  • Page 1 IP Kamera 9000A Plus User Guide...

  • Page 2: User Guide

    IP KAMERA 9000A PLUS USER MANUAL User Guide IP Kamera 9000A Manual version: 1.0 Date: Apr.07, 2004 - 1 - VER. 1.0.0,...
  • Page 3 If IP Kamera 9000A does not operate properly, please contact your local dealer for after sale service. In all cases, you are prohibited to disassemble the product. If so, Aviosys does not hold any responsibility for mal-function nor service warranty.

  • Page 4: Table Of Contents

    IP KAMERA 9000A PLUS USER MANUAL Table of Contents 1. PRODUCT OVERVIEW....................4 ...................... FEATURES 2. PHYSICAL DESCRIPTION ..................5 ........................SPECIFICATION ..................SYSTEM MINIMUM REQUIRNMENT 3. PANEL DESCRIPTION…………………………………………………………………6 ……………………………………………………………………………… FRONT PANEL ……………………………………………………………………………….. BACK PANEL 4. INSTALLATION………………………………………………………………………..9 ........................PREPERATION ....................

  • Page 5: Product Overview

    1. Product Overview IP Kamera 9000A is an IP camera that has a digital web server in camera. This camera can put up live image on-line and make remote locations immediately accessible through standard web browsers. IP Kamera 9000A is equipped with cutting edge technology, includes a digital camera, web server, audio in device and optimized hardware for image compression, and physical Ethernet connection.

  • Page 6: Physical Description

    IP KAMERA 9000A PLUS USER MANUAL 2. Physical Description BOX CONTENT IP Kamera package content： IP Kamera 9000A Tripot 1 x RJ 45 internet line 1 x Power DC Adopter 5V, 110~240. 1 x Composite Video Cable 1 x CD ( a. IP Editor program b. User Manual book)

  • Page 7: Panel Description

    3. Panel Description Front Panel : 1. Power indicator ( blue LED ) 2. Lens ( CMOS ) Back Panel : from left to right: 1. Reset Button 2. DC Power - 5V , 110~240 3. On / Off 4. RJ 45(Cat5 Network) 5.

  • Page 8: Installation

    IP KAMERA 9000A PLUS USER MANUAL 4. Installation Before using IP Kamera 9000A, follow bellow: Before installation: Reconfirm your package content A Hub Electricity 110 ~ 240 V Hardware installation 1. Plug in IP Kamera 9000A ( Power ) 2. Plug in RJ 45 line to a HUB 3.
  • Page 9 SOFTWARE INSTALLER After connecting your power and RJ 45 line, please use IPEDIT program that provided by Aviosys to find IP KAMERA 9000A’s address. 區域設定 NAME： IP KAMERA GETEWAY： IP： IP address now NETMASK： HTTP PORT1：sending address HTTP PORT2：sending address Set up : Step by step step: In IE ( Internet Explorer ) / Nescape’s IP EDIT IP please type your IP:...
  • Page 10 IP KAMERA 9000A PLUS USER MANUAL * Security protection warning ( follow step 2 ) 2th step： tools > internet option > security > default level > select Low 3rd step Switch default level to “low” then you will be able to see” IP Kamera 9000A”...
  • Page 11 4th step Switch your security default level back to medium or higher, after you are able to view your picture. tool > internet option > security > default level > select medium 5th step Switch your security default level back to medium or higher, after you are able to view your picture.
  • Page 12 IP KAMERA 9000A PLUS USER MANUAL 5. Network Set up From our Network set up, users can view live video from any where in the world, with just a computer. Click on Network set up: this area is authorized by administrator only.
  • Page 13 2. DHCP setup- ADSL / xDSL: ISP will provide your exact IP address, please enter your Username and password for your provider. 2-1 Enter your user name, password, mail server, mail name (pass word), sender e-mail, receiver e-mail. 2-2 Choose Save & Dial Now, by using PPPoE it can automatically dial to your ISP, and ISP will provide exact IP address in your mail.

