OWNER'S
MANUAL
MODEL NO.
ST60022Q
START SERIAL # L305-042001
ST65022Q
START SERIAL # L305-042001
ST65022DXQ
START SERIAL # L305-039001
ST6002212V
START SERIAL # L305-109001
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
Rev 06-032
1602 CORPORATE DRIVE, P.O. BOX 67, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
10698
All manuals and user guides at all-guides.com
Visit us at : www.swisherinc.com
Trim-Max
Assembly
Operation
Service and Adjustment
Repair Parts
PHONE 660-747-8183 FAX 660-747-8650
Trim-N-Mow
Made In The
USA

Advertisement

loading
Need help?

Need help?

Do you have a question about the Trim-N-Mow and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Swisher Trim-N-Mow

Summary of Contents for Swisher Trim-N-Mow

  • Page 1 All manuals and user guides at all-guides.com Visit us at : www.swisherinc.com OWNER’S MANUAL Trim-N-Mow MODEL NO. ST60022Q START SERIAL # L305-042001 ST65022Q START SERIAL # L305-042001 ST65022DXQ START SERIAL # L305-039001 ST6002212V Trim-Max START SERIAL # L305-109001 IMPORTANT Read and follow all...

  • Page 2: Limited Warranty

    1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.

  • Page 3: Safety Instructions

    All manuals and user guides at all-guides.com Safety Instructions This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. • Read, understand and follow all instructions in the manual and on the trimmer before starting •...

  • Page 4: Slope Operation

    All manuals and user guides at all-guides.com Slope Operation Slopes are a major factor related to loss of control and slip accidents, which can result in severe injury. All slopes require extra caution. If you feel uneasy on it do not trim it. DO: Trim across the face of a slope and not up and down.
  • Page 5 Do not operate the trimmer if it vibrates abnormally. Excessive vibration is a sign of Damage. Stop the engine and safely check for damage and repair as required Trimmer Head Instruction Decal OD68 Caution Notice Decal OD67 Trim-Max Decal Trim-N-Mow Decal OD64 OD65...

  • Page 6: Handle Adjustment

    All manuals and user guides at all-guides.com Assembly Contents of Box: • Trimmer • Parts bag containing: • Manual • Engine manual • Safety goggles • Bottle of engine oil • 4 sets of .155 trimmer line • Cable Clip Tools Required: •...
  • Page 7 All manuals and user guides at all-guides.com Preparing Unit For First Use • Fill engine crankcase with oil. A bottle has been provided with this unit. DO NOT OVERFILL. • Fill the engine fuel tank with gasoline. GASOLINE SHOULD BE ADDED OUTSIDE IN A WELL-VENTILATED AREA.
  • Page 8 All manuals and user guides at all-guides.com Installing Trimmer Line Important! Use the proper length of line. Using a line too long for the unit will cause stalling and unacceptable operation. 5+ HP use 18” String Pre Cut Line Purchase P3618 Step 1 Step 2 Step 3...
  • Page 9 Occasionally check the belt for wear. A worn belt should be replaced. • Belt Adjustment The TRIM-N-MOW has an automatic belt tightener and needs no further adjustment • The TRIM-MAX has an automatic belt tightener that automatically adjusts when the head is tilted. If •...
  • Page 10 All manuals and user guides at all-guides.com Trim-N-Mow Paint Reference Chart Color Paint Code Texture Black Texture Red See Detail Page 11 Item # Description Part # Item # Description Part # Briggs & Stratton Engine Operator Presence Bail 10397 Trimmer Pulley &...
  • Page 11 All manuals and user guides at all-guides.com Trimmer Head Assembly for Standard Item # Description Part # 5/8-11 2 Way Lock Jam Nut NB595 Blade Pulley- 4.5" 2049 5/8 ID X 1 OD 14 GA Washer NB149 Blade Bearing B985/8 Compression Spring 2033 Head Weldment...
  • Page 12 All manuals and user guides at all-guides.com Service Part 2076 Parts Breakdown Item # Description Part # Shield 2042 Spacer 2084 Knob 2030 Clamp 2043 Bolt NB110 Washer NB275 Trim-Max Axle Setup Item # Description Part # 16" Wheel 2003 Conical Spring 10004 Cotter Pin...
  • Page 13 All manuals and user guides at all-guides.com Deluxe Paint Reference Chart Color Paint Code Texture Black Texture Red See Details Page 12 See Detail Page 11 Item # Description Part # Item # Description Part # Briggs & Stratton Engine Upper Handle 10578TK Engine Pulley- 6"...
  • Page 14 All manuals and user guides at all-guides.com 12 Volt Deluxe Paint Reference Chart Color Paint Code Texture Black Texture Red For Additional Parts See Page 13 Item # Description Part # Wiring Harness 2120B Not Shown Key Switch 2102 Not Shown Keys For Key Switch (set of two) Battery for Weedtrimmer 2101...
  • Page 15 All manuals and user guides at all-guides.com 2101 2102 Notes...
  • Page 16 MANUAL All trimmer parts listed herein may be ordered directly from Swisher Mower & Machine Co. Inc. or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the MODEL NO.
