  • Page 1 OWNER’S MANUAL STARTING SERIAL #: L105-349001 ENDING SERIAL #: L106-017000 MODEL NO. T1360B1 T1360T 60” FINISH CUT T1360H T1360K TRAILMOWER T13560 RK1360 T14560 T17560 IMPORTANT Assembly Read and follow all Safety Precautions Operation and Instructions before operating this Service and Adjustment equipment.

  • Page 2: Limited Warranty

    1-800-222-8183. model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects.
  • Page 4 (EECS) on your model year 2006 and later Swisher Product. In California, new Outdoor Power Equipment, must be designed, built and equipped to meet the State’s stringent anti-smog standards. Swisher Mower must warrant the EECS on your Power Equipment, for the period of time listed below provided there has been no abuse, neglect, or improper maintenance.

  • Page 5: Safety Decals

    SAFETY DECALS Replace decals immediately if damaged.Order by part number from Swisher Mowers OD11- No step Decal OD45- Warning Decal OD55- Triangle Danger Decal OD33- Speed Decal OD43- Flying Debris Decal OD29- Danger Decal...
  • Page 6 REQUIRED ASSEMBLY FRONT WHEEL CASTER ASSEMBLY 1. Remove single nut and washers from caster shaft. 2. Place one washer on the shaft of the caster/wheel sub-assembly. 3. Slide same shaft through the bearing/frame with wheel towards the ground. 4. Place the other washer on the shaft; it should be resting on the top bearing. 5.

  • Page 7: Intended Use

    STARTING THE ENGINE See engine manufacturer’s instructions for the type and amount of oil and fuel used. TrailMowers with electric start engines will need a battery (sold separately). Swisher recommends using a standard “U 1 R” lawn & garden battery.

  • Page 8: Starting To Mow

    Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged. Check spark plug wire, oil, and fuel. Check all electrical connections (See Schematics). Make sure toggle switch is turned “ON” and the red tether is properly attached. Set engine idle to “CHOKE”...

  • Page 9: General Troubleshooting

    ALTERNATIVE STOPPING METHOD Bring vehicle to complete stop, shut off engine, and set parking brake. Disengage blade engage lever (6008). Manually shut toggle and key switches to their “OFF” positions. Always remember to remove keys to avoid irresponsible usage. TRANSPORTING MOWER Stop mower properly.

  • Page 10: Mower Maintenance

    MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this Trailmower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season.
  • Page 11 Item No. Description Part # NB149 - WASHER Swivel Hitch IF NECESSARY Frame 6014* Bearing Cotter Pin NB126 Rear Axle 6034 Height Adjustment Handle 5/16 PAL Nut NB276 Plastic Knob Crank Arm ES214 Height Indicator Decal OD41 USE PAINT CODE: TC=RED, TK=BLACK EX:6014TC FRAME DETAIL Item No.
  • Page 12 Description Part # Belt Cover 6025TK Grass Chute 6039TK Chute Bracket 6030TK Anti-Scalp Roller AS001 Deck (T1360B1, T1360T, T1360K, RK1360) 6027* Deck (T1360H, T13560, T14560, T17560) 12248 Chute Spring 9100 Gas Cap 6102NC Gas Tank 6102T Tank Bracket For Kohler Eninge...

  • Page 13: Parts Not Shown

    Slide plastic tube snug SEE ENGINE against toggle switch. DETAIL HEAT SHIELD 6052TK NOT USED ON HONDA UNITS DETAIL 10 MOTOR BASE DETAIL Item No. Description Part # Heat Shield 6052TK Throttle 686N Anti-Scalp Roller AS001 Toggle Switch 685SP Control Console 10737* DETAIL 10 Ignition Switch...

  • Page 14: Engine Detail

    ENGINE DETAIL BRIGGS / TECUMSEH > DETAIL - 1 DETAIL - 1 Item No. Description Part # UPPER SPACER 689L 5-1/2'' ENGINE PULLY 1/4/ X 1'' KEY STOCK 9031 LOWER SPACER 689S 3/8 BELLEVILLE WASHER FLAT WASHER TR150W 3/8-24 X 1BOLT [BRIGGS ] NB452N 7/16-20 X 1 BLOT [TECUMSEH ] NB238N...

  • Page 15: Wiring Schematics

    WIRING SCHEMATICS...

  • Page 16: How To Order Repair Parts

    The model number for the engine will be found on the top of the blower fan housing. T1360B1 All mower parts listed herein may be ordered directly from Swisher Mower & Machine Co. Inc. or your nearest Swisher T1360T dealer. All engine parts may be ordered from the nearest dealer of the...
