General Information; Specifications - Agatec LT300 Owner's Manual

GENERAL INFORMATION

Thank you for buying the LT300! Although it is very simple to use, we
recommend that you read this manual before operating the laser.
Description
The LT300 is a visible laser that can be used for leveling, vertical alignment
& squaring. It's totally waterproof and also has scanning and constant
squaring for interior jobs. Other advanced features include: totally automatic
self-leveling in both horizontal and vertical modes; electronic calibration by
the user; and optional remote control.

Specifications

Recommended use
Accuracy
Self-leveling range
Rotation speeds
Scanning lengths
Slope match
Laser battery
Charging time
Battery life
Operating temperature
Dimensions
Weight
Environmental
Laser diode
2
Caution/Certification Label
Class 3R Laser Product
Wave length 630-680 nm
Max. Output Power 5mW
Laser Light: Avoid direct eye exposure
Conforms to IEC 60825-1; 2001
Complies with 21 CFR 1040.10 and 1040.11 except for deviations
Pursuant to Laser Notice No. 50
Dated July 26, 2001
1,000 ft. (300 m) diameter
± 1/8" @ 100 ft. (± 3 mm @ 30 m)
± 8%
0, 90, 150, 300, 450, 600 rpm
From 2 to 35°
5° on both X & Y axis; also, semi-automatic mode
with Y in manual, X in automatic
NiCad rechargeable
15 hours
40 hours
14˚ to 122˚ F (-10˚C to 50˚C)
5" x 4 1/2" x 8 1/2"
(12.5 x 11.5 x 21.9 cm)
7 3/4 lbs. (3.5 kg)
IP67
635 nm, visible, <5mW
IEC/CDRH: Class 3R
