OWNER'S
MANUAL
SERIAL # AFTER
L100313001
MODEL NO.
T844CH
T10544CH
T10544B
T844CH-12V
T1244CH-12V
T8544SP
T12544CH
T10544TSP
T10544BSP
IMPORTANT
Read and follow all Safety
Precautions and
Instructions before
operating this equipment.
Rev.01.12.2002
1602 CORPORATE DRIVE, WARRENSB URG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
ONT44SPH
44" FINISH CUT
TRAILMOWER
Assembly
Operation
Service and Adjustment
Repair Parts
FAX 660-747-8650
PHONE 660-747-8183
Made In The
USA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Swisher T844CH
Summary of Contents for Swisher T844CH
- Page 1 OWNER’S MANUAL SERIAL # AFTER L100313001 MODEL NO. T844CH T10544CH T10544B T844CH-12V 44” FINISH CUT T1244CH-12V TRAILMOWER T8544SP T12544CH T10544TSP T10544BSP IMPORTANT Assembly Read and follow all Safety Operation Precautions and Instructions before Service and Adjustment operating this equipment.
- Page 2 TELESCOPING FRONT BALL LOCK PINS LEFT RIGHT Left offset shown REAR FIGURE ONE T44 RECOIL S TART Slide plastic tube snug against toggle switch. FIGURE TWO T44 12 VOLT S TART FIGURE THREE...
- Page 3 See Detail See Details See Detail See Detail FIGURE FOUR DUAL HEIGHT ADJUST MODELS ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # BELT BA66 TIRE/WHEEL F44157 RIGHT BELT COVER A44155R* HEIGHT ADJUST BOLT ACORN NUT/WASHER NB120/NB272 ADJUST NUT NB213Z REAR BELT COVER 4430TK...
- Page 4 FIGURE S IX BLADE SET-UP FIGURE FIVE ENGINE SET-UP ITEM # DESCRIPTION PART # 3/4 NUT NB175 ITEM # DESCRIPTION PART # UPPER BELLEVILLE AS155 ENGINE NOT AVAILABLE BLADE PULLEY B4104 5/16 BOLT NB253 THIN WASHER NB179 5/16 NUT NB170 BLADE DRIVER 9085 TOGGLE BRACKET...
- Page 5 FIGURE S EVEN FIGURE EIGHT T-HANDLE OPTION STANDARD ENGAGE ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # T-HANDLE LEVER 4463TK COTTER PIN NB126 COTTER PIN NB597 ENGAGE LINKAGE 4534* 1/4 BOLT NB180 1/2 BOLT NB132 WASHER NB274 ENGAGE LEVER 4537* ENGAGE LINK 4461TK...
- Page 6 T-HANDLE OPT. W/ 12 VOLT START WH44B12V BLADE ENGAGE CABLE 9074 12 VOLT MODELS BATTERY (12N12A) RECOMMENDED SOLD SEPARATELY SOLENOID 9043 BATTERY CABLE - POSITIVE BCSR BATTERY CABLE - NEGATIVE EXTRAS VELCRO STRAPS 7033 SWISHER DECAL OD99116 44" DECAL OD99119...
- Page 7 FIGURE ELEVEN ENGAGE / TENSION ASSEMBLY ITEM # DESCRIPTION PART # 3/8 LOCK NUT NB280 WASHER NB272 IDLER PULLEY B527 1/2 SHOULDER BOLT NB220 IDLER ARM OFFSET 687RTK 3/8 JAM NUT NB174 WASHER NB271 3/8 NYLOK NUT NB182 WIRE LINK BRS6H 3/8 BOLT NB231...
- Page 8 FIGURE TWELVE SINGLE POINT HEIGHT ADJUST MODEL ITEM # DESCRIPTION PART # CRANK KNOB CRANK HANDLE ES214 CRANK ROD 4006 SINGLE POINT FRAME 4001TK BUSHING 21008 PIVOT BLOCK 4007TK GRASS CHUTE MOUNT 6030TK CHUTE SPRING 9100 GRASS CHUTE 4019TK TIRE/WHEEL/BEARING F44157 ANTI-SCALP ROLLER 1/2"...
- Page 9 All TrailMower parts listed herein may be ordered directly T10544CH from Swisher Mower & Machine Co. Inc., your nearest Swisher dealer, or from our website. www.swisherinc.com T10544B All engine parts may be ordered from the nearest dealer of the...