  • Page 14: Function

    IP KAMERA 9000A PLUS USER MANUAL 2-3 turn off your browser of IP Kamera 9000A and restart 6. Functions Please refer to all the function on the left side of IP Kamera 9000A AP, most of its configuration can only be use by Administrator.
  • Page 15 1.Picture Quality: Low , High 2.Resolution set up 3.Color: contrast, Sharpness, Hue, Brightness, Saturation STD –Setup 3-1 Brightness Dark Default Bright 3-2 contrast 3-3 Saturation 3-4 Hue - 14 -...
  • Page 16 IP KAMERA 9000A PLUS USER MANUAL 3-5 Sharpness 4. Splits - 4, 9, 16 4-1: 4 4-2: 9 4-3:16 - 15 - VER. 1.0.0,...

  • Page 17: Motion Detection Function

    5. View Log – view which IP has been visiting your Live image Note: View/Log / Camera Window 1. Configuration: System User Motion Detection Network 6-1 System Set up 6-1-1 : Camera name, time and date setup - 16 -...
  • Page 18 IP KAMERA 9000A PLUS USER MANUAL Note: maximum 18 English characyters 6-1--2 : Setup 6-1-3 : Reset: 6-1-4 : Restart IP Kamera 9000A 6-1-5 : Renew its position User Management: Can choose user authorization require optional 6-2 - can choose if viewers needs a password or not.
  • Page 19 6-2-3: You can also delete a user by selecting its name and press delete. 6-3: Motion detection: when motion detection is triggered, it will automatically send video or image to user E-mail or FTP site. 6-3-1: Choose motion detection: Disable - Enable: choose –...
  • Page 20 IP KAMERA 9000A PLUS USER MANUAL 6-3-1-2: When send to FTP, please fill in its FTP server address, user name, password, account and upload path, and click on Upload images when motion detected. 7. When right click mouse , it can also use :...
  • Page 21 7-2 Splite - 1x1, 2x2, 3x3, 4x4 7-3 Rotate Rotate 0 Rotate 180 Rotate 0 Rotate 180 - 20 -...
  • Page 22 IP KAMERA 9000A PLUS USER MANUAL 7-4 Quality High 7-5 Resolution - 640x480, 320X240, 352X288, 176X144 7-5 Image Recording Record image to JPEG and AVI file. Both files can be recorded in the same time. JPEG : can select how many pictures taken.
  • Page 23 7-5-1 Recording AVI Select save as AVI, then select the maximum number of frame in each file. Note: If select No limit, it will continue recording until it used up all memory space. 7-6 Save current picture as - Take a snap shot on current images showed on IP Kamera AP.

  • Page 24: Other Functions

    IP KAMERA 9000A PLUS USER MANUAL 7. Other Functions 1. IP Kamera 9000A can view 9 different IP at the same time. 2. IP Kamera 9000A can receive live audio when plug in microphone receiver. Now user can view and hear live images in the same time.

  • Page 25: Administrator

    ８. Authorization In IP Kamera 9000A factory set up : factory setting Username : administrator Password : 1234 *Is recommended to change its factory setting password and user name 1. Administrator: Change Password: Camera Control: (Quality) - Low, High, Advance (Resolution) - 640*480, 352*288, 320*240, 176*144 (Split) - 1x1, 2x2, 4x4, and 8x8...
  • Page 26 IP KAMERA 9000A PLUS USER MANUAL 1-2 When cancel camera, please select the camera you want to delete and select “Delete Camera 2. Visitor Authorization: Change its own passward View log: check other visitors IP address Add ／ delete camera...

  • Page 27: Caution

    9. Caution Q 1 : I forgot the ID and password for the administrator account, so I cannot log into the Administration Page. A : Make sure IP Kamera 9000 is powered on and press the “reset” button behind IP Kamera 9000A for at least 10 seconds, to help default camera setting to factory setting.
