level. Spin time: the time from intermittent running to finishing. The Jeans program could combine the process of soak during which the washing machine firstly soak for about 25~45 min after water filling and then begins to wash.
  • Page 17: Finish Washing

    6 Finish washing The washing machine cuts off the power supply automatically when wash cycle ends. Disposal after washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning.
  • Page 18: Trouble Shooting Answer To Questions

    Trouble shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department . Do not repair it by yourself.
  • Page 19: Packing List

    Common phenomena Phenomena The spinning is intermittent when it starts. Push the" PROGRAM RESERVATION select "Spin", but it doesn't work. There may be some water flowing out of the drain hose in the first use of the machine. While water filling in wash and rinse, the pulsator pauses rotation Wash pauses Packing list...
  • Page 20: Specifications

    Rated washing / spinning capacity Water level/Water quantity (about) Max water consumption Water inlet pressure Rated washing power Rated spinning power Weight Dimension XQB50-10A 5.0kg Lowest/20L Low/30L Mid/37L High/48L About 144L (High water level; Standard program) 0.03MPa-0.78MPa 325W 285W About 39kg...
