  • Page 1 50 W X 4 R-9 05...
  • Page 2 Thank you for purchasing this AM/FM/CD/MP3 Weather Band Receiver from REI. This product is designed and tested to withstand temperature and vibration extremes. Please read the owner s manual carefully before attempting to install this unit. IF ADDITIONAL INSTALLATION COMPONENTS ARE NECESSARY,...
  • Page 3 SPECIFICATIONS CONTROLS AND INDICATORS AUDIO SECTION Power supply voltage (negative ground) ………………………….12V DC (11V-16V) Nominal Current Consumption……...………………………………..…less than 2.5A Max Current Consumption……...…………………………………….………. …..10A Speaker impedance …………………….……………………… 4-8 Ohms per channel POWER OUTPUT (RMS) Continuous Output into 4Ω, 20 to 20,000 Hz at 3 % THD ……...………4 x 14 Watts Maximum Power Output (Volume control Maximum)……………50W×4 (at 1kHz) FM TUNER Range ………………………………………………………..

  • Page 4: Electrical Connections

    REIAudio System REIAudio System THE DIGITAL RADIO ELECTRICAL CONNECTIONS Follow this easy wiring diagram to install new or existing Radio and Speakers. (1) Power On/Off Button Warning: Press the Power Button to turn ON or OFF the unit. **Shorting or grounding any of the speaker wires can damage the radio and is not covered by warranty.

  • Page 5: Installing The Radio

    (8) Scan Button INSTALLING THE RADIO 1. First put the DIN collar in the hole opening,then, use the screwdriver to bend the Under radio mode, press this button to scan to the next stations. It will stay at any tabs outward as shown on the drawing below. available station for 5 seconds and then scan to next available station unless interrupted by the user.
