OWNER'S
MANUAL
STARTING SERIAL #:
99-307001
MODEL NO.
T1260
T1260F
T1360
T1460
IMPORTANT
Read and follow all
Safety Precautions and
Instructions before
operating this
equipment.
Rev.04-288
P.O. BOX 67, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
ONT60
60" UNIVERSAL
TRAILMOWER
Assembly
Operation
Service and Adjustment
Repair Parts
PHONE 660-747-8183 FAX 660-747-8650
Made In The
USA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Swisher T1260F
Summary of Contents for Swisher T1260F
- Page 1 OWNER’S MANUAL STARTING SERIAL #: 99-307001 MODEL NO. T1260 T1260F T1360 60” UNIVERSAL T1460 TRAILMOWER IMPORTANT Read and follow all Safety Precautions and Assembly Instructions before operating this Operation equipment. Service and Adjustment Rev.04-288 Repair Parts Made In The P.O. BOX 67, WARRENSBURG, MISSOURI 64093...
-
Page 2: Limited Warranty
1-800-222-8183. model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. -
Page 4: Safety Decals
M o w e r b l a d e s a r e s h a r p a n d c a n c u t . W r a p t h e b l a d e s o r w e a r g l o v e s , a n d u s e e x t r a c a u t i o n w h e n s e r v i c i n g t h e m . SAFETY DECALS Replace decals immediately if damaged.Order by part number from Swisher Mowers OD43- Flying Debris Decal OD45- Warning Decal... - Page 5 REQUIRED ASSEMBLY FRONT WHEEL CASTER ASSEMBLY 1. Remove single nut and washers from caster shaft. 2. Place one washer on the shaft of the caster/wheel sub-assembly. 3. Slide same shaft through the bearing/frame with wheel towards the ground. 4. Place the other washer on the shaft; it should be resting on the top bearing. 5.
-
Page 6: Intended Use
STARTING THE ENGINE See engine manufacturer’s instructions for the type and amount of oil and fuel used. TrailMowers with electric start engines will need a battery (sold separately). Swisher recommends using a standard “U 1 R” lawn & garden battery. - Page 7 • Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged. • Check spark plug wire, oil, and fuel. • Check all electrical connections (See Schematics). • Make sure toggle switch is turned “ON” and the red tether is properly attached. •...
-
Page 8: General Troubleshooting
ALTERNATIVE STOPPING METHOD • Bring vehicle to complete stop, shut off engine, and set parking brake. • Disengage blade engage lever (681N). • Manually shut toggle and key switches to their “OFF” positions. • Always remember to remove keys to avoid irresponsible usage. TRANSPORTING MOWER •... -
Page 9: Mower Maintenance
MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this Trailmower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season. - Page 10 POL1260F Service Parts Part Number Description 0-D56 Throttle Decal 0-D57 Consol Decal AS-066 Plastic Connector for Clutch AS-067 Female Connector for Clutch AS-068 In-Line Fuse Holder AS-069 10 Amp Fuse AS-071 1/2" Convoluted Tubing AS-072 End For Convoluted Tubing AS-078 1"...
- Page 11 NB122 NB126 NB195 664N NB149 F4157WF Figure 01 Figure 02 H10TK H10TK Figure 03 661A NB136 CH5S NB181 6031TK steel chute replaces plastic chute shown Figure 04...
- Page 12 NB120 Caster Nut NB122 Gas Tank 6102T Washer NB195 Gas Cap 6102NC Throttle Plate 6155THC Gas Tank Mount 6102NTK Engage Lever 6720C Rubber Bushing AS119 Swisher Decal OD99116 Fuel Shutoff Valve AS120 Fuel Line Hose Clamp 6FLC Fuel Line AS140...
- Page 13 REAR SWITCH FRONT Figure 06 Item # Description Part # Item # Description Part # Clutch Idler Rod/Spring 3123TK/682S Blade Driver Left 9086 Idler Rod/Spring 6704TK/682S Deck 6725TC Idler Pulley B527 Warning Serious Injury Decal OD45 Clutch Idler Arm 6709TK 5 MPH Decal OD33 Idler Bracket...
- Page 14 26 30 Figure 07 Item # Description Part # Blade (3) 9004 Anti-Scalp Roller AS001 Rear Axle 664N MIDDLE CENTER BOTTOM CENTER BLADE DRIVER BLADE DRIVER PULLEY BELT 66LR2 PULLEY BELT 66LR2 TOP CENTER BLADE ENGINE PULLEY BELT 644 DRIVER PULLEY REAR ENGINE PULLEY...
- Page 15 ENGINE 689L 9031 689S NB452N (Briggs & Honda) NB238N (Tecumseh) Not Shown OIL DRAIN VALVE + CAP AS122, AS123 ENGINE PULLEY ASSEMBLY...
- Page 16 BLADE DRIVER ASSEMBLIES EFFECTIVE AFTER SERIAL# L199307001 NB175 6114 AS155 6114CS NB179 9091TK (re-enforcement will vary from what is shown) 9075 shaft replaces 9085 “RIGHT” both the 9002 shaft & 9010 spacer NB175 NB179 AS155 9008 NB216 6114 9004 NB179 NB166 NB607 NB607...
- Page 17 9086 “LEFT” NB175 AS155 6114 12823 9078 shaft replaces both the 9001 shaft and the 9010 spacer B99TK NB179 NB216 9008 9004 NB607 NB238N NB166...
-
Page 18: Honda Wiring Schematic
ELECTRIC START WIRING SCHEMATIC ATTACH RED TETHER HERE HONDA WIRING SCHEMATIC ATTACH RED TETHER HERE... - Page 19 Items Not Shown Item Part # Wiring Harness (Briggs) WHN60B Wiring Harness (Tecumseh) WHN60T Wiring Harness (Honda) WHN60H Solenoid 16915 Frame Caster Bearings Key Switch KS12 Battery Cable - Red BCSR Battery Cable - Black Engine Belt Blade Driver Belts 66LR2 Throttle Cable 686N...
- Page 20 NOTES...
-
Page 21: How To Order Repair Parts
T1260F All mower parts listed herein may be ordered directly from Swisher Mower & Machine Co. Inc. or your nearest Swisher T1360 dealer. All engine parts may be ordered from the nearest dealer of the...
