- Page 1 AM/FM/CD/MP3 Receiver with USB/SD & Auxiliary Input 3 Built-in Microphone inputs for PA Announcements Installation/Operation Manual 50W x 4 CD-2000...
-
Page 2: Controls And Indicators
CONTROLS AND INDICATORS Power Button Volume/Select Knob Band Button Mode Button Reset Button Scan Button Preset Memory Buttons/r Playback Options Mute Button Radio Station Tune/Seek, Track Control Buttons (10) Front Auxiliary Input Jack (11) SD Card Input slot (12) Display Button (13) Clock Button (14) USB Input Slot (15) Eject Button... - Page 3 Thank you for purchasing the CD-2000 AM/FM/CD/MP3/USB/SD Receiver from REI. This product is designed and tested to withstand temperature and vibration extremes. Please read the owner’s manual carefully before attempting to install. IF ADDITIONAL INSTALLATION COMPONENTS ARE NECESSARY, CONTACT YOUR REI...
-
Page 4: Operation
OPERATION 1) Power Button Press the Power Button to turn ON or OFF the unit. A red light means the unit is in standby, a Blue light means the radio is on. 2) Volume/Select Knob Rotate the knob left or right to change the volume level. Press the knob to select one of the following functions: VOL---BASS---TREB---BAL---FAD Rotate the knob to adjust the desired setting. - Page 5 9) TUNE / SEEK /TRACK Buttons Under Radio mode, press the desired button to manually tune a station moving upward or downward. Press and hold button momentarily and the radio will automatically seek or down to the next available radio station. Press and hold button for 2 seconds and the radio continuously tunes up or down until the button is released.
- Page 6 PA OPERATION The CD-2000 has three PA Microphone inputs, 2 Dynamic & 1 Carbon microphone input. All microphones have priority over all other audio modes and MUTE the source audio being played when keyed. When the PA is triggered, the front display will show MIC 1, MIC 2 or MIC, until the trigger is un-keyed.
-
Page 7: Radio Connections
RADIO CONNECTIONS Follow this easy wiring diagram when installing. Be sure to disconnect the battery negative terminal before beginning. -
Page 8: Radio Installation
REQUIRED RADIO DIMENSIONS Verify the radio will fit by following the suggested dimensions below. RADIO INSTALLATION Verify lock Clips on the DIN collar are pressed inward. Place the collar into the dash opening. Bend the tabs outward as shown on the drawing below to secure into place in the Dash Opening. -
Page 9: Troubleshooting
RADIO REMOVAL To remove the radio, disconnect the rear support stud if installed. Remove the front Trim Ring and insert the two release keys on either side of the radio then pull the radio out. TROUBLESHOOTING Problem Cause Measure Power light does not tur n on No power to yellow wire;... -
Page 10: Specifications
SPECIFICATIONS: General Specifications Operating Voltage (10.0 –15.6V allowable) Maximum Current Consumption POWER OUTPUT Continuous Output (4Ω, 20 to 20,000 Hz at 1% THD) 4 x 22 Watts Maximum Power Output 4 x 50 Watts Speaker Impedance 4-8 Ohms FM STEREO RADIO Frequency range USA 87.5MHZ –... -
Page 11: Usb Interface
USB INTERFACE USB Standard USB1.1/2.0 (Full Speed) Maximum Supply Current 500mA File System Fat16/32 Decoding Format same as CD SD CARD INTERFACE Frequency Response (+/- 1dB) 10 – 20,000Hz Dynamic Range 80dB (1kHz) Harmonic Distortion 0.01% Decoding Format same as CD AUDIO PRE-AMP SPECIFICATIONS Max Output level 600Ω...
